GE DS200TCEAG1 PC Board | Replacement, Equivalent & Selection Guide
The GE DS200TCEAG1 is a printed circuit board (PC Board) manufactured by General Electric, designed for use in GE Mark V and Mark VI turbine control systems. This board plays a critical role in turbine excitation and control signal processing. Whether you are sourcing an OEM replacement, seeking a compatible equivalent, or evaluating alternatives for your control system, this guide provides the technical detail and selection criteria you need.
Technical Specifications
- Part Number: DS200TCEAG1
- Manufacturer: General Electric (GE)
- Product Type: PC Board / Printed Circuit Board
- Compatible Platform: GE Mark V / Mark VI Turbine Control System
- Function: Turbine Control Excitation & Signal Processing Board
- Weight: 980 g (approx.)
- Condition Available: New, Refurbished, Tested & Repaired
- Warranty: 12-month warranty on all units supplied by Konmask
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or functional equivalents for the DS200TCEAG1. Always verify firmware revision and system compatibility before substitution:
- DS200TCEAG2 — Revised version of the same board; direct form-fit-function replacement in most Mark V applications
- DS200TCEAG3 — Later revision with minor component updates; confirm firmware compatibility
- DS200TCEBG1 — Alternate suffix variant; verify connector pinout before installation
- DS200TCDAG1 — Functionally similar board used in adjacent control slots; consult GE Mark V documentation
- IS200TCEAG1 — Mark VI platform equivalent; not directly interchangeable without system-level reconfiguration
Note: Konmask engineers can assist with cross-reference verification. Contact us before ordering if you are unsure of compatibility.
Why Choose the Original Model
- OEM Specification Compliance: The DS200TCEAG1 meets GE’s original design specifications for Mark V turbine control, ensuring no deviation from validated system behavior.
- Firmware Compatibility: Original boards carry the correct firmware revision pre-loaded, eliminating re-flashing risk.
- Regulatory & Safety Assurance: Critical turbine control environments often require OEM-certified components for compliance with plant safety protocols.
- Reduced Integration Risk: Substituting with non-OEM equivalents may introduce latency, signal mismatch, or communication errors in the control loop.
Typical Applications
- Gas turbine and steam turbine control systems (GE Frame 5, 6, 7, 9 series)
- Combined-cycle power plant automation
- Industrial co-generation facilities
- Offshore and onshore oil & gas turbine-driven compressors
- Petrochemical plant turbine control upgrades and maintenance
System Compatibility
- Primary System: GE Mark V Speedtronic Turbine Control
- Secondary System: GE Mark VI (with configuration adaptation)
- Communication Protocol: ARCNET / Serial (Mark V native)
- Slot/Rack Position: Refer to GE Mark V system drawing for exact slot assignment
- Power Supply Requirement: Supplied by Mark V rack backplane (±15 VDC, +5 VDC)
Selection Guide
Use the following criteria to determine whether the DS200TCEAG1 or an alternative is the right choice for your application:
- Step 1 — Identify your control platform: Confirm whether your system is Mark V or Mark VI. The DS200TCEAG1 is a Mark V board.
- Step 2 — Check the board revision suffix: Suffix letters (A, B, C…) and revision numbers (G1, G2…) indicate hardware revisions. Match as closely as possible to the original installed board.
- Step 3 — Verify firmware version: Request the firmware version from your DCS/control system documentation or existing board label before ordering.
- Step 4 — Assess condition requirements: For critical turbine applications, new or factory-refurbished boards are recommended. Tested & repaired units are suitable for non-critical or backup roles.
- Step 5 — Confirm lead time vs. urgency: New OEM boards may have longer lead times. Konmask maintains stock of refurbished and tested units for rapid dispatch.
Quality Assurance & Sourcing
- All DS200TCEAG1 boards supplied by Konmask are inspected, tested, and documented prior to shipment.
- Refurbished units undergo full functional testing on GE Mark V rack simulators.
- Traceability documentation (test reports, photos, serial numbers) available upon request.
- Sourced from decommissioned power plants, authorized distributors, and OEM surplus channels.
- Export compliance: ECCN classification and export documentation provided for international orders.
How to Order
- Online: Add to cart directly from this page. Specify required condition (New / Refurbished / Tested) in the order notes.
- Email: Send your part number, required quantity, and condition preference to support@konmask.com
- Phone/WhatsApp: +0086 19859288691 — available for urgent inquiries and technical pre-sales consultation.
- Lead Time: In-stock units ship within 1–3 business days. Special orders: 2–4 weeks.
- Payment: T/T (Wire Transfer), PayPal, and major credit cards accepted.
- Shipping: DHL, FedEx, UPS express available worldwide. Sea freight for bulk orders.
Replacement & Compatibility FAQ
Q: Can DS200TCEAG2 directly replace DS200TCEAG1?
A: In most Mark V applications, yes. The G2 revision is a hardware update with the same functional footprint. However, always verify with your GE system documentation or contact Konmask for confirmation.
Q: Is the DS200TCEAG1 compatible with GE Mark VI systems?
A: Not directly. Mark VI uses the IS200 series boards. A system-level reconfiguration would be required, which is generally not recommended.
Q: Do you provide a warranty on refurbished boards?
A: Yes. All Konmask-supplied boards carry a 12-month warranty covering functional defects under normal operating conditions.
Q: Can you repair my existing DS200TCEAG1?
A: Yes. Konmask offers board-level repair services. Contact us with your board’s fault description for a repair assessment and quote.
Q: What documentation do you provide with the board?
A: Test report, inspection photos, serial number record, and packing list. CE/RoHS declarations available on request.
