Pfeiffer TC100 PMH 13/3000 (PM C01 692A) Turbopump AF-Controller | Replacement, Equivalent & Selection Guide
The Pfeiffer TC100 PMH 13/3000 (part number PM C01 692A, serial reference 3152290-000) is a dedicated AF-type drive controller manufactured by Pfeiffer Vacuum GmbH (D-35614 Asslar, Germany) for controlling turbomolecular pumps in high-vacuum and ultra-high-vacuum systems. This page provides full technical specifications, compatible replacement models, a structured selection guide, and sourcing information for industrial buyers and OEM engineers.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Pfeiffer Vacuum GmbH (D-35614 Asslar, Germany) |
| Model / Series | TC100 — AF-Controller Series |
| Part Number | PM C01 692A |
| Serial / BOM Reference | 3152290-000 |
| Compatible Pump Series | PMH 13/3000 Turbomolecular Pump |
| Controller Type | AF (Air-Frequency) Drive Controller |
| Pump Speed (nominal) | 3,000 rpm (PMH 13/3000) |
| Communication Interface | RS-485 (DCU / RS-232 optional) |
| Supply Voltage | 100–240 V AC, 50/60 Hz (universal input) |
| Operating Temperature | 5 °C – 40 °C |
| Weight | ~800 g |
| Country of Origin | Germany |
| HS Code | 8543.70.90 |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or functional replacements for the Pfeiffer TC100 PMH 13/3000 controller. Always verify electrical and communication compatibility before substitution.
| Model | Manufacturer | Type | Compatibility Notes |
|---|---|---|---|
| TC110 (PM C01 723) | Pfeiffer Vacuum | AF-Controller (upgraded) | Direct upgrade; same pump family, enhanced diagnostics |
| TC400 (PM C01 925) | Pfeiffer Vacuum | Multi-pump controller | Supports multiple pump types; requires parameter configuration |
| DCU 002 (PM C01 620) | Pfeiffer Vacuum | Display & Control Unit | Add-on display; pairs with TC100/TC110 controllers |
| TurboDrive TD-20 / TD-400 | Leybold | Turbopump controller | Cross-brand equivalent; verify connector pinout |
| STP-iXA3306C Controller | Edwards Vacuum | Turbopump controller | Functional equivalent for similar pump classes |
Note: Konmask.com recommends using OEM Pfeiffer parts wherever possible to ensure warranty compliance and system integrity.
Why Choose the Original Model
- OEM-matched firmware — factory-calibrated for PMH 13/3000 pump parameters, ensuring optimal ramp-up and speed regulation.
- Certified safety compliance — CE-marked, designed to IEC/EN standards for industrial vacuum equipment.
- Seamless integration — plug-and-play with Pfeiffer DCU display units and RS-485 network topologies.
- Long service life — robust design for continuous 24/7 operation in semiconductor, analytical, and research environments.
- Manufacturer support — full Pfeiffer Vacuum service network, spare parts availability, and firmware updates.
Typical Applications
- Semiconductor wafer processing (CVD, PVD, etch chambers)
- Mass spectrometry and residual gas analysis (RGA)
- Electron microscopy (SEM / TEM) vacuum systems
- Thin-film deposition and sputtering systems
- Particle accelerator and synchrotron beamline vacuum
- Industrial leak detection systems
- R&D laboratory high-vacuum setups
System Compatibility
- Pump: Pfeiffer PMH 13/3000 turbomolecular pump (primary); also compatible with select PMH/TMH series pumps — confirm via Pfeiffer compatibility matrix.
- Backing pump: Any dry or oil-sealed rotary vane pump with appropriate inlet pressure (<5 mbar).
- Display unit: Pfeiffer DCU 002 / DCU 003 (PM C01 620 / PM C01 621).
- Remote control: RS-485 bus, compatible with Pfeiffer RVC / PrismaPlus RGA systems.
- Software: Pfeiffer PV.Easy software suite for parameter setting and monitoring.
Selection Guide
Use the criteria below to confirm the TC100 PMH 13/3000 is the correct controller for your application:
| Selection Criterion | TC100 PMH 13/3000 | TC110 (Upgrade) | TC400 (Multi-pump) |
|---|---|---|---|
| Single pump control | ✔ Yes | ✔ Yes | ✔ Yes |
| Multi-pump control | ✗ No | ✗ No | ✔ Yes |
| Enhanced diagnostics | Basic | Advanced | Advanced |
| Legacy system retrofit | ✔ Best fit | ✔ Compatible | Requires config |
| Budget sensitivity | Mid-range | Mid-range | Higher |
Recommendation: If you are replacing a failed TC100 in an existing system, the TC100 (PM C01 692A) is the safest like-for-like replacement. For new installations or system upgrades, consider the TC110 for enhanced monitoring capabilities.
Quality Assurance & Sourcing
- All units sourced by Konmask.com are inspected for physical integrity and functional condition prior to listing.
- Surplus, refurbished, and new-old-stock (NOS) units are clearly labeled with condition status.
- Traceability documentation (serial number, condition report) available upon request.
- Export compliance: units shipped in accordance with applicable export control regulations (EAR/ECCN).
- Packaging: anti-static ESD-safe packaging with foam cushioning for international freight.
How to Order
- Confirm your pump model and existing controller part number (check the controller label or Pfeiffer documentation).
- Add the Pfeiffer TC100 PMH 13/3000 (PM C01 692A) to your cart on Konmask.com.
- For bulk orders (>3 units) or OEM procurement, contact us directly for a custom quote.
- Specify any required documentation (test report, CoC, customs invoice) in the order notes.
- Lead time: in-stock units ship within 1–3 business days; sourced units 5–15 business days.
Replacement & Compatibility FAQ
Q: Can the TC100 (PM C01 692A) directly replace a TC100 with a different sub-part number?
A: Minor sub-variants (e.g., PM C01 692 vs PM C01 692A) may differ in firmware revision. Contact Konmask.com to verify cross-compatibility before ordering.
Q: Is the TC110 a drop-in replacement for the TC100?
A: In most cases yes — the TC110 uses the same connector and communication protocol. However, firmware parameter defaults may differ; reconfiguration via PV.Easy software is recommended.
Q: Can I use this controller with a non-Pfeiffer turbopump?
A: The TC100 is optimized for Pfeiffer pump series. Use with third-party pumps is not officially supported and may void warranties.
Q: What is the warranty on units purchased from Konmask.com?
A: All units carry a 90-day functional warranty. Extended warranty options are available — contact support for details.
Q: Do you provide a test report or certificate of conformance?
A: Yes, available upon request at time of order. Please specify in order notes.
