ABB ABBYPG109E (3ASD273001B3) Pulse Encoder Interface Board – ACS800 Drive Option Module
When a high-performance AC drive loses its speed feedback signal, the consequences cascade instantly: motor speed becomes uncontrolled, process tolerances collapse, and in safety-critical applications, emergency shutdowns trigger costly unplanned downtime. In paper mills, steel rolling lines, and precision winding machines, even a momentary loss of encoder feedback can mean scrapped product, damaged equipment, or worse. The ABB ABBYPG109E pulse encoder interface board is the critical link that keeps closed-loop vector control reliable — without it, your ACS800 drive is blind to actual shaft speed.
The ABBYPG109E (part number 3ASD273001B3) is ABB’s dedicated pulse encoder option board for the ACS800 series variable frequency drive platform — one of the most widely deployed industrial drive families globally. Designed to enable closed-loop speed and torque control via incremental encoder feedback, this board slots directly into the ACS800 option slot and communicates natively with the drive’s RDCO/RMIO control board. Its adoption spans demanding sectors including metals, mining, pulp & paper, and material handling, where precise motor control is non-negotiable.
Technical Specifications
- Part Number: ABBYPG109E / 3ASD273001B3
- Manufacturer: ABB
- Compatible Drive Series: ACS800 (single drive and multi-drive configurations)
- Module Type: Pulse Encoder Interface Option Board
- Encoder Input: Incremental TTL/HTL pulse encoder
- Encoder Supply Voltage: 5 V / 15 V / 24 V (selectable)
- Max Encoder Frequency: Up to 200 kHz
- Channels: A, B, Z (differential)
- Interface: Direct plug-in to ACS800 option slot
- Weight: Approx. 2.6 kg (module with packaging)
- Condition: New / Surplus / Refurbished (specify on inquiry)
Key Features & Benefits
- Closed-Loop Precision: Enables true closed-loop vector control for demanding speed and torque accuracy requirements
- Plug-and-Play Integration: Designed as a native ABB option board — no external signal converters or adapters required
- Wide Encoder Compatibility: Supports TTL and HTL incremental encoders with selectable supply voltage
- High-Frequency Response: Handles encoder pulse frequencies up to 200 kHz for high-speed applications
- Robust Signal Integrity: Differential A/B/Z channel inputs reject common-mode noise in industrial environments
- Direct Drive Communication: Interfaces natively with ACS800 RMIO control board for seamless parameter configuration
- Reduced Commissioning Time: ABB DriveStudio / Drive Composer compatible for fast setup and diagnostics
Industry & Equipment Applications
- Metals & Steel: Rolling mills, coilers, tension reels requiring precise speed synchronization
- Pulp & Paper: Winders, unwinders, and section drives demanding tight speed ratio control
- Mining & Minerals: Conveyor drives, hoists, and crushers with closed-loop torque control
- Material Handling: Cranes, elevators, and automated storage systems
- Water & Wastewater: Pump and fan drives requiring accurate flow control
- General Manufacturing: Any ACS800-driven application requiring encoder-based closed-loop feedback
System Integration & Compatible Parts
The ABBYPG109E is designed for use within the ABB ACS800 drive ecosystem. Compatible and commonly paired components include:
- ABB ACS800 Single Drive Control Board (RMIO)
- ABB RDCO-02 / RDCO-03 Communication Option Boards
- ABB RAIO-01 Analog I/O Extension Module
- ABB RDIO-01 Digital I/O Extension Module
- ABB RTAC-01 Pulse Encoder Interface (alternative series)
- Standard incremental encoders: 5V TTL or 24V HTL, 1024 PPR typical
Always verify the ACS800 firmware version and option slot availability before ordering. Our technical team can assist with compatibility confirmation.
Our Quality Assurance Process
At Konmask.com, every ABB module we supply undergoes a structured verification process before shipment:
- Visual Inspection: PCB, connectors, and housing checked for physical damage or corrosion
- Label & Part Number Verification: Cross-referenced against ABB official part databases
- Functional Test (where applicable): Boards tested on compatible ACS800 test rigs
- Anti-Static Packaging: Shipped in ESD-safe bags with foam protection
- Documentation: Test report and certificate of conformity available on request
How to Order
- Submit your inquiry via the Contact / Request a Quote button on this page
- Provide your drive model, serial number, and required quantity
- Our team will confirm availability, lead time, and pricing within 24 hours
- Upon agreement, we issue a proforma invoice and arrange secure international shipping
- Tracking information provided upon dispatch — DHL / FedEx / UPS available
Why Choose Konmask.com?
- Specialized Inventory: Focused exclusively on industrial automation components — ABB, Siemens, Schneider, Rockwell, and more
- Global Shipping: Export experience to 50+ countries with full customs documentation support
- Technical Expertise: Our team includes qualified automation engineers who understand your application
- Fast Response: Inquiries answered within 24 business hours
- Competitive Pricing: Direct sourcing relationships enable cost-effective pricing for MRO and project procurement
- Trusted by Industry: Serving OEMs, system integrators, and plant maintenance teams worldwide
Frequently Asked Questions
Q: Is the ABBYPG109E compatible with all ACS800 variants?
A: The ABBYPG109E is designed for the ACS800 single drive series. Compatibility with ACS800 multi-drive or regenerative units should be confirmed against your specific drive type and firmware version. Contact us for verification.
Q: What encoder types are supported?
A: The board supports incremental TTL (5V) and HTL (15V/24V) encoders with differential A, B, and Z channel inputs. Absolute encoders are not supported by this module.
Q: Can I use this board as a direct replacement for a failed ABBYPG109E?
A: Yes, provided the replacement board is the same hardware revision. We recommend noting the revision code on your existing board and specifying it in your inquiry.
Q: Do you provide a warranty?
A: Yes. We offer a standard 90-day warranty on all tested units. Extended warranty options are available — please inquire.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For sourced units, lead time is typically 5–15 business days depending on origin. Exact lead time confirmed at time of inquiry.
Q: Can you provide an export declaration or customs invoice?
A: Yes. We provide full export documentation including commercial invoice, packing list, and certificate of origin as required.
