Genuine SIEMENS 6AV6642-0BA01-1AX1 TP 177B PN/DP Touch Panel | SIMATIC HMI Series – Verified Source
The SIEMENS 6AV6642-0BA01-1AX1 TP 177B PN/DP is a cornerstone HMI device in industrial automation, widely deployed across process control, machine tool, and manufacturing execution systems worldwide. Its dual-protocol support (PROFINET and PROFIBUS DP) makes it one of the most versatile and sought-after touch panels in the SIMATIC HMI portfolio — and precisely because of its high demand, it is one of the most frequently counterfeited or misrepresented HMI units on the secondary market. Buyers sourcing from unverified distributors risk receiving refurbished units sold as new, cloned firmware devices, or panels with tampered serial numbers that fail within weeks of deployment.
At Konmask, every unit of the 6AV6642-0BA01-1AX1 passes through our documented 4-step verification process before dispatch. We source exclusively from authorized supply chains and maintain full traceability records for each shipment. Our listings carry genuine, verified, and authentic as operational commitments — not marketing language. Each order is backed by a Certificate of Conformity, and test reports or packing list documentation are available upon request, giving your procurement and quality teams the paper trail they need.
Technical Specifications
- Part Number: 6AV6642-0BA01-1AX1
- Product Family: SIMATIC HMI TP 177B
- Display: 5.7″ STN color display, 256 colors
- Resolution: 320 × 240 px (QVGA)
- Touch Screen: Resistive analog touch, single-touch
- Interfaces: PROFINET (RJ45 × 1), PROFIBUS DP (RS 485 × 1), USB Type A × 1, MPI/DP (RS 422/485)
- Memory: 512 KB user memory (project), 2 MB flash
- Operating System: Windows CE 5.0
- Supply Voltage: 24 V DC (20.4 – 28.8 V)
- Power Consumption: Approx. 6 W
- Protection Rating: IP65 (front panel), IP20 (rear)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: −20 °C to +60 °C
- Dimensions (W × H × D): 196 × 141 × 52 mm
- Weight: Approx. 0.8 kg
- Certifications: CE, UL, cULus, ATEX Zone 2 (with appropriate enclosure)
- Compatible Engineering Software: WinCC flexible 2008 SP3 and above
Specifications verified against SIEMENS official documentation — SIMATIC HMI TP 177B Operating Instructions (A5E00331143-01).
Our 4-Step Quality Verification Process
- Step 1 — Source Authentication: All units are procured from traceable supply chains. Supplier credentials, delivery documentation, and original manufacturer packaging are inspected and logged at intake. Batch-level traceability is maintained for every SKU.
- Step 2 — Physical Inspection & Serial Number Validation: Each panel undergoes visual inspection for label integrity, housing condition, and connector quality. Serial numbers are cross-referenced against SIEMENS product databases to confirm authenticity and rule out refurbished or remarked units.
- Step 3 — Functional Power-On Test: Units are powered at 24 V DC and tested for display initialization, touch calibration response, and communication port activity. Firmware version is confirmed against the factory-issued build for this part number.
- Step 4 — Documentation & Packaging Audit: A Certificate of Conformity (COC) is issued per shipment. Upon request, we can provide: Test Report, Packing List with serial numbers, Country of Origin (COO) Declaration, and product photos of the actual unit prior to dispatch.
Key Features & Benefits
- Dual-Protocol Connectivity: Simultaneous PROFINET and PROFIBUS DP support enables seamless integration into mixed-network architectures without additional gateways — compliant with IEC 61158 fieldbus standards.
- IP65 Front Panel Protection: Rated for wash-down and dust-proof environments per IEC 60529, making it suitable for food processing, pharmaceutical, and heavy industrial enclosures.
- WinCC Flexible Compatibility: Native engineering via SIEMENS WinCC flexible 2008 ensures full access to alarm management, trend displays, recipe handling, and multi-language HMI projects.
- Compact Panel-Mount Form Factor: Standard cutout dimensions allow direct replacement of legacy TP 177 units with no enclosure modification, reducing retrofit downtime.
- USB Host Port: Supports project transfer, data logging to USB storage, and firmware updates without network dependency — critical for air-gapped or secure production environments.
- CE & UL Dual Certification: Meets both European Machinery Directive (2006/42/EC) and North American UL 508 panel safety requirements, simplifying multi-market compliance documentation.
Typical Applications
- Discrete Manufacturing: Machine tool HMI for CNC lathes, milling centers, and press lines requiring real-time parameter visualization and operator input.
- Process Industry: Local operator station for chemical dosing skids, water treatment plants, and HVAC control panels integrated with SIMATIC S7-300/400 PLCs.
- Packaging & Filling Lines: Touch-based recipe selection and batch control on bottling, labeling, and cartoning machines.
- Energy & Utilities: Substation automation HMI for monitoring switchgear status, transformer parameters, and alarm annunciation via PROFIBUS DP.
- Automotive Assembly: Line-side operator terminals for torque tool management, quality checkpoints, and production count tracking.
- Building Automation: BMS integration panels for HVAC zone control, access monitoring, and energy metering in commercial facilities.
Compatible System Components
- SIMATIC S7-300 CPUs (e.g., 6ES7315-2EH14-0AB0, 6ES7317-2EK14-0AB0)
- SIMATIC S7-400 CPUs (e.g., 6ES7412-2XJ05-0AB0)
- SIMATIC ET 200S distributed I/O (PROFIBUS DP)
- SCALANCE X-200 Industrial Ethernet Switches (PROFINET)
- SINAMICS G120 / S120 Drives (via PROFIBUS DP or PROFINET)
- WinCC flexible 2008 SP3+ Engineering Station
- SIMATIC PC Adapter USB A2 (6ES7972-0CB20-0XA0) for MPI/DP programming
- 24 V DC Power Supply (e.g., SITOP PSU100S 6EP1334-2BA20)
Global Sourcing & Shipping Capabilities
- Primary Service Regions: Mainland China, Hong Kong SAR, Southeast Asia (Vietnam, Thailand, Indonesia, Malaysia), Middle East (UAE, Saudi Arabia), Europe (Germany, Poland, Netherlands), and North America (USA, Canada).
- Packaging Standard: Anti-static foam insert, original or equivalent OEM-grade carton, moisture barrier bag where applicable. Each unit is individually boxed with serial number label visible on outer packaging.
- Logistics: DHL Express, FedEx International Priority, and sea freight consolidation available. Export documentation (commercial invoice, packing list, COO declaration) provided for all international shipments.
- Lead Time: In-stock units ship within 1–3 business days. Pre-order or bulk procurement: 7–15 business days depending on quantity and destination.
Certifications & Compliance Statement
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL Listed / cULus — UL 508 Industrial Control Equipment
- RoHS Compliant — Directive 2011/65/EU
- ATEX Zone 2 compatible (with appropriate certified enclosure)
- IP65 (front) per IEC 60529
Konmask Quality Commitment: We do not list products we cannot verify. Every unit sold under the Konmask brand is accompanied by a Certificate of Conformity. If a unit fails to match its documented specifications upon receipt, we provide full replacement or refund — no dispute required. Our quality commitment is not a policy footnote; it is the foundation of every transaction.
How to Order
- Step 1 — Confirm Your Requirement: Add to cart directly, or contact us at support@konmask.com with your part number, required quantity, and destination country. We respond within 24 hours on business days.
- Step 2 — Receive Quotation & Documentation: We issue a formal quotation with unit price, lead time, and available documentation (COC, test report, photos of actual stock). Sample units available for qualified buyers upon request.
- Step 3 — Confirm & Ship: Upon order confirmation and payment, we dispatch with full export documentation. Tracking number provided within 24 hours of shipment.
Authenticity & Trust FAQ
-
Q: How can I verify the unit I receive is genuine SIEMENS?
A: Each unit ships with a Certificate of Conformity referencing the serial number. You can cross-check the serial number via SIEMENS’ product identification tools or request our pre-shipment photos showing the original label and packaging. We also provide the firmware version on request so your engineering team can validate against SIEMENS’ official release history. -
Q: What is your warranty policy?
A: All units carry a 12-month warranty from date of shipment against manufacturing defects and functional failure under normal operating conditions. DOA (Dead on Arrival) units are replaced or refunded within 5 business days of confirmed return. Warranty claims are handled directly by Konmask — no third-party escalation required. -
Q: Can you provide a test report or inspection certificate?
A: Yes. A Certificate of Conformity is issued as standard with every order. Full test reports, pre-shipment inspection photos, packing list with serial numbers, and Country of Origin declarations are available upon request at no additional charge. For large-volume orders, third-party inspection (SGS, BV, or equivalent) can be arranged.
