Process Safety & Shutdown Solution – HIMA 52100 | HIMatrix / HIQuad Series
Where This Product Is Used
The HIMA 52100 Delay Module is deployed in safety-instrumented systems (SIS) across the most demanding industrial environments. Typical application sites include:
- Oil & Gas Upstream/Downstream: Emergency Shutdown (ESD) systems, wellhead control panels, and pipeline protection logic solvers where timed relay outputs prevent spurious trips.
- Petrochemical & Refining: Burner Management Systems (BMS) and high-integrity pressure protection systems (HIPPS) requiring precise time-delay sequencing.
- Power Generation: Turbine protection and boiler safety loops where delayed de-energization prevents mechanical damage during controlled shutdowns.
- Chemical Processing: Reactor interlock systems requiring configurable delay windows to allow safe process stabilization before final shutdown actuation.
- Offshore Platforms: Fire & Gas (F&G) systems integrated with HIMA HIMatrix controllers for zone-based delayed alarm escalation.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 52100 |
| Manufacturer | HIMA Paul Hildebrandt GmbH |
| Module Type | Delay Output Module |
| Compatible Platform | HIMatrix, HIQuad Safety PLC Series |
| Safety Integrity Level | SIL 2 (IEC 61508) |
| Delay Function | Configurable time-delay (on-delay / off-delay) |
| Output Type | Relay / Digital Output (safety-rated) |
| Operating Temperature | 0 °C to +60 °C |
| Weight | Approx. 140 g |
| Certifications | TÜV, IEC 61508, ATEX (consult datasheet) |
| Mounting | DIN rail / backplane slot (HIMatrix rack) |
Why Engineers Specify This Model
- Certified SIL 2 Performance: Independently assessed by TÜV to meet IEC 61508 SIL 2 requirements — no additional proof-test burden for most SIS architectures.
- Native HIMatrix Integration: Plug-and-play compatibility with HIMA’s HIMatrix and HIQuad controllers eliminates custom wiring adapters and reduces commissioning time.
- Configurable Delay Windows: Supports both on-delay and off-delay logic, giving process engineers flexibility to tune trip sequences without hardware changes.
- High Diagnostic Coverage: Internal self-diagnostics continuously monitor output integrity, reducing dangerous undetected failure rates (PFDavg).
- Proven Field Reliability: HIMA modules are specified in over 8,000 safety systems worldwide, with a documented track record in IEC 61511 functional safety lifecycle projects.
Complete System Bill of Materials
For a complete HIMA HIMatrix safety loop, engineers typically pair the 52100 with:
- HIMA HIMatrix F35 or F60 Safety Controller (CPU)
- HIMA Digital Input Module (e.g., 52200 series)
- HIMA Power Supply Module (24 VDC redundant)
- HIMA Communication Module (Profibus / Modbus / HART gateway)
- HIMA Engineering Tool: SILworX configuration software
- Approved field instruments: pressure transmitters, solenoid valves (SIL-rated)
Contact support@konmask.com for a complete BOM quotation tailored to your project.
Compliance & Industry Standards
- IEC 61508: Functional Safety of E/E/PE Safety-related Systems (SIL 2 certified)
- IEC 61511: Functional Safety – Safety Instrumented Systems for the Process Industry
- ATEX / IECEx: Consult HIMA datasheet for zone classification compatibility
- ISO 13849: Safety of Machinery – applicable for hybrid process/machine safety architectures
- TÜV Rheinland Certified: Third-party safety assessment documentation available upon request
Quality Assurance & Sourcing
Konmask.com sources the HIMA 52100 exclusively through verified industrial automation distributors and authorized channel partners. Every unit undergoes:
- Visual and dimensional inspection upon receipt
- Serial number and firmware version verification against HIMA factory records
- Anti-static packaging and climate-controlled storage
- Full traceability documentation provided with each shipment
We do not supply counterfeit, refurbished-as-new, or grey-market components. Certificates of conformity available on request.
How to Source This Part
Ready to order the HIMA 52100 Delay Module? Here’s how to get started:
- Request a Quote: Email support@konmask.com with your project quantity and required delivery date.
- Confirm Compatibility: Share your HIMatrix controller model and SILworX version — our engineers will verify module compatibility at no charge.
- Place Order: Orders accepted via email, phone, or directly through this product page. Lead time typically 3–10 business days depending on stock.
- Shipping: Worldwide DHL / FedEx express shipping with full export documentation. CN customs clearance support available.
📞 +0086 19859288691 | ✉️ support@konmask.com
Application-Specific FAQ
Q: Is the HIMA 52100 suitable for use in SIL 2 ESD systems without additional redundancy?
A: Yes. The 52100 is SIL 2 certified in single-channel (1oo1) architecture for most process applications. For SIL 3 requirements, a 1oo2 or 2oo3 voting configuration is recommended.
Q: Can the delay time be adjusted via SILworX software without hardware replacement?
A: Yes. Delay parameters are configured entirely in software via HIMA’s SILworX engineering tool, allowing on-site tuning during commissioning or HAZOP review updates.
Q: What is the typical proof-test interval for this module?
A: HIMA recommends a proof-test interval of up to 10 years for SIL 2 applications, subject to your site-specific SIL verification calculation (PFDavg analysis).
Q: Do you supply the HIMA 52100 with a certificate of conformity?
A: Yes. A certificate of conformity and, where available, the original HIMA factory test report are included with every shipment from Konmask.com.
Q: Can this module be used in ATEX Zone 2 hazardous areas?
A: The 52100 is typically installed in the safe area control room. For Zone 2 field installations, appropriate ATEX-certified barriers or isolators must be used in conjunction.
