ABB 3HAC022279-001 – RV 400C-224-26-76 Precision Robot Reducer | RV Series Platform
Engineering Background: The ABB 3HAC022279-001 is an OEM-grade RV (Rotary Vector) precision gear reducer engineered specifically for ABB industrial robot joint axes. Designed to deliver ultra-low backlash, high torsional rigidity, and long service life under continuous cyclic loading, this unit is a critical drivetrain component in ABB’s articulated robot platforms.
Product Positioning: Sourced and verified by Konmask.com, this reducer serves procurement engineers and MRO teams requiring a direct OEM replacement or spare for ABB robot systems. It eliminates the risk of dimensional mismatch and performance degradation associated with aftermarket alternatives.
Complete Technical Specifications
- Part Number: 3HAC022279-001
- Cross-Reference / Alternate P/N: 76003HAC056861-001 / 76003HAC14726-2
- Series: RV 400C
- Reduction Ratio: 224 : 1 (nominal, 26-76 stage configuration)
- Gear Type: RV (Rotary Vector) Cycloidal Planetary
- Rated Torque: Per ABB OEM specification for RV-400C frame
- Backlash: ≤ 1 arc-min (OEM tolerance)
- Lubrication: Grease-packed, sealed for life (or per ABB maintenance schedule)
- Weight: Approx. 400 g (unit only, without mounting hardware)
- Country of Origin: Japan (OEM supply chain)
- Condition: New / Genuine OEM
- HS Code: 8483.40 (Gears and gearing; ball or roller screws; gear boxes)
Proven Application Environments
- ABB IRB series articulated robots (joint axis drives)
- Automotive body welding and assembly lines
- Palletizing and material handling cells
- Precision arc welding and laser cutting stations
- Semiconductor and electronics manufacturing automation
- MRO replacement for field-worn or damaged reducer units
Engineering Advantages
- Zero-compromise OEM fit: Identical mounting dimensions, shaft interface, and bolt pattern to factory specification — no shimming or adaptation required.
- Ultra-low backlash: ≤ 1 arc-min ensures positioning repeatability critical for path-accuracy applications.
- High torsional stiffness: RV cycloidal architecture distributes load across multiple contact points, resisting shock and overload.
- Extended service life: Hardened alloy steel cycloid discs and precision needle bearings rated for millions of cycles.
- Sealed lubrication: Factory-filled grease eliminates field lubrication errors during installation.
System Architecture & Signal Flow
In a typical ABB robot joint, the servo motor output shaft drives the RV reducer input (high-speed stage). The cycloidal disc set (low-speed stage) converts high-speed / low-torque rotation into low-speed / high-torque output at the joint flange. The 3HAC022279-001 occupies this drivetrain position, with the 224:1 ratio providing the mechanical advantage required for precise, repeatable joint positioning under full payload.
Signal path: Servo Drive → Motor Shaft → RV Input Pinion → Cycloidal Stage (224:1) → Output Flange → Robot Link
Sourcing & Quality Verification
- All units sourced through verified ABB authorized distribution channels or certified OEM supply partners.
- Each unit inspected for correct part marking, date code, and packaging integrity prior to dispatch.
- Traceability documentation (CoC / packing list) available upon request for regulated industries.
- Anti-counterfeit verification: holographic OEM label and serial number cross-check performed before shipment.
Procurement Process
- Confirm your robot model and joint axis to validate compatibility with 3HAC022279-001.
- Submit your RFQ or place order directly via Konmask.com product page.
- Receive order confirmation with lead time and shipping estimate within 1 business day.
- Unit ships with commercial invoice, packing list, and optional CoC documentation.
- Post-delivery technical support available via support@konmask.com.
Technical FAQ
Q: Is 3HAC022279-001 interchangeable with 76003HAC056861-001 or 76003HAC14726-2?
A: Yes. These are ABB’s alternate/superseded part numbers for the same RV 400C-224-26-76 reducer assembly. All three P/Ns reference the identical unit.
Q: What robot models use this reducer?
A: This unit is used in specific joint axes of ABB IRB series robots. Please provide your robot model and axis number for a definitive compatibility confirmation.
Q: Can I replace this reducer in the field without ABB service?
A: Reducer replacement requires mechanical disassembly of the robot joint and precise torque procedures per ABB service manual. Konmask recommends qualified ABB-certified technicians perform the replacement.
Q: What is the lead time?
A: Standard in-stock units ship within 3–5 business days. Contact us for urgent requirements.
Q: Do you provide a warranty?
A: Yes. Genuine OEM units carry the standard ABB warranty. Konmask additionally provides a 90-day quality guarantee on all shipped units.
