Industrial Ethernet-to-Serial Gateway Solution — ADVANTECH ADAM-4572 | ADAM-4500 Series
Where This Product Is Used
The ADVANTECH ADAM-4572 is deployed wherever legacy RS-232/RS-485/RS-422 serial devices must be integrated into modern Ethernet-based SCADA, DCS, or IIoT networks without replacing existing field instruments. Typical deployment environments include:
- Water & Wastewater Treatment Plants — bridging Modbus RTU meters and flow sensors to Ethernet SCADA hosts
- Power Generation & Substations — connecting serial protection relays and energy meters to TCP/IP supervisory systems
- Oil & Gas Pipelines — remote RTU serial port extension over Ethernet backbone
- Factory Automation & Assembly Lines — integrating serial PLCs (Mitsubishi, Siemens, Omron) into Ethernet control networks
- Building Management Systems (BMS) — linking BACnet MS/TP or Modbus RTU HVAC controllers to IP-based BMS platforms
- Transportation & Traffic Control — serial-to-Ethernet conversion for roadside controllers and signal equipment
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ADAM-4572 |
| Series | ADVANTECH ADAM-4500 |
| Function | Ethernet-to-Serial Gateway / Device Server |
| Serial Interfaces | RS-232 / RS-485 / RS-422 (software selectable) |
| Serial Ports | 1 × DB9 male |
| Baud Rate | 300 bps – 115.2 Kbps |
| Ethernet Interface | 10/100 Mbps, RJ-45 |
| Protocols Supported | TCP/IP, UDP, Modbus TCP, Virtual COM (VCOM) |
| Operating Temperature | -10°C to +70°C |
| Storage Temperature | -20°C to +85°C |
| Relative Humidity | 5% – 95% RH (non-condensing) |
| Power Supply | 10 – 30 VDC (unregulated) |
| Power Consumption | ≤ 2.5 W typical |
| Isolation | 1,500 VDC (serial port isolation) |
| Housing | DIN-rail mountable, compact plastic enclosure |
| Dimensions (W×H×D) | ~72 × 120 × 35 mm |
| Weight | ~200 g |
| Certifications | CE, FCC Class A, RoHS |
Why Engineers Specify This Model
- Transparent Serial Tunneling — Virtual COM port driver allows existing serial software to communicate over Ethernet with zero code changes
- Modbus Protocol Conversion — Native Modbus RTU ↔ Modbus TCP gateway eliminates the need for a separate protocol converter
- Wide Power Input Range — 10–30 VDC accepts both 12 V and 24 V industrial power rails without additional regulators
- Robust Serial Isolation — 1,500 VDC isolation protects the host network from ground loops and surge events common in industrial environments
- DIN-Rail Form Factor — Snap-mount installation in standard control cabinets; no custom panel cutout required
- ADVANTECH Ecosystem Compatibility — Fully supported by ADVANTECH Adam/Apax .NET Utility and third-party SCADA platforms (Wonderware, Ignition, iFIX)
- Long Product Lifecycle — ADVANTECH industrial-grade components rated for 10+ year availability, critical for brownfield retrofit projects
Complete System Bill of Materials
A typical ADAM-4572 installation requires the following components:
- ADAM-4572 — Ethernet-to-Serial Gateway (this unit)
- Power Supply — 24 VDC DIN-rail PSU (e.g., ADVANTECH PWR-242 or equivalent, 1 A minimum)
- DIN-Rail — 35 mm TS-35 standard rail, minimum 80 mm section
- Ethernet Patch Cable — Cat5e or Cat6, shielded (STP) recommended for industrial environments
- Serial Cable — DB9 to terminal block adapter or pre-wired RS-485 cable (application dependent)
- Managed Ethernet Switch — Industrial-grade (e.g., ADVANTECH EKI-2528 or equivalent) for multi-device networks
- Virtual COM Driver — ADVANTECH VCOM utility (free download from ADVANTECH support portal)
- Grounding Lug & Wire — For chassis earth bonding per IEC 60364
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- FCC Part 15 Class A — Suitable for industrial/commercial environments
- RoHS 2 Compliant — Directive 2011/65/EU; lead-free, halogen-restricted materials
- Modbus Protocol — Compliant with Modbus.org specification (RTU and TCP modes)
- IEC 61000-4 Series — ESD, EFT/Burst, and surge immunity per industrial EMC standards
Quality Assurance & Sourcing
All ADVANTECH ADAM-4572 units supplied by Konmask.com are:
- Sourced directly from ADVANTECH-authorized distribution channels or verified industrial surplus with full traceability
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Shipped with original ADVANTECH packaging, documentation, and accessories where available
- Backed by Konmask.com’s quality guarantee — counterfeit-free policy with full refund on verified non-genuine units
- Supported by pre-sales technical consultation for application fit verification
How to Source This Part
To place an order or request a quotation for the ADAM-4572:
- Online Order — Add to cart directly on this page; HKD pricing shown; multi-currency checkout available
- Bulk / Project Quotation — Email support@konmask.com with quantity, delivery location, and required lead time
- Phone / WhatsApp — +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Expedited Availability — In-stock units typically ship within 1–3 business days from Fujian, China; DHL/FedEx international express available
- OEM / System Integrator Accounts — Contact us for volume pricing tiers and NET payment terms
Application-Specific FAQ
Q: Can the ADAM-4572 convert Modbus RTU to Modbus TCP automatically?
A: Yes. The ADAM-4572 operates as a transparent Modbus gateway. Configure it in “Modbus Gateway” mode via the utility software and it will translate RTU frames from serial devices into Modbus TCP responses for Ethernet SCADA clients — no additional converter required.
Q: How many TCP connections can the ADAM-4572 handle simultaneously?
A: The ADAM-4572 supports up to 4 simultaneous TCP connections to the same serial port, allowing multiple SCADA clients or HMI stations to poll the same serial device concurrently.
Q: Is the ADAM-4572 compatible with Siemens S7 or Mitsubishi FX PLCs?
A: The ADAM-4572 provides transparent serial tunneling, so any PLC with an RS-232 or RS-485 programming/communication port can be accessed over Ethernet using the Virtual COM driver. Protocol-level compatibility depends on the SCADA/HMI software driver, not the gateway itself.
Q: What is the maximum cable distance for RS-485 with the ADAM-4572?
A: RS-485 supports up to 1,200 m (4,000 ft) at lower baud rates (e.g., 9,600 bps). For longer runs, use a repeater. Shielded twisted-pair (STP) cable is recommended for noise immunity in industrial environments.
Q: Can I use the ADAM-4572 in a hazardous area (Zone 2 / Class I Div 2)?
A: The standard ADAM-4572 is not ATEX or IECEx certified. For hazardous area installations, install the unit in a purged/pressurized enclosure rated for the zone, or consult Konmask.com for alternative ADVANTECH models with appropriate certifications.
Q: Does Konmask.com provide firmware update support?
A: Yes. We provide guidance on firmware update procedures using the ADVANTECH Adam/Apax .NET Utility. Contact support@konmask.com for the latest firmware file and step-by-step instructions specific to your application.
