NORGREN VAC030-S4-S4 – Pneumatic Valve Drive Board | VAC Series Platform
Engineering Background: NORGREN (IMI Norgren) is a globally recognized leader in motion and fluid control technologies, serving industries from semiconductor manufacturing to heavy process automation. The VAC series represents their precision pneumatic valve control platform, engineered for demanding industrial environments where signal integrity and actuation reliability are non-negotiable.
Product Positioning: The VAC030-S4-S4 is a dedicated drive board (PCB control card) within the NORGREN VAC030 pneumatic valve controller family. It serves as the core signal processing and drive output module, translating control signals into precise valve actuation commands. This unit is critical for OEM machine builders, MRO replacement sourcing, and system integrators requiring a verified, drop-in compatible drive board.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | NORGREN (IMI Norgren) |
| Part Number / SKU | VAC030-S4-S4 |
| Product Type | Drive Board / PCB Control Card |
| Series / Platform | VAC030 Pneumatic Valve Controller Series |
| Function | Valve drive signal processing and output control |
| Input Signal Type | S4 (4-channel solenoid drive, refer to VAC030 datasheet) |
| Output Configuration | S4 (4-output drive stage) |
| Operating Voltage | Per VAC030 series specification (typically 24 VDC) |
| Mounting | PCB card, integrated into VAC030 valve controller housing |
| Weight (approx.) | 300 g |
| Condition Available | New OEM / Tested Surplus / Refurbished |
| Country of Origin | Germany / UK (IMI Norgren manufacturing) |
Proven Application Environments
- Semiconductor & Electronics Manufacturing: Precision pneumatic valve sequencing in wafer handling and SMT assembly lines
- Automotive Assembly: Body-in-white welding fixtures, paint shop pneumatic control panels
- Packaging Machinery: High-speed form-fill-seal machines requiring reliable solenoid drive boards
- Food & Beverage Processing: Hygienic valve control in CIP/SIP systems
- Pharmaceutical Manufacturing: GMP-compliant pneumatic control for isolators and filling lines
- General Industrial Automation: Any application using NORGREN VAC030 series valve controllers
Engineering Advantages
- Drop-in Replacement: Direct form-fit-function replacement for failed or degraded VAC030-S4-S4 drive boards — no rewiring or reconfiguration required
- Dual S4 Architecture: Dual 4-channel configuration provides redundant drive capability and flexible valve bank control
- Signal Integrity: Engineered PCB layout minimizes EMI interference in electrically noisy industrial environments
- Thermal Reliability: Designed for continuous duty cycle operation within VAC030 controller thermal envelope
- OEM-Grade Components: All sourced units verified against NORGREN OEM BOM specifications
System Architecture & Signal Flow
The VAC030-S4-S4 drive board operates within the VAC030 controller as follows:
- Input Stage: Receives digital control signals (PLC output, fieldbus, or discrete I/O) via the VAC030 controller backplane connector
- Signal Processing: Onboard logic decodes valve addressing and command data
- Drive Output Stage: S4 output drivers energize solenoid coils with controlled current profiles to prevent coil burnout
- Feedback Path: Drive board monitors coil continuity and reports fault status back to the VAC030 controller diagnostics
- Protection Circuits: Integrated flyback diode arrays and overcurrent protection safeguard both the board and connected solenoids
Sourcing & Quality Verification
At Konmask.com, every VAC030-S4-S4 drive board undergoes a structured verification process before shipment:
- ✅ Visual Inspection: PCB examined for component damage, solder joint integrity, and connector condition
- ✅ Functional Test: Drive output channels verified under load conditions
- ✅ Part Number Verification: Label and board markings cross-referenced against NORGREN OEM documentation
- ✅ Anti-Static Packaging: Shipped in ESD-safe bags with moisture barrier protection
- ✅ Traceability: Batch records maintained for all units; documentation available on request
Procurement Process
- Submit Inquiry: Email support@konmask.com with your part number (VAC030-S4-S4), required quantity, and delivery timeline
- Quotation: Receive a formal quotation within 24 business hours including unit price, lead time, and shipping options
- Order Confirmation: Confirm PO; payment via T/T, PayPal, or trade terms for qualified accounts
- Quality Check & Dispatch: Unit tested, packed, and dispatched with full shipping documentation
- After-Sales Support: Technical support available post-delivery for installation verification
Technical FAQ
Q: Is the VAC030-S4-S4 compatible with all VAC030 series controllers?
A: The VAC030-S4-S4 is designed for VAC030 controllers with S4-type solenoid valve banks. Confirm your controller’s valve bank configuration before ordering. Contact us if you need compatibility verification.
Q: Can this drive board be used as a direct replacement without reprogramming the PLC?
A: Yes. As a hardware drive board, the VAC030-S4-S4 is a transparent replacement — no PLC program changes are required. Simply swap the board and restore power.
Q: What is the typical lead time for VAC030-S4-S4?
A: In-stock units ship within 3–5 business days. For sourced or refurbished units, lead time is typically 2–4 weeks. Contact us for current stock status.
Q: Do you provide a warranty on this drive board?
A: Yes. All units carry a minimum 90-day functional warranty. Extended warranty options are available for volume orders.
Q: Can you supply other NORGREN VAC series components?
A: Yes. Konmask.com stocks and sources a broad range of NORGREN VAC series controllers, valve manifolds, and spare parts. Submit your full BOM for a consolidated quotation.
