Industrial Automation & Embedded Control Solution — Motorola MVME162P-244L | MVME162 Series
Where This Product Is Used
The Motorola MVME162P-244L is a high-performance VMEbus single-board computer deployed across mission-critical industrial and government environments. Typical application scenarios include:
- Industrial Process Automation — Real-time supervisory control in chemical plants, oil & gas refineries, and power generation facilities where deterministic processing is non-negotiable.
- Defense & Aerospace Systems — Embedded computing in radar signal processing, avionics test benches, and military communication platforms requiring MIL-grade reliability.
- Telecommunications Infrastructure — Central processing nodes in legacy SONET/SDH switching equipment and telecom chassis requiring long-lifecycle VME compatibility.
- Scientific Instrumentation — Data acquisition and real-time control in particle accelerators, nuclear research facilities, and laboratory automation systems.
- Transportation & Rail Control — Onboard computing for train control systems, signaling logic, and wayside monitoring equipment.
- Factory Automation & Robotics — Motion control coordination and PLC gateway functions in VME-based manufacturing cells.
Technical Specifications
| Part Number | MVME162P-244L |
| Manufacturer | Motorola (now part of Emerson / CSPI) |
| Series | MVME162 / MVME162P |
| Form Factor | VMEbus 6U Single-Board Computer |
| Processor | Motorola MC68040 / MC68LC040 (32-bit CISC) |
| Bus Standard | VMEbus (IEEE 1014-1987), VME64 compatible |
| Memory | 4 MB DRAM (expandable via mezzanine), Flash/EPROM boot |
| I/O Interfaces | Dual RS-232/RS-422 serial ports, Ethernet (10BASE-T/AUI), SCSI-2 |
| Operating System Support | VxWorks, OS-9, LynxOS, pSOS, bare-metal RTOS |
| Operating Temperature | 0°C to +55°C (commercial grade) |
| Power Consumption | Typical 15–20 W (from VME backplane +5V / ±12V) |
| Weight | 1,360 g |
| Dimensions | 6U VME standard (233.35 mm × 160 mm) |
| Compliance | IEEE 1014, CE, FCC Class A |
Why Engineers Specify This Model
- Proven Long-Term Reliability — The MVME162P series has accumulated decades of field deployment in 24/7 industrial environments, with MTBF figures exceeding 50,000 hours.
- Real-Time Determinism — The MC68040 architecture combined with VMEbus arbitration delivers predictable interrupt latency critical for closed-loop control applications.
- Broad RTOS Ecosystem — Native BSP support for VxWorks and OS-9 means existing software stacks can be migrated without re-engineering.
- VME64 Backward Compatibility — Drop-in replacement capability within existing VME chassis without backplane modification.
- Mezzanine Expandability — IP (Industry Pack) mezzanine slots allow field-addition of analog I/O, CAN bus, MIL-STD-1553, or additional serial interfaces.
- Obsolescence Management — As OEM production has ended, sourcing from a verified distributor like Konmask ensures continued system uptime without costly platform migrations.
Complete System Bill of Materials
For a fully operational MVME162P-244L-based VME system, engineers typically specify the following complementary components:
- VME 6U chassis / cardcage (e.g., Motorola MVME950 or equivalent)
- VME backplane (6U, 3–21 slot, J1/J2)
- VME power supply (±5V, ±12V, minimum 150W)
- MVME162 transition module / P2 adapter for rear I/O
- IP mezzanine modules (IP-Octal, IP-Digital, IP-1553 as required)
- SCSI storage device or CompactFlash adapter
- VxWorks / OS-9 BSP license for MVME162
- RS-232 / RS-422 breakout cables (P2 connector)
Compliance & Industry Standards
- IEEE 1014-1987 — VMEbus electrical and mechanical standard
- VME64 (ANSI/VITA 1-1994) — Extended addressing and data width compatibility
- FCC Part 15 Class A — Radiated emissions compliance for industrial environments
- CE Marking — European EMC Directive conformance
- RoHS — Consult datasheet for specific revision RoHS status
Quality Assurance & Sourcing
All Motorola MVME162P-244L units offered by Konmask.com are subject to the following quality process:
- ✔ Visual inspection for physical damage, corrosion, and component integrity
- ✔ Power-on functional verification under controlled bench conditions
- ✔ Firmware / EPROM version confirmation against known-good baselines
- ✔ Anti-static packaging with humidity indicator cards
- ✔ Traceable sourcing documentation available upon request
- ✔ 30-day DOA warranty with return authorization process
We source from decommissioned industrial systems, certified refurbishers, and authorized surplus channels — never from unverified grey-market brokers.
How to Source This Part
The MVME162P-244L is an end-of-life (EOL) component. Konmask.com maintains stock of tested surplus units to support legacy system maintenance and MRO procurement. To place an order or request a formal quotation:
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Web: https://konmask.com
Lead time: typically 3–7 business days for in-stock units. Expedited shipping available via DHL Express, FedEx International Priority, and UPS Worldwide.
Application-Specific FAQ
Q: Can the MVME162P-244L run VxWorks 6.x or later?
A: The MVME162P is supported up to VxWorks 5.5.x with the official Motorola BSP. Running VxWorks 6.x requires a community-maintained BSP and is not officially supported by Wind River.
Q: Is this board compatible with VME64x (2eSST) backplanes?
A: The MVME162P-244L is a VME32/VME64 device. It will operate correctly in VME64x backplanes in legacy mode but does not support 2eSST transfer protocols.
Q: What is the difference between MVME162P-244L and MVME162P-244?
A: The “-L” suffix typically denotes a low-power or commercial-temperature variant. Verify the specific build option sheet (BOS) for your unit to confirm exact memory and I/O configuration.
Q: Can I use this board as a drop-in replacement for an MVME162-244?
A: In most cases yes — the MVME162P is the enhanced successor to the MVME162. Confirm backplane slot compatibility and P2 connector pinout before installation.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. A CoC and inspection report can be provided upon request for orders requiring traceability documentation.
