HVAC & Pump Drive Solution — ABB ACS550-01-045A-4+B055 | ACS550 Series
Where This Product Is Used
The ABB ACS550-01-045A-4+B055 is a 22 kW (30 HP) general-purpose AC variable frequency drive engineered for demanding industrial and commercial environments. Engineers and system integrators specify this drive across a wide range of motor-control applications:
- HVAC Systems — Variable-speed control of supply/return air fans and chiller pumps in commercial buildings, data centers, and hospitals.
- Water & Wastewater — Centrifugal pump speed regulation for municipal water treatment plants, booster stations, and irrigation systems.
- Industrial Conveyors — Smooth start/stop and speed ramping for belt conveyors, roller tables, and material-handling lines.
- Compressors — Energy-efficient control of screw and reciprocating compressors in manufacturing and process industries.
- Mixers & Agitators — Precise torque control for chemical reactors, food-processing mixers, and wastewater aeration basins.
- Cooling Towers — Fan-speed modulation to maintain optimal thermal performance while reducing energy consumption.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | ACS550-01-045A-4+B055 |
| Brand | ABB |
| Series | ACS550 |
| Output Current (Continuous) | 45 A |
| Motor Power (400 V) | 22 kW / 30 HP |
| Input Voltage | 3-phase 380–480 V AC ±10% |
| Output Voltage | 0–Input Voltage |
| Input Frequency | 48–63 Hz |
| Output Frequency Range | 0–500 Hz |
| Control Method | Scalar (V/Hz) & Sensorless Vector |
| EMC Filter | Built-in (B055 option, Class C2) |
| Protection Class | IP21 (standard) |
| Ambient Temperature | -15°C to +50°C (operating) |
| Cooling Method | Forced air cooling |
| Communication | Modbus RTU (standard); optional fieldbus modules |
| Weight | Approx. 3.3 kg |
| Certifications | CE, UL, cUL, RoHS |
Why Engineers Specify This Model
- Built-in EMC Filter (B055) — Eliminates the need for an external line filter, reducing panel footprint and wiring complexity. Meets EN 61800-3 Class C2 limits out of the box.
- Energy Savings — ABB’s Energy Optimizer function automatically adjusts magnetizing current to minimize losses at partial loads — critical for pump and fan applications running below full speed.
- Application Macros — Pre-configured parameter sets for HVAC, pump, fan, and general machinery reduce commissioning time from hours to minutes.
- Integrated PID Controller — Closed-loop process control (pressure, flow, temperature) without an external PLC for simple single-loop applications.
- Safe Torque Off (STO) — Meets IEC 61508 SIL 1 / EN 954-1 Cat. 3 for safety-critical stop functions without main contactor.
- Fieldbus Flexibility — Optional plug-in modules support PROFIBUS-DP, DeviceNet, CANopen, EtherNet/IP, and Modbus TCP for seamless integration into existing automation architectures.
Complete System Bill of Materials
For a fully engineered ACS550 drive panel, consider pairing this unit with:
- ABB ACH550 / ACS550 input choke (du/dt filter) for long motor cable runs (>50 m)
- ABB NEMA 1 / IP54 enclosure kit for outdoor or wash-down environments
- ABB RDNA-01 DeviceNet adapter or RPBA-01 PROFIBUS-DP module
- ABB JOKAB Safety relay for STO wiring
- Shielded motor cable (min. 4-core + ground) per ABB installation guidelines
- Upstream fuses: gG type, sized per ACS550 hardware manual Table 9-1
Compliance & Industry Standards
- CE Marking — Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL 508C — Power Conversion Equipment (North America)
- IEC 61800-5-1 — Adjustable speed electrical power drive systems — Safety
- IEC 61800-3 — EMC requirements (with B055 filter: Category C2)
- EN ISO 13849-1 — Safety of machinery (STO function)
- RoHS 2011/65/EU — Restriction of hazardous substances
Quality Assurance & Sourcing
Every ABB ACS550-01-045A-4+B055 unit supplied by Konmask.com is:
- Sourced directly from ABB-authorized distribution channels or verified surplus stock with full traceability documentation.
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch.
- Shipped with original ABB packaging, documentation, and serial number intact.
- Backed by Konmask’s quality guarantee — counterfeit-free assurance with photographic inspection records available on request.
How to Source This Part
Ready to order or need a formal quotation? Contact our technical sales team:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Website: https://Konmask.com
- Provide your required quantity, delivery timeline, and destination country for an accurate lead time and freight quote.
- OEM, system integrator, and volume pricing available upon request.
Application-Specific FAQ
Q: Can the ACS550-01-045A-4+B055 control a 22 kW pump motor directly?
A: Yes. The drive is rated for 45 A continuous output at 400 V, which matches standard 22 kW 4-pole induction motors. Verify motor nameplate current does not exceed 45 A.
Q: Is an external EMC filter required?
A: No. The +B055 suffix denotes a factory-installed Class C2 EMC filter. This satisfies EN 61800-3 requirements for industrial environments without additional external filtering.
Q: What fieldbus protocols are supported?
A: Modbus RTU is built-in via the standard RS-485 port. Optional plug-in adapter modules add PROFIBUS-DP, DeviceNet, CANopen, EtherNet/IP, and Modbus TCP support.
Q: Can this drive be used in a HVAC BMS integration?
A: Yes. The integrated PID controller and Modbus RTU interface allow direct integration with BACnet gateways and most building management systems.
Q: What is the warranty period?
A: Konmask.com provides a 12-month warranty on all ABB drives against manufacturing defects. Extended warranty options are available — contact us for details.
