Safety PLC Fiber Optic Solution – ICS Triplex T8314 | Trusted TMR Series
The ICS Triplex T8314 is a Trusted Fiber TX/RX Module engineered for Triple Modular Redundant (TMR) safety instrumented systems. When a refinery control engineer needs to extend a safety loop across a hazardous area boundary without introducing electrical noise or ground loops, the T8314 is the specified solution — converting digital I/O signals to fiber optic transmission with full SIL-rated integrity. It slots directly into the Trusted TMR chassis, maintaining the system’s fault-tolerant architecture while enabling long-distance, EMI-immune communication.
Where This Product Is Used
- Oil & Gas Refineries: Extending ESD (Emergency Shutdown) loops across process units where electrical isolation is mandatory
- Offshore Platforms: Connecting topside safety controllers to subsea or remote wellhead panels via fiber runs
- LNG & Petrochemical Plants: Linking TMR safety controllers to remote I/O racks in classified hazardous areas
- Power Generation: Turbine protection systems requiring high-speed, noise-immune signal transmission between control rooms and turbine halls
- Chemical Processing: Reactor safety interlock systems where galvanic isolation between control and field equipment is required
- Water & Wastewater: Distributed safety systems across large treatment facilities with long cable runs
Technical Specifications
| Part Number | T8314 |
| Manufacturer | ICS Triplex (Rockwell Automation) |
| Series | Trusted TMR Safety System |
| Module Type | Fiber Optic TX/RX (Transmitter/Receiver) |
| Interface | Fiber optic, compatible with Trusted TMR backplane |
| Signal Direction | Bidirectional TX and RX channels |
| Connector Type | ST-type fiber optic connectors |
| Weight | 320 g |
| Form Factor | Single-slot Trusted TMR chassis module |
| Operating Temperature | 0°C to +60°C |
| Power Supply | Supplied via TMR chassis backplane |
| Safety Integrity Level | Suitable for SIL 1, SIL 2, SIL 3 applications (system-level) |
Why Engineers Specify This Model
- EMI Immunity: Fiber optic transmission eliminates susceptibility to electromagnetic interference in heavy industrial environments
- Galvanic Isolation: Complete electrical isolation between transmitting and receiving ends — critical for hazardous area boundaries
- TMR Architecture Preserved: Maintains the Triple Modular Redundant voting logic of the Trusted safety system without compromise
- Long-Distance Reach: Fiber runs extend signal integrity over distances impractical for copper wiring
- Drop-In Replacement: Direct chassis-slot compatibility with existing Trusted TMR installations — no rewiring required
- Proven Field Record: Deployed in SIL 3 safety loops across global oil & gas and power generation facilities
Complete System Bill of Materials
The T8314 operates within the ICS Triplex Trusted TMR ecosystem. Typical companion components include:
- T8110 / T8111 — Trusted TMR Processor Module
- T8120 / T8121 — Trusted Power Supply Module
- T8431 / T8451 — Trusted Digital Input / Output Modules
- T8800 — Trusted Communications Gateway
- T8310 / T8311 — Trusted Fiber Optic Repeater Modules
- Trusted TMR Chassis (6-slot / 12-slot variants)
- ST-type multimode or singlemode fiber optic patch cables
Compliance & Industry Standards
- IEC 61508 — Functional Safety of E/E/PE Safety-Related Systems
- IEC 61511 — Functional Safety for the Process Industry Sector
- ATEX / IECEx — Compatible with installations in classified hazardous areas (zone-dependent; verify with system documentation)
- CE Marking — Compliant with applicable EU directives
- RoHS — Restriction of Hazardous Substances compliant
Quality Assurance & Sourcing
At Konmask.com, every ICS Triplex module undergoes a structured verification process before dispatch:
- Visual Inspection: Housing, connectors, and label integrity checked against OEM reference standards
- Firmware & Revision Verification: Hardware revision confirmed against customer requirements
- Functional Pre-Check: Power-on and communication handshake tested where applicable
- Secure Packaging: ESD-safe anti-static packaging with moisture barrier for international transit
We source from decommissioned plant inventories, certified industrial surplus channels, and authorized distribution networks — providing full traceability documentation on request.
How to Source This Part
- In Stock: Add to cart and proceed to checkout — we ship globally within 3–5 business days
- Quote Required: Contact support@konmask.com for volume pricing, lead time confirmation, or project BOM support
- Urgent Requirement: Call or WhatsApp +0086 19859288691 for expedited sourcing
- Datasheet / Test Report: Available upon request prior to purchase
Application-Specific FAQ
Q: Can the T8314 be used in a SIL 3 safety loop?
A: Yes. The Trusted TMR system architecture supports SIL 3 applications. The T8314 is a qualified module within this architecture — confirm with your functional safety engineer and the system’s Safety Manual.
Q: What fiber type does the T8314 support — multimode or singlemode?
A: The T8314 is designed for multimode fiber optic cable (typically 62.5/125 µm or 50/125 µm). Consult the ICS Triplex T8314 datasheet for maximum transmission distance specifications.
Q: Is the T8314 compatible with the Trusted T8110 processor?
A: Yes. The T8314 is a standard Trusted TMR chassis module and is compatible with the T8110/T8111 processor family within the same chassis.
Q: Do you provide a warranty or return policy?
A: Yes. We offer a 90-day functional warranty on all modules. Contact support@konmask.com for warranty claims or pre-purchase technical questions.
Q: Can you supply multiple units for a plant-wide upgrade project?
A: Yes. We handle project-scale sourcing. Send your BOM to support@konmask.com for a consolidated quote with lead times.
