RF Power Supply Solution – HUTTINGER PFG5000 | PFG Series
The HUTTINGER PFG5000 is a high-performance RF power supplies module engineered for demanding industrial plasma and thin-film deposition processes. Trusted by process engineers worldwide, this unit delivers stable, repeatable RF output critical to semiconductor fabrication, surface treatment, and advanced materials research.
Where This Product Is Used
- Semiconductor & Thin-Film Manufacturing: Drives RF plasma in PVD/CVD sputtering chambers for wafer coating and dielectric deposition.
- Surface Treatment Lines: Powers plasma activation and etching systems for adhesion improvement on metals, plastics, and composites.
- Flat Panel Display (FPD) Production: Supplies stable RF energy for large-area plasma-enhanced deposition processes.
- Research & Development Labs: Used in university and industrial R&D reactors requiring precise, programmable RF power delivery.
- Medical Device Manufacturing: Supports plasma sterilization and surface functionalization of implantable components.
- Photovoltaic (Solar Cell) Production: Integral to PECVD processes for amorphous silicon and passivation layer deposition.
Technical Specifications
- Model: PFG5000
- Brand: HUTTINGER Elektronik (now part of Trumpf Group)
- Series: PFG (Plasma Frequency Generator)
- Output Power: Up to 5,000 W (5 kW)
- Output Frequency: 13.56 MHz (ISM standard)
- Output Impedance: 50 Ω
- Input Voltage: 3-phase AC, 200–480 V (±10%), 50/60 Hz
- Cooling: Forced air / water-cooled options
- Control Interface: Analog (0–10 V), RS-232/RS-485 optional
- Protection: Arc detection, reflected power limiting, over-temperature
- Weight: 1,280 g (module unit)
- Compliance: CE, UL, RoHS
Why Engineers Specify This Model
- Proven PFG Platform: HUTTINGER’s PFG series is the industry benchmark for RF power in plasma processes, with decades of field reliability.
- Arc Management: Integrated arc detection and fast shutdown protect both the power supply and the process chamber.
- Precise Power Control: Forward/reflected power regulation ensures process repeatability batch-to-batch.
- Wide Input Voltage Range: Compatible with global facility power standards without additional transformers.
- Compact Module Form Factor: Rack-mountable design simplifies integration into existing control cabinets.
- Long Service Life: Robust construction with readily available spare parts and global service network.
Complete System Bill of Materials
- HUTTINGER PFG5000 RF Power Supply Module (this unit)
- Matching Network / Auto-Tuner (e.g., HUTTINGER MFG series or equivalent)
- RF Coaxial Cable Assembly (50 Ω, rated ≥5 kW)
- Process Chamber with RF electrode feedthrough
- Cooling water supply or forced-air cooling infrastructure
- PLC / Process Controller (for analog or serial control integration)
- Arc Detection Interface Module (if not integrated)
- Grounding and shielding hardware per RF safety standards
Compliance & Industry Standards
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive
- UL Listed: Recognized for North American industrial use
- RoHS Compliant: Restriction of Hazardous Substances Directive
- ISM Band: 13.56 MHz operation per ITU Radio Regulations
- IEC 61010-1: Safety requirements for electrical equipment for measurement and control
Quality Assurance & Sourcing
All HUTTINGER PFG5000 units offered by Konmask.com are sourced from verified industrial channels including decommissioned OEM lines, certified refurbishers, and authorized surplus distributors. Each unit undergoes:
- Visual and mechanical inspection
- Power-on functional verification
- Output power and frequency calibration check
- Arc detection circuit test
- 90-day warranty on parts and workmanship
How to Source This Part
Ready to order or need a formal quotation? Contact our industrial components team:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Website: https://Konmask.com
- Provide your required quantity, delivery timeline, and any certification requirements.
- OEM purchase orders, wire transfer, and major credit cards accepted.
- Global shipping available — DHL, FedEx, UPS, sea freight for bulk orders.
Application-Specific FAQ
Q: Is the PFG5000 compatible with my existing HUTTINGER matching network?
A: Yes. The PFG5000 uses the standard 50 Ω output interface common across the PFG series and is compatible with HUTTINGER MFG and third-party auto-tuners rated for 5 kW at 13.56 MHz.
Q: Can this unit be controlled via PLC?
A: Yes. The analog control input (0–10 V) allows direct integration with any PLC analog output module. Optional RS-232/RS-485 cards enable digital process control.
Q: What is the lead time for the PFG5000?
A: In-stock units typically ship within 3–5 business days. Contact us for current inventory status and expedited shipping options.
Q: Do you provide calibration certificates?
A: Calibration reports are available upon request. Please specify your requirements at the time of order.
Q: Can the PFG5000 be repaired if it fails?
A: Yes. Konmask.com offers repair and refurbishment services for PFG series units. Contact our technical team for a repair assessment.
