GE IC670PBI001 Profibus Bus Interface Unit | Series 90-70

GE IC670PBI001 Profibus Bus Interface Unit – Series 90-70 PLC

When a Profibus network segment loses its bus interface, the consequences cascade fast: field devices go silent, process variables disappear from the controller, and operators are left flying blind. In a continuous manufacturing environment — a paper mill mid-run, a water treatment plant managing dosing cycles, or an automotive body shop coordinating robot cells — even a 15-minute unplanned outage translates directly into scrap, safety incidents, and contractual penalties. The IC670PBI001 is the component that keeps that from happening.

Within GE’s Series 90-70 architecture, the IC670PBI001 occupies a specific and non-substitutable role: it is the dedicated Profibus DP bus interface unit that bridges the Series 90-70 backplane to a Profibus DP field network. Unlike generic communication modules, this unit was engineered alongside the Series 90-70 I/O family, meaning its timing, addressing, and diagnostic behavior are tightly coupled to the GE PACSystems and Series 90-70 CPU firmware. Profibus DP remains one of the most widely deployed fieldbus protocols in European and Asian heavy industry, and the IC670PBI001 continues to serve as a critical spare and replacement component across tens of thousands of installed systems globally.

Technical Specifications

Electrical

• Protocol: Profibus DP (EN 50170 / IEC 61158)
• Baud Rate: Auto-detects 9.6 kbps to 12 Mbps
• Bus Topology: RS-485 differential, linear bus with termination
• Power Supply: Derived from Series 90-70 backplane (5 VDC)
• Max Slaves per Segment: 32 (up to 126 with repeaters)

Mechanical

• Form Factor: Single-slot Series 90-70 I/O module
• Connector: 9-pin D-sub (DB9) female, Profibus standard pinout
• Weight: Approximately 200 g
• Mounting: Series 90-70 baseplate (IC697CHS750, IC697CHS782, compatible variants)

Environmental

• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5% to 95% non-condensing
• Vibration: IEC 68-2-6 compliant

Certifications & Standards

• Profibus DP: EN 50170 / IEC 61158 Type 3
• CE Marking: EMC Directive compliant
• UL Listed (where applicable to original production run)

Note: Specifications are based on GE Automation & Controls published documentation. Always verify against the applicable hardware reference manual (GFK-1504 series) for your firmware revision.

Key Features & Benefits

• Auto Baud Rate Detection (9.6 kbps–12 Mbps) — Eliminates manual DIP-switch configuration during commissioning, reducing setup time by up to 60% compared to fixed-rate alternatives.
• Hot-Swap Compatible with Series 90-70 Backplane — Allows module replacement without full rack power-down in supported configurations, minimizing process interruption during maintenance windows.
• Profibus DP Class 1 Master/Slave Support — Enables both master (controller-side) and slave (I/O-side) topologies within a single module type, providing deployment flexibility across mixed-architecture sites.
• Integrated Diagnostic Reporting via GE Logicmaster/Proficy — Bus faults, slave dropouts, and CRC errors are surfaced directly in the PLC fault table, meeting IEC 61131-3 diagnostic transparency requirements.
• Supports Up to 244 Bytes Input / 244 Bytes Output per Slave — Accommodates high-density I/O slaves such as valve manifolds and multi-axis drive interfaces without segmentation.
• Direct Replacement for Aging Series 90-70 Installations — Drop-in compatible with existing baseplates and wiring; no firmware upgrade required for most Series 90-70 CPU revisions, protecting existing capital investment.

Industry & Equipment Applications

• Automotive Manufacturing — Body-in-white welding lines, paint shop conveyor control, and press transfer systems where Profibus DP coordinates robot controllers and vision systems.
• Pulp & Paper — Stock preparation, headbox control, and dryer section drives where continuous process data from distributed sensors must reach the DCS/PLC without latency.
• Water & Wastewater Treatment — Pump station automation, dosing control, and SCADA-connected remote I/O panels operating under EN 50170 fieldbus standards.
• Oil & Gas Upstream/Midstream — Wellhead control panels and pipeline compressor stations using Series 90-70 PLCs with Profibus-connected pressure transmitters and valve positioners.
• Food & Beverage Processing — Filling lines, CIP (clean-in-place) systems, and packaging machinery where hygienic-area I/O slaves communicate over Profibus DP to a central controller.
• Power Generation & Utilities — Turbine auxiliary systems, switchgear control, and substation automation panels where the Series 90-70 platform remains the installed standard.

System Integration & Compatible Parts

Compatible Upstream (CPUs & Racks):

• GE IC697CPU731, IC697CPU771, IC697CPU781, IC697CPU788 — Series 90-70 CPUs
• GE IC697CHS750, IC697CHS782 — Series 90-70 baseplates (5-slot and 9-slot)
• GE IC697PWR710, IC697PWR724 — Series 90-70 power supplies

Compatible Downstream (Profibus DP Slaves):

• GE VersaMax Profibus Remote I/O (IC200PBI001)
• Siemens ET 200M / ET 200S distributed I/O
• ABB AC500 I/O modules in slave mode
• Pepperl+Fuchs DP/PA segment couplers

Functional Equivalents / Substitution Notes:

• IC670PBI001B — Revised hardware revision; functionally equivalent, verify firmware compatibility with your CPU revision before substitution.
• IC697BEM731 — Profibus DP master module for Series 90-70; different form factor and addressing scheme; not a direct drop-in replacement but serves overlapping use cases in master-only topologies.

Our Quality Assurance Process

1. Visual & Physical Inspection — Each unit is examined for board damage, connector integrity, label legibility, and correct revision markings against GE’s published hardware revision history.
2. Functional Power-On Test — Module is seated in a Series 90-70 test rack and powered; LED status indicators and backplane communication are verified against expected behavior per GFK-1504.
3. Profibus Communication Verification — A live Profibus DP segment with known-good slave devices is used to confirm master/slave handshake, baud rate auto-detection, and cyclic data exchange.
4. Final Documentation & Packaging — Unit is cleaned, anti-static bagged, and boxed with foam protection. Shipment includes test report, photos of actual unit, and available traceability documentation.

Available Documentation: Functional test report · Unit photos (pre-shipment) · Original GE datasheet · Certificate of conformance (on request) · DHL/FedEx tracking with insurance

How to Order

1. Submit Your Inquiry — Use the contact form on this page or email support@konmask.com with your required quantity, delivery timeline, and destination country.
2. Receive Quotation — Our team will respond within 24 hours with pricing, lead time, shipping options, and payment terms. We support T/T, PayPal, and trade assurance arrangements.
3. Confirm & Ship — Upon order confirmation, units are inspected, documented, and dispatched with full tracking. Export documentation (commercial invoice, packing list) is provided for customs clearance.

Why Choose Konmask.com?

• Specialist Inventory — We focus exclusively on industrial automation components: PLCs, DCS modules, drives, and fieldbus hardware from GE, Siemens, ABB, Rockwell, and Schneider.
• Verified Stock, Not Broker Listings — Units listed on Konmask.com are physically in our warehouse or with verified supply partners — not aggregated from unverified third-party brokers.
• Technical Pre-Sales Support — Our team can advise on revision compatibility, substitution feasibility, and integration requirements before you commit to a purchase.
• Export-Ready Documentation — We routinely ship to EU, Southeast Asia, Middle East, and South America with complete export paperwork, reducing customs friction for international buyers.
• Responsive Communication — 24-hour inquiry response, dedicated account handling for repeat buyers, and WhatsApp/WeChat availability for time-sensitive sourcing needs.

Frequently Asked Questions

Q: Is the GE IC670PBI001 compatible with PACSystems RX7i controllers?
A: The IC670PBI001 is a Series 90-70 module and is designed for Series 90-70 baseplates. PACSystems RX7i uses a different backplane architecture (IC698 series). While RX7i racks can accept some Series 90-70 modules in compatibility mode, Profibus interface modules are not among the supported cross-compatible types. For RX7i Profibus connectivity, the IC698PBM001 is the appropriate module. Contact us to confirm your specific configuration before ordering.

Q: What is the difference between IC670PBI001 and IC670PBI001B, and can I use them interchangeably?
A: The “B” suffix denotes a hardware revision update. In most Series 90-70 installations running firmware version 6.0 or later, the two revisions are functionally interchangeable. However, if your system runs an earlier CPU firmware revision, we recommend verifying against GE’s compatibility matrix (GFK-1504 appendix) or contacting our technical team before substituting revisions.

Q: Can the IC670PBI001 be used as a Profibus DP slave to connect a Series 90-70 rack to an upstream Siemens S7 master?
A: Yes. The IC670PBI001 supports both DP master and DP slave operating modes. When configured as a slave, the Series 90-70 rack appears as a standard Profibus DP slave device to any Class 1 master, including Siemens S7-300/400 and S7-1500 with CP 342-5 or CM 1542-5 communication processors. GSD file configuration is required on the master side.

---
