NEGELE DPM-GS-2GW-S – Universal Digital Indicator | NEGELE PROZESSORANZEIGE Series
Engineering Background: The DPM-GS-2GW-S is a precision process display module engineered by NEGELE PROZESSORANZEIGE for demanding industrial measurement and monitoring applications. Designed to accept a wide range of analog and sensor inputs, it delivers accurate real-time readout of process variables including temperature, pressure, flow, and level — making it a versatile front-end display solution for control panels and field enclosures.
Product Positioning: Targeted at OEM machine builders, system integrators, and plant engineers who require a reliable, panel-mount digital indicator with multi-input flexibility. The DPM-GS-2GW-S bridges field sensors and operator interfaces without requiring a dedicated PLC or HMI, reducing system cost and complexity in standalone monitoring loops.
Complete Technical Specifications
- Model: DPM-GS-2GW-S
- Brand: NEGELE PROZESSORANZEIGE
- Series: DPM-GS (Universal Process Display)
- Function: Universal Digital Indicator / Process Display Module
- Display Type: Digital LED/LCD process readout
- Input Compatibility: Multi-input (thermocouple, RTD, 4–20 mA, 0–10 V, potentiometer — confirm with datasheet)
- Mounting: Panel-mount (flush-mount cutout)
- Output: Relay / analog retransmission (model-dependent)
- Power Supply: AC/DC universal supply (confirm with datasheet)
- Protection Rating: IP65 front panel (typical for GS series)
- Weight: 1,380 g (packaged)
- Compliance: CE marked; RoHS compliant
- Country of Origin: Germany
Proven Application Environments
- Food & beverage processing — temperature and CIP monitoring
- Pharmaceutical manufacturing — validated process display loops
- Water treatment — level and flow indication panels
- HVAC and building automation — pressure and temperature readout
- Chemical processing — corrosive-environment panel installations
- OEM machine integration — standalone sensor-to-display loops
Engineering Advantages
- Universal Input: Single unit accepts multiple sensor types, reducing spare-part SKU count
- Panel-Mount Design: Standard cutout dimensions simplify enclosure integration
- High Visibility Display: Clear digital readout readable at distance in industrial lighting
- Compact Footprint: Minimizes panel real estate without sacrificing readability
- Robust Construction: IP65 front seal protects against washdown and dust ingress
- Easy Configuration: Front-panel or software parameter setup (model-dependent)
System Architecture & Signal Flow
Field sensor → DPM-GS-2GW-S analog/digital input → internal signal conditioning & scaling → digital display readout → optional relay output or analog retransmission → upstream SCADA / PLC / DCS. The DPM-GS-2GW-S operates as a standalone display node, requiring no host controller for basic indication functions.
Sourcing & Quality Verification
- All units sourced through authorized NEGELE distribution channels
- Each unit inspected for physical integrity and label authenticity prior to dispatch
- Original manufacturer packaging preserved for traceability
- Certificate of conformity and datasheet available upon request
- Batch traceability records maintained for B2B procurement compliance
Procurement Process
- Submit inquiry via support@konmask.com with quantity and delivery requirements
- Receive quotation with lead time and shipping options within 1 business day
- Confirm order — payment via T/T, PayPal, or platform checkout
- Dispatch with tracking number; express and sea freight available
- Post-delivery technical support provided by Konmask engineering team
Technical FAQ
Q: Is the DPM-GS-2GW-S compatible with PT100 RTD sensors?
A: The GS series is designed for multi-input compatibility including RTD types. Confirm the exact input configuration against the NEGELE datasheet for your application.
Q: What panel cutout dimensions are required?
A: Standard DIN panel cutout dimensions apply. Contact us for the exact cutout drawing for the DPM-GS-2GW-S.
Q: Can the unit retransmit the measured value to a PLC?
A: The -2GW-S suffix indicates dual relay or analog output capability. Verify output configuration with the product datasheet or contact our technical team.
Q: What is the typical lead time?
A: In-stock units ship within 3–5 business days. For bulk orders, lead time is confirmed at quotation stage.
Q: Do you provide a warranty?
A: Yes — 12-month warranty against manufacturing defects. RMA process handled directly by Konmask.
