PROFIBUS DP Fieldbus Solution – ABB CI853K01 3BSE018103R1 | AC 800M Series
The ABB CI853K01 (Part No. 3BSE018103R1) is a PROFIBUS DP master communication interface module designed for the AC 800M distributed control system platform. It enables seamless fieldbus integration between the AC 800M controller and PROFIBUS DP field devices — a critical link in modern process automation architectures.
Where This Product Is Used
The CI853K01 is deployed across a wide range of process-critical industries where PROFIBUS DP fieldbus communication is the backbone of field device integration:
- Oil & Gas Refineries — Connecting remote I/O, valve positioners, and flow transmitters via PROFIBUS DP to the AC 800M DCS backbone
- Chemical & Petrochemical Plants — Integrating distributed field instruments in hazardous-area loops requiring deterministic communication
- Power Generation (Thermal & Hydro) — Coordinating turbine control, boiler management, and auxiliary systems through a unified PROFIBUS network
- Pulp & Paper Mills — Managing high-speed process loops with consistent cycle times via PROFIBUS DP master/slave topology
- Water & Wastewater Treatment — Linking pumps, actuators, and analyzers to centralized AC 800M control nodes
- Pharmaceutical Manufacturing — Supporting GMP-compliant process control with reliable, auditable fieldbus communication
- Mining & Minerals Processing — Robust fieldbus connectivity in electrically noisy, high-vibration environments
Technical Specifications
| Part Number | CI853K01 |
| ABB Reference | 3BSE018103R1 |
| Manufacturer | ABB |
| Product Series | AC 800M |
| Module Type | PROFIBUS DP Communication Interface |
| Fieldbus Protocol | PROFIBUS DP (EN 50170 / IEC 61158) |
| PROFIBUS Role | DP Master (Class 1) |
| Max. DP Slaves | Up to 125 slaves per segment |
| Baud Rate | 9.6 kbps – 12 Mbps (auto-detect) |
| Connector | 9-pin D-Sub (DB9) |
| Power Supply | Via AC 800M controller backplane |
| Operating Temperature | 0°C to +55°C |
| Weight | 440 g |
| Certifications | CE, UL, ATEX (zone 2 when installed per ABB guidelines) |
Why Engineers Specify This Model
- Native AC 800M Integration — Plug-in module with zero external wiring; communicates directly over the controller’s internal bus
- Deterministic Cycle Times — PROFIBUS DP master ensures predictable, low-latency data exchange critical for closed-loop process control
- High Slave Capacity — Supports up to 125 DP slave devices per interface, reducing the number of controllers needed in large installations
- Auto Baud Rate Detection — Simplifies commissioning; no manual baud rate configuration required
- Proven Field Reliability — Widely deployed in ABB 800xA and Symphony Plus DCS environments globally since 2003
- Long Product Lifecycle — ABB’s extended support commitment makes this module a safe long-term investment for brownfield plants
Complete System Bill of Materials
The CI853K01 operates within the ABB AC 800M ecosystem. Typical companion components include:
- PM861AK01 / PM864AK01 — AC 800M Processor Modules (controller CPU)
- TB807 / TB811 — PROFIBUS DP Termination Boards
- CI854AK01 — PROFIBUS DP Slave Interface (for redundant configurations)
- SD821 / SD822 — Power Supply Units for AC 800M racks
- TK850V007 — PROFIBUS DP Cable Kit
- CI860K01 — FF HSE Communication Interface (for Foundation Fieldbus segments)
Contact us to source a complete BOM for your AC 800M upgrade or expansion project.
Compliance & Industry Standards
- PROFIBUS DP: EN 50170 / IEC 61158 / IEC 61784
- EMC Directive: 2014/30/EU (CE marked)
- Low Voltage Directive: 2014/35/EU
- UL Listed for industrial control equipment
- RoHS 2 Compliant (2011/65/EU)
- ATEX Zone 2 compatible (per ABB installation guidelines)
Quality Assurance & Sourcing
At Konmask.com, every ABB module undergoes a structured verification process before dispatch:
- Visual Inspection — Enclosure integrity, label authenticity, connector condition, and ABB holographic seal verification
- Firmware & Version Check — Firmware revision confirmed against ABB’s official release matrix
- Functional Bench Test — Module powered and enumerated on an AC 800M test rack; PROFIBUS DP communication verified with a live slave device
- Documentation Package — ABB datasheet, test report, and certificate of conformity included with every shipment
We source CI853K01 units from decommissioned ABB-maintained plants, certified ABB distributors, and authorized surplus channels — never from unverified grey-market sources.
How to Source This Part
- Submit a Quote Request — Email [email protected] with your required quantity and delivery timeline
- Receive Availability Confirmation — We confirm stock, condition (new / tested surplus), and lead time within 24 hours
- Review & Accept Quotation — Itemized quote with unit price, shipping cost, and payment terms
- Order Confirmation & Payment — Secure payment via T/T, PayPal, or trade assurance
- Dispatch & Tracking — Shipped via DHL / FedEx with full tracking; export documentation included for international orders
Application-Specific FAQ
Q: Can CI853K01 be used as a PROFIBUS DP slave?
A: No. The CI853K01 operates exclusively as a DP Class 1 Master. For slave functionality, use the CI854AK01.
Q: Is CI853K01 compatible with ABB 800xA?
A: Yes. It is fully supported under ABB 800xA System Version 5.x and 6.x when used with compatible PM8xx processor modules.
Q: Can it replace CI853 (without the K01 suffix)?
A: The K01 suffix denotes a kit version including mounting hardware. Functionally identical to CI853; confirm your rack configuration before ordering.
Q: What is the maximum cable length for PROFIBUS DP at 12 Mbps?
A: 100 meters per segment at 12 Mbps. Use repeaters to extend the network. At 1.5 Mbps, maximum segment length is 200 meters.
Q: Do you provide warranty on surplus units?
A: Yes — all tested surplus units carry a 12-month functional warranty from date of shipment.
Q: Can you supply multiple units for a plant-wide upgrade?
A: Yes. We regularly fulfill multi-unit orders for plant upgrades and spare parts programs. Contact us for volume pricing.
