ABB DSQC345C 3HAB8101-3 Drive Rectifier Unit – IRC5 Robot Controller Power Supply
When a drive rectifier unit fails inside an ABB IRC5 robot controller, the entire production line comes to a halt. The robot loses its power conversion backbone — AC mains voltage can no longer be transformed into the stable DC bus voltage that servo drives depend on. Without a functioning rectifier, every axis goes dead, every programmed motion stops, and every minute of downtime translates directly into lost output, missed delivery windows, and escalating maintenance costs. In high-throughput automotive, electronics, and heavy-industry environments, this single component is the gatekeeper between your power grid and your robot’s motion system.
The ABB DSQC345C, part number 3HAB8101-3, is the factory-specified Drive Rectifier Unit for ABB IRC5 single-cabinet and dual-cabinet robot controllers. Within the IRC5 platform — ABB’s most widely deployed industrial robot controller family — the DSQC345C occupies a critical position in the drive module stack, converting three-phase AC input into a regulated DC bus that feeds the axis computer and drive units for all six robot axes. Its robust design, tight voltage regulation, and compatibility with ABB’s SafeMove and FlexPendant ecosystem make it the preferred replacement part for maintenance engineers worldwide.
Technical Specifications
- Part Number: DSQC345C / 3HAB8101-3
- Manufacturer: ABB Robotics
- Series: IRC5 Robot Controller
- Function: Drive Rectifier Unit — AC to DC bus conversion
- Compatible Controller Types: IRC5 Single Cabinet, IRC5 Dual Cabinet, IRC5 Panel Mounted Controller
- Weight: 3,680 g (approx.)
- Condition Available: New / Refurbished / Tested Used
Key Features & Benefits
- Factory-Matched Design: Engineered specifically for the IRC5 drive module bay — no adaptation or modification required for drop-in replacement.
- Stable DC Bus Output: Delivers consistent DC voltage to servo drive units, ensuring smooth multi-axis coordinated motion and preventing nuisance faults.
- Robust Thermal Management: Built-in thermal protection and heat-dissipation design supports continuous-duty industrial cycles without derating.
- Fast Fault Recovery: Replacing a failed DSQC345C restores full IRC5 controller functionality, minimizing MTTR (Mean Time to Repair) on the production floor.
- Long Service Life: Designed to ABB’s industrial-grade reliability standards for demanding 24/7 manufacturing environments.
- Global Availability: Stocked and shipped internationally from Konmask.com to minimize lead times for urgent maintenance needs.
Industry & Equipment Applications
- Automotive Manufacturing: Welding robots, body-in-white assembly lines, paint shop robots using ABB IRB 6600, IRB 6640, IRB 7600 series.
- Electronics & Semiconductor: Pick-and-place, PCB handling, and precision assembly robots in cleanroom environments.
- Metal Fabrication: Arc welding, plasma cutting, and press-tending robots requiring high-duty-cycle power stability.
- Food & Beverage: Palletizing and packaging robots (IRB 460, IRB 660) in high-throughput logistics lines.
- General Industrial Automation: Any facility running ABB IRC5-based robot cells requiring preventive or corrective maintenance.
System Integration & Compatible Parts
The DSQC345C works within the IRC5 drive module ecosystem. Common companion parts for a complete controller overhaul include:
- DSQC346 / DSQC346A — Drive Unit (Axis Computer)
- DSQC609 — Power Supply Unit
- DSQC679 — FlexPendant (Teach Pendant)
- DSQC1000 — Main Computer Unit
- 3HAC026254-001 — IRC5 Drive Module Cabinet
If you are unsure which additional parts are needed for your specific robot model and software version, our technical team can assist with a full BOM review before you order.
Our Quality Assurance Process
- Visual Inspection: Every unit is inspected for physical damage, burnt components, corrosion, and connector integrity before listing.
- Functional Testing: Where applicable, units are bench-tested under load conditions to verify DC output stability and protection circuit operation.
- Traceability: Part numbers, revision codes, and serial numbers are verified against ABB documentation to confirm authenticity and compatibility.
- Secure Packaging: Anti-static packaging with foam cushioning ensures safe transit for sensitive power electronics.
- Warranty: All units ship with Konmask.com’s standard warranty. Contact us for specific terms applicable to your order.
How to Order
- Submit an inquiry via the Contact / Request a Quote form on this page.
- Provide your robot model, controller serial number, and required quantity — our team will confirm compatibility and stock availability within 1 business day.
- Receive a formal quotation with lead time, shipping options, and payment terms.
- Confirm your order and receive tracking information once dispatched.
For urgent requirements, please email support@konmask.com or call +0086 19859288691 directly.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC modules, DCS components, robot controller parts, and industrial drives — not general electronics.
- Global B2B Supply: Serving maintenance engineers, MRO procurement teams, and system integrators across Asia, Europe, and the Americas.
- Technical Pre-Sales Support: Our engineers can help verify part compatibility before you commit to a purchase.
- Competitive Lead Times: Extensive inventory network enables fast sourcing even for discontinued or hard-to-find ABB parts.
- Transparent Documentation: We provide datasheets, photos, and test reports on request — no surprises on delivery.
Frequently Asked Questions
Q: What is the difference between DSQC345C and DSQC345?
A: The “C” suffix denotes a hardware revision with updated component specifications. DSQC345C (3HAB8101-3) is the current production revision and is backward-compatible with earlier IRC5 controller configurations that used DSQC345 or DSQC345B. Always verify your controller’s drive module revision before ordering.
Q: Is this part compatible with IRC5 Compact controllers?
A: The DSQC345C is designed for the standard IRC5 single-cabinet and dual-cabinet drive module. IRC5 Compact uses a different power architecture. Please contact us with your controller type and serial number for confirmation.
Q: Can I get a datasheet or test report for this unit?
A: Yes. We provide available documentation upon request after inquiry submission. Contact support@konmask.com with your order reference.
Q: What is the lead time for the ABB DSQC345C?
A: Lead time depends on current stock status. In-stock units typically ship within 2–5 business days internationally. Contact us for real-time availability.
Q: Do you accept returns or offer a warranty?
A: Yes. Konmask.com offers a standard warranty on all parts. Terms vary by condition (new vs. refurbished). Please review our warranty policy or contact our team for details specific to your order.
