National Instruments PCI-6033E – 64-Channel Multifunction Analog Input DAQ Card | E Series Platform
Engineering Background
The NI PCI-6033E is a high-channel-count multifunction data acquisition card from National Instruments’ proven E Series platform. Designed for demanding measurement applications, it integrates seamlessly into PCI-bus industrial PCs and engineering workstations running NI-DAQ or NI-DAQmx driver frameworks. The E Series architecture has been the backbone of laboratory and industrial data acquisition for over two decades, offering unmatched driver maturity, software ecosystem depth, and field-proven reliability.
Product Positioning
The PCI-6033E targets procurement engineers and system integrators who require high-density analog input with 16-bit resolution in a single PCI slot. It is the preferred choice for multi-sensor monitoring, structural health monitoring, environmental data logging, and automated test equipment (ATE) where channel count and measurement accuracy are both critical constraints.
Complete Technical Specifications
| Part Number / SKU | PCI-6033E |
| Manufacturer | National Instruments (NI) |
| Series / Platform | E Series Multifunction DAQ |
| Form Factor | PCI (32-bit, 5 V) |
| Analog Input Channels | 64 single-ended / 32 differential (software-selectable) |
| ADC Resolution | 16-bit |
| Maximum Sampling Rate | 100 kS/s (aggregate) |
| Input Voltage Range | ±0.05 V to ±10 V (8 software-selectable ranges) |
| Input Impedance | >1 GΩ |
| Analog Output Channels | 2 (16-bit, ±10 V, 1 MS/s) |
| Digital I/O Lines | 8 TTL/CMOS bidirectional |
| Counter/Timers | 2 × 24-bit general-purpose |
| Trigger | Analog & digital hardware triggering; RTSI bus |
| Bus Interface | PCI 2.1 compliant |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -20 °C to 70 °C |
| Dimensions (L × W) | 170 mm × 107 mm (standard PCI half-length) |
| Weight | ~400 g |
| Driver Support | NI-DAQ 6.9+, NI-DAQmx (Windows / Linux RT) |
| Software Compatibility | LabVIEW, LabWindows/CVI, Measurement Studio, MATLAB, Python (nidaqmx) |
| Connector | 68-pin VHDCI (compatible with NI SH68-68-EP shielded cable) |
| Calibration | NIST-traceable; onboard EEPROM calibration constants |
Proven Application Environments
- Automated Test Equipment (ATE): High-channel-count stimulus-response testing for PCB and module validation
- Structural Health Monitoring: Simultaneous multi-point strain gauge, accelerometer, and LVDT acquisition
- Process Control R&D: Real-time closed-loop control with analog output feedback
- Environmental Monitoring: Multi-sensor temperature, pressure, and humidity logging in industrial facilities
- Power Electronics Testing: Waveform capture and harmonic analysis at sub-100 kHz bandwidth
- Academic & Research Labs: Physics, biomedical, and materials science data acquisition platforms
Engineering Advantages
- 64-Channel Density: Maximum sensor coverage in a single PCI slot — eliminates multi-card complexity and reduces system cost
- 16-Bit Resolution: 1-in-65,536 measurement granularity; resolves signals as small as 1.5 µV on the ±0.05 V range
- E Series Driver Maturity: NI-DAQmx driver with 20+ years of field validation; extensive example code library in LabVIEW, Python, and C
- RTSI Bus Synchronization: Hardware-level multi-board synchronization for distributed acquisition systems
- Onboard FIFO Buffer: 512-sample FIFO prevents data loss during host CPU latency spikes
- Dual AO Channels: Integrated analog output enables closed-loop control without additional hardware
System Architecture & Signal Flow
The PCI-6033E employs a multiplexed single-ADC architecture. All 64 single-ended (or 32 differential) channels are routed through a programmable gain instrumentation amplifier (PGIA) before conversion by the 16-bit successive-approximation ADC. Channel scanning order, gain, and coupling are fully software-configurable via NI-DAQmx tasks. The RTSI bus connector enables hardware-triggered synchronization with other NI DAQ, motion, and vision boards in the same chassis. Analog outputs are driven by independent 16-bit DACs with output amplifiers capable of sourcing ±5 mA.
Signal connectivity is via the 68-pin VHDCI front-panel connector, compatible with NI’s full range of terminal blocks (SCB-68A, TB-2715) and shielded cables, enabling noise-immune signal routing in industrial environments.
Sourcing & Quality Verification
- All units sourced through verified industrial automation supply channels
- Pre-shipment functional verification: ADC linearity, channel continuity, and driver enumeration test
- Original NI calibration EEPROM data intact; recalibration available on request
- Packaging: ESD-safe anti-static bag + foam-lined carton; compliant with IEC 61340-5-1
- Traceability documentation available for regulated industries (ISO 9001 environments)
Procurement Process
- Confirm compatibility: Verify your host PC has an available 32-bit PCI slot (not PCIe) and runs a supported OS (Windows 7–11, Linux RT)
- Place order via Konmask.com product page or contact [email protected] for volume pricing
- Lead time: In-stock units ship within 1–3 business days; ETA confirmation provided at order
- Export compliance: ECCN classification available on request for international shipments
- Payment: T/T bank transfer, PayPal, and major credit cards accepted
Technical FAQ
Q: Is the PCI-6033E compatible with PCIe slots?
A: No. The PCI-6033E requires a 32-bit 5 V PCI slot. It is not electrically or mechanically compatible with PCIe. For PCIe platforms, consider the NI PCIe-6321 or PCIe-6341.
Q: What is the maximum per-channel sampling rate?
A: The 100 kS/s aggregate rate is shared across all scanned channels. Scanning 10 channels yields 10 kS/s per channel; scanning 1 channel yields the full 100 kS/s.
Q: Can I use this card with Python?
A: Yes. NI provides the nidaqmx Python package (PyPI) with full E Series support. Compatible with Python 3.6+.
Q: Does the card include a terminal block?
A: The card ships without a terminal block. We recommend the NI SCB-68A or TB-2715 with an SH68-68-EP shielded cable, available separately.
Q: Is recalibration service available?
A: Yes. Contact [email protected] to arrange NIST-traceable recalibration with certificate issuance.
Q: What warranty is provided?
A: 90-day functional warranty against defects in materials and workmanship. Extended warranty available on request.
