LENZE MDSKSRS036-13 Servo Motor | Replacement, Equivalent & Selection Guide
The LENZE MDSKSRS036-13 is a high-performance AC servo motor from LENZE’s MDS series, engineered for precision motion control in demanding industrial automation environments. This page provides full technical specifications, compatible replacement models, equivalent alternatives, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Manufacturer: LENZE
- Part Number / SKU: MDSKSRS036-13
- Series: MDS (Modular Drive System)
- Motor Type: AC Synchronous Servo Motor
- Rated Torque: 3.6 Nm (nominal)
- Peak Torque: ~10.8 Nm (3× rated)
- Rated Speed: 3000 RPM
- Encoder: Incremental / Resolver (series-dependent)
- Protection Class: IP65 (shaft seal)
- Insulation Class: F
- Weight: Approx. 4.85 kg
- Mounting: Flange mount (IEC standard)
- Cooling: Self-cooled (IC 410)
- Compatible Drive: LENZE 9300 / EVS series servo inverters
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or near-equivalent replacements for the LENZE MDSKSRS036-13. Always verify electrical and mechanical parameters before substitution:
- LENZE MDSKSRS036-22 – Same frame, higher encoder resolution variant
- LENZE MDSKSRS036-12 – Lower inertia variant, same torque class
- LENZE MCS06C41 – Next-generation MCS series equivalent (3.6 Nm class)
- Siemens 1FK7034-5AK71 – Cross-brand equivalent, 3.4 Nm, 3000 RPM, IEC flange
- Yaskawa SGMJV-04ADE6S – 400 W class equivalent, 3000 RPM, compatible flange
- Mitsubishi HG-KR43 – 400 W, 3000 RPM, similar torque profile
- Beckhoff AM8032 – One Cable Technology variant, comparable torque/speed
Note: Cross-brand replacements require drive parameter reconfiguration and mechanical adapter verification. Contact our engineering team for compatibility confirmation.
Why Choose the Original LENZE MDSKSRS036-13
- ✅ Drop-in compatibility with existing LENZE 9300/EVS servo drive systems — zero reconfiguration
- ✅ Proven reliability in continuous-duty industrial cycles with Class F insulation
- ✅ IP65 shaft seal for operation in dusty or lightly humid environments
- ✅ OEM-matched encoder signal — no feedback tuning required
- ✅ Full LENZE warranty & traceability — critical for regulated industries
- ✅ Consistent dynamic response — ideal for high-cycle positioning applications
Typical Applications
- CNC machine tool axes (milling, turning, grinding)
- Packaging machinery — form-fill-seal, cartoning, labeling
- Printing and converting equipment
- Textile and winding machines
- Robotics and multi-axis gantry systems
- Semiconductor and electronics assembly automation
- Conveyor indexing and pick-and-place systems
System Compatibility
The MDSKSRS036-13 is designed to operate within the LENZE MDS servo system and is fully compatible with:
- LENZE 9300 Servo Inverter Series (EVS9321, EVS9322, EVS9323, etc.)
- LENZE ECS Servo Drive System
- LENZE L-force Controller (with appropriate axis module)
- Standard IEC 60034 servo drive interfaces (with parameter adaptation)
Feedback interface: Resolver or incremental encoder (TTL/HTL) — confirm suffix code for your specific variant.
Selection Guide
Use this guide to confirm the MDSKSRS036-13 is the right choice, or to identify the correct alternative:
- Step 1 – Torque: Confirm rated torque ≥ 3.6 Nm and peak torque ≥ 10 Nm for your load profile
- Step 2 – Speed: Verify max operating speed ≤ 3000 RPM (or select higher-speed variant)
- Step 3 – Drive compatibility: Match to your existing LENZE servo inverter model number
- Step 4 – Encoder type: Confirm resolver vs. incremental encoder from the part suffix (-13 = resolver)
- Step 5 – Mounting: Verify flange size and shaft diameter against your mechanical interface
- Step 6 – Environment: IP65 standard — confirm if higher ingress protection is required
- Step 7 – Replacement scenario: If cross-brand, share your drive model with our team for compatibility check
Quality Assurance & Sourcing
- 🔍 Authenticity verified: All units sourced from authorized distributors or OEM-certified supply chains
- 📦 Pre-shipment inspection: Visual, dimensional, and electrical continuity checks performed
- 📋 Documentation available: Test reports, CE declarations, and country-of-origin certificates on request
- 🏭 Stock origin: New surplus, refurbished (tested), or factory-new — clearly labeled per listing
- 🔒 Anti-counterfeit: Serial number and label verification against LENZE manufacturer records
How to Order
- Confirm part number: LENZE MDSKSRS036-13
- Specify quantity and required delivery timeline
- Request a quote via [email protected] or add to cart directly
- For bulk orders (>5 units) or urgent requirements, contact us for priority sourcing
- Lead time: In-stock items ship within 1–3 business days; sourced items 5–15 business days
Replacement & Compatibility FAQ
Q: Can I replace MDSKSRS036-13 with MDSKSRS036-22?
A: Yes, the -22 suffix indicates a higher-resolution encoder. It is mechanically identical and electrically compatible with the same LENZE drives, but requires encoder parameter update in the drive.
Q: Is the LENZE MCS06C41 a direct drop-in replacement?
A: The MCS series is the successor to MDS. Mechanical dimensions are similar but the feedback interface differs — a drive firmware update and cable adapter may be required.
Q: Can I use a Siemens or Yaskawa motor as a replacement?
A: Cross-brand replacement is possible but requires drive reconfiguration, mechanical adapter, and encoder signal conversion. We recommend consulting our technical team before proceeding.
Q: Do you supply refurbished units?
A: Yes. Refurbished units are clearly marked, fully tested, and come with a 90-day functional warranty. New surplus and factory-new units are also available.
Q: What is the warranty on new units?
A: New units carry the standard LENZE manufacturer warranty (12 months from date of shipment). Extended warranty options available on request.
