Honeywell 900RTC-BA10 – Analog Output RTP Termination Cable | HC900 Hybrid Controller Platform
Engineering Background: The HC900 Hybrid Controller is Honeywell’s flagship mid-range process control platform, widely deployed in refining, chemical, power generation, and advanced manufacturing. Reliable signal termination between the controller I/O modules and field instrumentation is critical to loop integrity and plant safety. The 900RTC-BA10 is the factory-engineered RTP (Remote Termination Panel) cable designed specifically for HC900 Analog Output modules, eliminating field-wiring errors and reducing commissioning time.
Product Positioning: The 900RTC-BA10 serves as the certified interconnect between HC900 16-channel Analog Output modules and Honeywell RTP termination panels. It is the only cable assembly that guarantees pin-for-pin compatibility, shielding continuity, and full compliance with Honeywell’s HC900 system architecture — making it the preferred choice for EPC contractors, system integrators, and plant maintenance teams worldwide.
Complete Technical Specifications
- Part Number: 900RTC-BA10
- Platform: Honeywell HC900 Hybrid Controller
- Cable Function: Analog Output (AO) RTP Termination Cable
- Compatible Module: HC900 16-Channel Analog Output I/O Module
- Connector Type: High-density D-sub / proprietary HC900 I/O bus connector
- Signal Type: 4–20 mA analog output (current loop)
- Channel Count: 16 channels per cable assembly
- Cable Length: Standard (refer to Honeywell HC900 documentation for length options)
- Shielding: Overall foil shield with drain wire for EMI/RFI immunity
- Weight: 1,850 g (approx.)
- Country of Origin: USA (Honeywell factory-manufactured)
- Compliance: CE, UL listed; meets Honeywell HC900 system specifications
Proven Application Environments
- Petroleum refining and upstream oil & gas process control
- Chemical and petrochemical batch/continuous process plants
- Power generation (boiler, turbine, and BOP control loops)
- Pharmaceutical manufacturing (FDA-regulated process automation)
- Pulp & paper and water/wastewater treatment facilities
- Advanced manufacturing and automotive paint/assembly lines
Engineering Advantages
- Zero field-wiring errors: Factory-terminated, pin-verified cable eliminates manual wiring mistakes during commissioning
- Full shielding continuity: End-to-end foil shield maintains signal integrity in high-noise industrial environments
- Plug-and-play installation: Direct mating with HC900 AO module and RTP panel — no tools or field termination required
- Reduced MTTR: Hot-swap capable with RTP architecture; cable replacement takes minutes, not hours
- OEM-certified: Honeywell factory part — guaranteed compatibility and warranty compliance
- Long service life: Industrial-grade insulation rated for continuous operation in control room and marshalling cabinet environments
System Architecture & Signal Flow
In the HC900 architecture, the 900RTC-BA10 connects the I/O module backplane (mounted in the HC900 controller rack) to the Remote Termination Panel (RTP) located in the marshalling cabinet. Field instrument cables terminate at the RTP, while the 900RTC-BA10 carries all 16 AO channels in a single, shielded assembly to the controller — dramatically reducing cabinet wiring density and improving signal traceability during maintenance.
Signal path: HC900 AO Module → 900RTC-BA10 Cable → RTP Termination Panel → Field Instruments (control valves, positioners, variable-speed drives)
Sourcing & Quality Verification
- All units sourced from authorized Honeywell distribution channels or verified surplus with full traceability
- Pre-shipment inspection: visual, dimensional, and continuity testing on all 16 channels
- Packaging: original Honeywell packaging or equivalent ESD-safe protective packaging
- Counterfeit prevention: part number, label, and connector geometry verified against Honeywell factory standards
- Certificate of conformance available upon request for regulated industries
Procurement Process
- Step 1: Confirm your HC900 AO module part number and RTP panel model to verify cable compatibility
- Step 2: Submit your purchase order or inquiry via Konmask.com or email support@konmask.com
- Step 3: Receive order confirmation with lead time and shipping details within 1 business day
- Step 4: Shipment with tracking; express DHL/FedEx available for urgent plant requirements
- Step 5: Post-delivery technical support available for installation and commissioning questions
Technical FAQ
Q: Is the 900RTC-BA10 compatible with all HC900 Analog Output modules?
A: The 900RTC-BA10 is designed for the HC900 16-channel AO module. Always verify your specific module part number against Honeywell’s HC900 I/O compatibility matrix before ordering.
Q: Can this cable be used with non-Honeywell RTP panels?
A: No. The 900RTC-BA10 uses proprietary Honeywell connectors and is engineered exclusively for HC900 RTP termination panels. Third-party panels are not compatible.
Q: What is the maximum cable run length?
A: Honeywell specifies maximum RTP cable lengths in the HC900 Hardware Installation Guide (document 51-52-25-107). Exceeding specified lengths may degrade signal integrity.
Q: Do you offer expedited shipping for plant shutdowns?
A: Yes. Contact support@konmask.com with your urgency details. We support same-day quotation and next-flight-out logistics for critical plant situations.
Q: Is a Certificate of Conformance available?
A: Yes, available upon request for all units. Please specify your requirement at time of order.
