Combustion Monitoring Solution – Fireye 45RM4-1001 | 45RM4 Series Scanner
Where This Product Is Used
The Fireye 45RM4-1001 is a self-checking ultraviolet (UV) flame scanner engineered for continuous flame supervision in demanding industrial combustion environments. It is widely deployed in:
- Industrial boilers — oil- and gas-fired package boilers in power generation and process industries
- Burner management systems (BMS) — as the primary flame-detection sensor in NFPA 85 / EN 746-2 compliant safety loops
- Thermal oxidizers & incinerators — ensuring pilot and main flame presence during waste-gas combustion
- Kilns & dryers — cement, lime, and mineral processing where high-temperature ambient conditions demand robust UV detection
- Fired heaters & process furnaces — refinery and petrochemical applications requiring SIL-rated flame supervision
- Marine & offshore boilers — where compact form factor and vibration tolerance are critical
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 45RM4-1001 |
| Series | 45RM4 |
| Manufacturer | Fireye (UTC Fire & Security) |
| Detection Method | Ultraviolet (UV) self-checking |
| Supply Voltage | 120 VAC / 60 Hz (consult datasheet for variant options) |
| Output Signal | Relay contact (flame relay) + amplifier interface |
| Response Time | ≤ 1 second flame-on / ≤ 3 seconds flame-out (typical) |
| Ambient Temperature | –40 °C to +70 °C operating |
| Enclosure Rating | NEMA 4 / IP65 (scanner head) |
| Weight | 340 g |
| Mounting | 1-inch NPT threaded sight pipe |
| Compatible Amplifiers | Fireye 45RM, 48PT, EP series amplifiers |
Always verify specifications against the official Fireye 45RM4 datasheet before system design.
Why Engineers Specify This Model
- Self-checking UV tube — periodic self-test cycle confirms sensor integrity without manual intervention, meeting IEC 61511 functional safety requirements
- High UV sensitivity — detects hydrogen, natural gas, oil, and propane flames reliably even in high-background-radiation environments
- Compact, rugged housing — stainless-steel scanner head withstands vibration, moisture, and elevated ambient temperatures common in boiler rooms
- Drop-in compatibility — direct replacement for legacy Fireye 45RM series scanners; no amplifier rewiring required in most installations
- Proven field record — 45RM4 platform has decades of installed base across global power and process industries
- Simplified commissioning — plug-and-play interface with Fireye EP266, EP270, and 48PT amplifier cards
Complete System Bill of Materials
A fully functional Fireye UV flame-detection loop typically includes:
- 45RM4-1001 — UV scanner (this item)
- Fireye EP266 / EP270 / 48PT amplifier — signal conditioning and relay output card
- Fireye BurnerLogix / NX series controller — burner management logic unit
- Sight pipe assembly — 1-inch NPT stainless steel, length per installation geometry
- Purge air fitting kit — for high-temperature or sooty applications
- Shielded signal cable — per Fireye wiring specification (typically Belden 8760 or equivalent)
Contact support@konmask.com for complete BOM quotations and compatibility verification.
Compliance & Industry Standards
- NFPA 85 — Boiler and Combustion Systems Hazards Code
- NFPA 86 — Standard for Ovens and Furnaces
- EN 746-2 — Industrial thermoprocessing equipment safety
- IEC 61511 — Functional Safety / SIL assessment support
- UL Listed / FM Approved (verify current approval status on Fireye certificate)
- CE Marking (EU Machinery Directive compliant configurations)
Quality Assurance & Sourcing
Konmask.com sources industrial automation components through verified supply channels with documented traceability:
- Authenticity — parts are inspected against OEM markings, date codes, and packaging standards prior to dispatch
- Condition — new, surplus-new, or factory-refurbished stock clearly indicated per listing; no unmarked refurbished parts
- Documentation — original datasheet, test reports, and certificate of conformance available on request
- Traceability — batch and lot records maintained for B2B procurement audit requirements
- Warranty — 12-month functional warranty against manufacturing defects; RMA process available
How to Source This Part
- Add to cart — click the purchase button above for standard stock orders
- Request a quote — email support@konmask.com with your PO number, required quantity, and delivery timeline for volume pricing
- Urgent requirement — call or WhatsApp +0086 19859288691 for same-day stock confirmation and expedited shipping options
- Cross-reference check — provide your existing scanner part number and we will confirm compatibility before shipment
- Export orders — we support international B2B shipments with commercial invoice, packing list, and HS code documentation
Application-Specific FAQ
Q: Is the 45RM4-1001 compatible with my existing Fireye EP266 amplifier?
A: Yes. The 45RM4 series is designed to interface directly with Fireye EP266, EP270, and 48PT amplifier cards. No hardware modification is required.
Q: Can this scanner detect oil flame as well as gas flame?
A: Yes. The UV detection method responds to the ultraviolet radiation emitted by both oil and gas combustion, making it suitable for dual-fuel burner applications.
Q: What is the maximum sight pipe length recommended?
A: Fireye recommends a maximum sight pipe length of 24 inches (610 mm) for standard installations. Longer runs may require a purge air system to maintain UV signal strength.
Q: Does this unit require periodic calibration?
A: The self-checking circuit performs automatic functional verification. Annual inspection of the UV tube and optical window cleaning is recommended per Fireye maintenance guidelines.
Q: Can Konmask provide a Certificate of Conformance for this part?
A: Yes. CoC documentation is available upon request for B2B and EPC procurement requirements. Contact support@konmask.com.
