B&R 8LSA34.E3030D200-0 – High-Precision Synchronous Servo Motor | ACOPOSmulti Platform
Engineering Background: The B&R 8LSA series represents the core motion axis solution within the ACOPOSmulti multi-axis servo drive ecosystem. Engineered in Austria to IEC and EN standards, these motors are designed for deterministic, high-dynamic positioning in demanding industrial automation environments where cycle time, repeatability, and thermal stability are non-negotiable.
Product Positioning: The 8LSA34.E3030D200-0 is a compact-frame (size 34) synchronous servo motor optimized for medium-inertia loads requiring precise torque control. It integrates natively with B&R ACOPOSmulti drive modules via EnDat 2.2 or resolver feedback, enabling single-cable or standard wiring configurations. Ideal for OEM machine builders and system integrators standardizing on the B&R automation platform.
Complete Technical Specifications
- Part Number / SKU: 8LSA34.E3030D200-0
- Series: 8LSA — ACOPOSmulti Synchronous Servo Motor
- Frame Size: 34 (compact)
- Motor Type: Permanent Magnet Synchronous (PMSM)
- Feedback Code (E): EnDat 2.2 encoder
- Winding / Speed Code (3030): Nominal speed 3000 rpm
- Brake Option (D): With holding brake
- Shaft / Flange Code (200): Standard smooth shaft, IEC flange
- Variant: -0 (standard configuration)
- Protection Class: IP65 (shaft end IP54)
- Insulation Class: F (155 °C)
- Ambient Temperature: 0 °C to +40 °C (operating)
- Weight: approx. 6.8 kg
- Country of Origin: Austria
- Compatible Drive Platform: B&R ACOPOSmulti (8BVI / 8B0 series modules)
- Certifications: CE, UL (per B&R platform certification)
Proven Application Environments
- Packaging machinery: pick-and-place, form-fill-seal, cartoning lines
- Printing & converting: register control, web tension, cut-to-length
- Semiconductor & electronics assembly: gantry axes, wafer handling
- Plastics & rubber: injection molding clamp and ejector axes
- Robotics: articulated arm joint drives, SCARA axes
- Material handling: conveyor indexing, palletizing, AGV drives
Engineering Advantages
- Native ACOPOSmulti Integration: Plug-and-play motor data via B&R Automation Studio — no manual parameter entry required.
- EnDat 2.2 Feedback: Absolute multiturn position data eliminates homing cycles and improves restart safety after E-stop.
- Integrated Holding Brake: Spring-applied, electrically released brake ensures safe load holding at zero speed without drive power.
- Compact Frame 34 Footprint: High torque density in a small envelope reduces machine frame size and inertia mismatch.
- IP65 Sealing: Suitable for wash-down adjacent zones and coolant mist environments without additional enclosure.
- Low Cogging Torque: Skewed rotor design minimizes velocity ripple for smooth low-speed operation in tension control and contouring.
System Architecture & Signal Flow
The 8LSA34.E3030D200-0 connects to an ACOPOSmulti drive module (e.g., 8BVI0014HWS0.000-1) via a hybrid motor cable carrying power (U/V/W + PE) and EnDat 2.2 feedback signals on a single connector. The drive module communicates with the B&R X20 or X67 controller over POWERLINK (IEC 61158) at 400 µs cycle time. Automation Studio 4.x handles motor parameterization, electronic cam profiles, and CNC path interpolation within the same engineering environment.
Typical wiring path: Controller (X20CP) → POWERLINK → ACOPOSmulti Inverter Module → Hybrid Cable → 8LSA34.E3030D200-0
Sourcing & Quality Verification
- Source: Decommissioned OEM production lines and authorized surplus channels — not gray-market or counterfeit.
- Inspection: Each unit undergoes visual inspection, connector integrity check, and encoder signal verification prior to listing.
- Traceability: Serial number and manufacturing date code recorded at intake; available on request.
- Packaging: Anti-static foam insert, moisture barrier bag, outer carton with shock indicators.
- Warranty: 12-month functional warranty from ship date; DOA replacement within 30 days.
Procurement Process
- Confirm compatibility: Provide your ACOPOSmulti drive module part number and Automation Studio version — we verify motor–drive pairing before shipment.
- Request quotation: Contact support@konmask.com for volume pricing, lead time, and export documentation (CO, packing list, commercial invoice).
- Order & payment: T/T, PayPal, or trade assurance accepted. Pro-forma invoice issued within 24 hours.
- Shipping: DHL / FedEx express (3–5 days worldwide) or sea freight for bulk orders. Export-controlled items shipped with full EX1/EEI filing.
- After-sales: Technical support via email or WhatsApp (+0086 19859288691) for commissioning assistance.
Technical FAQ
Q: Can this motor be used with a non-B&R drive?
A: The EnDat 2.2 feedback is proprietary to B&R’s ACOPOSmulti ecosystem. Use with third-party drives requires a feedback converter and custom motor data file — not recommended without engineering validation.
Q: Is the holding brake 24 VDC?
A: Yes. The integrated brake is 24 VDC, spring-applied, electrically released, with a holding torque matched to the motor’s rated torque. Brake release is typically handled by the ACOPOSmulti module’s integrated brake output.
Q: What is the encoder resolution?
A: EnDat 2.2 absolute multiturn encoder — 8192 lines/rev singleturn, 4096 turns multiturn (model-dependent; confirm with B&R datasheet 8LSA34 for exact singleturn resolution).
Q: Do you provide the motor cable?
A: Hybrid motor cables (8BCF series) are available separately. Specify cable length and connector type (straight or 90°) when ordering.
Q: Can I get a test report before purchase?
A: Yes. A pre-shipment inspection report with encoder signal screenshots is available for orders above 2 units or upon request for single-unit orders.
