Signal Generation Solution – Fluke 2423224 | 0050-06878 | DDS Function Generator Series
The Fluke 2423224 (P/N 0050-06878) is a MHz-range Direct Digital Synthesis (DDS) Function Generator with Arbitrary Waveform (ARB) capability. Cross-reference part numbers: 602199-104, 602705-107, 602200-103, 602199-504. Engineered for precision signal generation in demanding industrial, laboratory, and field-service environments.
Where This Product Is Used
- Electronics Manufacturing & PCB Testing — Inject calibrated sine, square, and triangle waveforms to validate amplifier gain, filter response, and circuit timing on production lines.
- Calibration Laboratories — Serve as a traceable signal reference source for calibrating oscilloscopes, spectrum analyzers, and other measurement instruments.
- Industrial Automation & PLC Commissioning — Simulate sensor output signals (4–20 mA analog equivalents, pulse trains) to verify PLC analog input modules and control loops without live process connections.
- R&D / Prototype Development — Generate arbitrary waveforms to stress-test custom ASICs, power electronics, and communication interfaces during design validation.
- Education & Training Labs — Provide students with a reliable, repeatable signal source for hands-on experiments in electronics and instrumentation courses.
- Field Service & Maintenance — Diagnose signal-path faults in servo drives, VFDs, and industrial sensors by injecting known reference signals on-site.
Technical Specifications
- Model / Part Number: Fluke 2423224 | 0050-06878
- Cross-Reference P/N: 602199-104 · 602705-107 · 602200-103 · 602199-504
- Waveform Technology: Direct Digital Synthesis (DDS)
- Waveform Types: Sine, Square, Triangle, Ramp, Arbitrary (ARB)
- Frequency Range: MHz-range (refer to official Fluke datasheet for exact upper limit)
- Arbitrary Waveform Memory: ARB-capable (user-defined waveform upload)
- Output Impedance: 50 Ω (standard)
- Amplitude Control: Variable, with DC offset adjustment
- Display: Digital readout with parameter indication
- Weight: 2.6 kg
- Manufacturer: Fluke Corporation (USA)
Why Engineers Specify This Model
- DDS Precision: Direct Digital Synthesis ensures frequency stability and low phase noise — critical for accurate circuit characterization.
- ARB Flexibility: Upload custom waveforms to simulate real-world signals (motor back-EMF, sensor noise profiles, communication bursts) without additional hardware.
- Fluke Reliability: Fluke instruments are the global benchmark for measurement accuracy and durability in industrial environments.
- Multi-P/N Compatibility: Covers multiple OEM and replacement part numbers (602199-104, 602705-107, 602200-103, 602199-504), simplifying procurement across different system generations.
- Compact Form Factor: Bench-top design suitable for both lab racks and field-service kits.
Complete System Bill of Materials
For a complete signal generation and verification workstation, engineers typically pair this unit with:
- Digital Storage Oscilloscope (DSO) — to verify output waveform integrity
- Precision BNC coaxial cables (50 Ω) — for low-loss signal routing
- Frequency Counter / Timer — for independent frequency verification
- Bench Power Supply — to power DUT (Device Under Test) during signal injection
- Isolation Transformer — for safe testing on live industrial circuits
- Fluke Calibration Software — for ARB waveform creation and instrument management
Contact support@konmask.com for bundled sourcing of compatible accessories.
Compliance & Industry Standards
- Manufactured by Fluke Corporation — ISO 9001 certified production facilities
- Designed to meet IEC 61010-1 safety requirements for electrical measurement equipment
- CE marked for European market compliance
- RoHS compliant
- Calibration traceable to NIST / national metrology standards
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components and precision test & measurement instruments. Every unit is:
- Sourced from verified supply channels with full traceability
- Inspected for physical integrity and completeness prior to dispatch
- Shipped with appropriate ESD-protective packaging
- Supported by our technical team for pre-sale specification confirmation
We maintain stock of hard-to-find Fluke replacement and OEM parts, including cross-reference P/Ns for legacy system maintenance.
How to Source This Part
- Add to Cart — Click “Add to Cart” above to proceed directly to checkout.
- Request a Quote — For volume orders (>3 units) or project BOM sourcing, email support@konmask.com with your required quantity and delivery timeline.
- Verify Compatibility — Provide your system model or existing P/N and our engineers will confirm fit before you order.
- Expedited Shipping — DHL / FedEx international express available. Lead time confirmed at order placement.
Application-Specific FAQ
Q: Can this unit simulate 4–20 mA sensor signals for PLC analog input testing?
A: The Fluke 2423224 outputs voltage waveforms. For 4–20 mA current loop simulation, a voltage-to-current converter (loop calibrator) should be used in conjunction with this generator.
Q: What software is required to upload ARB waveforms?
A: Fluke provides dedicated waveform editing software compatible with this series. Contact us to confirm the exact software version compatible with P/N 0050-06878.
Q: Is this unit suitable for RF testing above 100 MHz?
A: This is a function/arbitrary waveform generator optimized for lower-frequency signal generation. For RF applications above 100 MHz, a dedicated RF signal generator is recommended. Contact us for alternatives.
Q: Do you provide a calibration certificate with this unit?
A: Calibration certificates can be arranged upon request. Please specify your requirement at the time of order.
Q: Can I cross-reference P/N 602705-107 directly to this unit?
A: Yes. Part numbers 602199-104, 602705-107, 602200-103, and 602199-504 are all cross-references for the Fluke 2423224 / 0050-06878 function generator assembly.
