Gas Turbine Control Solution — GE DS200TCEAG1BTF | Mark V Series
The GE DS200TCEAG1BTF is a critical PC Board within the GE Mark V Turbine Control System, engineered to manage real-time I/O processing, signal conditioning, and inter-board communication in heavy-duty gas turbine and steam turbine applications. Sourced and verified by Konmask.com — your trusted industrial automation parts specialist.
Where This Product Is Used
This board is deployed across a wide range of high-demand industrial environments where turbine reliability is non-negotiable:
- Combined Cycle Power Plants (CCPP) — Real-time turbine sequencing and protection logic
- LNG & Petrochemical Facilities — Compressor drive turbine control in hazardous-area installations
- Steel Mills & Heavy Industry — Captive power generation with continuous process uptime requirements
- Offshore Oil & Gas Platforms — Gas turbine generator sets requiring SIL-rated control integrity
- District Heating & Cogeneration Plants — Steam turbine bypass and load-following control
- Pulp & Paper Mills — Back-pressure turbine control integrated with DCS supervisory systems
Technical Specifications
- Part Number: DS200TCEAG1BTF
- Manufacturer: General Electric (GE Energy / GE Power)
- Series: Mark V Turbine Control System
- Board Type: PC Board (Printed Circuit Board Assembly)
- Function: I/O signal processing, inter-processor communication, analog/digital I/O conditioning
- Compatible Systems: GE Mark V (TMR & Simplex configurations)
- Operating Voltage: Per Mark V backplane specification (typically ±15 VDC, +5 VDC logic rails)
- Operating Temperature: 0°C to +60°C (panel-mounted, forced-air cooled enclosure)
- Weight: 120 g (board only, without mounting hardware)
- Form Factor: VME-compatible card cage format
- Revision: G1BTF (confirm revision compatibility with your Mark V chassis before ordering)
Why Engineers Specify This Model
- TMR Architecture Compatibility — Supports Triple Modular Redundancy for fail-safe turbine protection, meeting IEC 61511 functional safety requirements
- Proven Field Reliability — Deployed in GE Frame 6, Frame 7, and Frame 9 gas turbine fleets globally since the 1990s
- Direct Drop-In Replacement — Maintains backward compatibility with existing Mark V card cage wiring and I/O termination boards
- Reduced Downtime Risk — Stocking a spare eliminates weeks-long OEM lead times during unplanned outages
- Tested & Verified — Each unit sourced by Konmask.com undergoes functional verification before dispatch
Complete System Bill of Materials
The DS200TCEAG1BTF typically operates alongside the following Mark V components. Konmask.com can source the full BOM:
- DS200TCQAG1BHF — Turbine Control I/O Board
- DS200SDCCG1AFB — Speed Detection & Control Card
- DS200EXPSG1ADA — Expansion Power Supply Board
- DS200DMPAG1AEB — Digital Motor Protection Board
- DS200IOCAG1B — I/O Controller Board
- IS200TTURH1CBB — Turbine Trip & Runback Board (Mark VIe compatible)
Contact us with your full panel BOM for a consolidated quote.
Compliance & Industry Standards
- IEC 61511 — Functional Safety for Process Industry Sectors (SIL-capable TMR architecture)
- IEC 61508 — Functional Safety of E/E/PE Safety-Related Systems
- NEMA ICS 2 — Industrial Control Devices, Controllers, and Assemblies
- RoHS Compliance: Verify with revision suffix; G1BTF revision — consult datasheet
- CE Marking: Applicable for EU installations per GE Mark V system certification
Quality Assurance & Sourcing
- ✅ Authentic OEM Parts — Sourced from verified GE-authorized channels and decommissioned OEM-maintained panels
- ✅ Pre-Shipment Functional Test — Visual inspection, board-level continuity check, and where applicable, bench-test against Mark V backplane
- ✅ Anti-Static Packaging — Shipped in ESD-safe bags with foam cushioning and moisture barrier
- ✅ Traceability Documentation — Serial number, revision, and sourcing records available on request
- ✅ Warranty: 90-day replacement warranty against DOA or latent defects
How to Source This Part
- Confirm your Mark V chassis revision — Check the existing board label for the revision suffix (e.g., G1BTF) to ensure compatibility
- Add to cart or request a quote — Use the Buy Now button above, or email support@konmask.com for volume pricing
- Provide your panel BOM — Share your full parts list for a consolidated sourcing quote and lead-time estimate
- Expedited shipping available — DHL Express, FedEx International Priority, and sea freight options for bulk orders
Application-Specific FAQ
Q: Is the DS200TCEAG1BTF compatible with both TMR and Simplex Mark V configurations?
A: Yes. The TCEA board family supports both TMR (Triple Modular Redundancy) and Simplex Mark V architectures. Confirm slot assignment with your Mark V system documentation.
Q: Can this board be used as a direct replacement for DS200TCEAG1AHF or other revision suffixes?
A: Revision compatibility depends on firmware and backplane configuration. Contact our technical team with your existing board revision for a compatibility assessment before ordering.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For out-of-stock items, typical sourcing lead time is 2–4 weeks. Expedited sourcing available for critical outage situations.
Q: Do you provide installation support?
A: Konmask.com provides part-level technical documentation and sourcing support. For on-site commissioning, we recommend engaging a GE-certified controls integrator.
Q: Can I return the board if it doesn’t resolve my fault?
A: Yes, within 30 days of receipt, provided the board is uninstalled and in original condition. See our Returns Policy for full terms.
