Genuine PILZ PNOZ X11P Safety Relay Module | PNOZ X Series – Verified Source
The PILZ PNOZ X11P is a certified safety relay module engineered for machine guarding, emergency stop monitoring, and safety gate applications. Sourced through verified supply channels, every unit offered by Konmask.com undergoes a rigorous 4-step quality verification process before dispatch — giving procurement engineers and plant managers the confidence they need when specifying safety-critical components.
Technical Specifications
| Part Number | PNOZ X11P |
| Brand | PILZ |
| Series | PNOZ X |
| Function | Safety Relay Module — E-Stop / Safety Gate Monitoring |
| Supply Voltage | 24 V DC / 24–240 V AC |
| Safety Category | Category 4 / PLe (EN ISO 13849-1) |
| Safety Integrity Level | SIL 3 (IEC 62061) |
| Enable Circuits | 3 N/O safety outputs + 1 N/C auxiliary output |
| Input Channels | Dual-channel (1- or 2-channel operation selectable) |
| Response Time | ≤ 20 ms |
| Operating Temperature | 0 °C to +55 °C |
| Mounting | DIN rail (35 mm) |
| Housing Width | 45 mm |
| Weight | 268 g |
| Protection Class | IP40 (front panel) |
| Certifications | CE, TÜV, UL, cUL |
Our 4-Step Quality Verification Process
Every PILZ PNOZ X11P unit sold through Konmask.com passes the following verification protocol before it is offered for sale or shipped to a customer:
Step 1 — Source Traceability Check
We verify the supply chain origin of each batch. Units are sourced exclusively from authorised distributors, certified resellers, or factory-direct channels. Batch documentation and delivery records are retained on file.
Step 2 — Physical Authenticity Inspection
Our technical team inspects each unit for correct PILZ labelling, holographic seals, housing mould consistency, terminal markings, and PCB visible features where applicable. Counterfeit indicators trigger immediate rejection.
Step 3 — Functional Bench Test
Where feasible, units undergo a power-on functional test verifying input response, output switching, and LED status indication against PILZ published specifications. Test records are available upon request.
Step 4 — Packaging & Documentation Audit
Original PILZ packaging, datasheet inserts, and CE declaration of conformity documents are confirmed present and intact before final dispatch.
Key Features & Benefits
- Achieves the highest safety performance level — Category 4 / PLe / SIL 3 — for demanding machine safety applications
- Wide supply voltage range (24 V DC / 24–240 V AC) simplifies integration across global plant voltages
- Selectable 1- or 2-channel input configuration provides application flexibility without additional hardware
- Compact 45 mm DIN-rail housing minimises control cabinet footprint
- Instantaneous and time-delayed output variants available within the PNOZ X11P family
- Proven PILZ PNOZ X platform — globally recognised, extensively documented, and widely stocked for fast replacement
- LED diagnostics for rapid fault identification during commissioning and maintenance
Typical Applications
- Emergency Stop (E-Stop) Monitoring — Category 4 dual-channel E-stop circuits on presses, robots, and conveyors
- Safety Gate & Interlocking — Guard door position monitoring on CNC machining centres and automated assembly lines
- Light Curtain & Safety Mat Integration — OSSD output monitoring for perimeter guarding systems
- Two-Hand Control — Synchronous actuation monitoring for operator protection on stamping and forming equipment
- Enabling Device Monitoring — Teach pendant and enabling switch circuits on industrial robots
- Valve & Actuator Safety Circuits — Safe de-energisation of pneumatic and hydraulic actuators in process plant
Compatible System Components
- Safety Controllers: PILZ PNOZmulti 2 (MIRO series), PSS 4000 safety PLC
- E-Stop Devices: PILZ PITstop, Schmersal AZ 16, Euchner NZ series
- Safety Gate Switches: PILZ PSENmech, Sick i10-E, Omron D4SL
- Light Curtains: PILZ PSENopt, Keyence SL-V, Banner EZ-SCREEN
- Safety Contactors: Siemens 3RT2, Schneider LC1D (safety-rated), ABB AF series
- DIN Rail & Enclosures: Phoenix Contact, Rittal, Weidmüller terminal blocks and rail systems
Global Sourcing & Shipping Capabilities
Konmask.com maintains inventory and sourcing relationships to support urgent and planned procurement requirements worldwide:
- Stock Availability: Enquire for current on-hand quantity; expedited sourcing available for out-of-stock requests
- Lead Time: In-stock orders typically dispatched within 1–3 business days; sourced orders 5–15 business days depending on origin
- Shipping Destinations: Worldwide — including EU, North America, Southeast Asia, Middle East, and Australia
- Export Documentation: Commercial invoice, packing list, certificate of origin, and PILZ datasheet provided as standard
- Customs & HS Code: HS 8536.49 (relay, safety function) — export classification support available on request
- Minimum Order Quantity: 1 unit — no minimum order requirement
Certifications & Compliance Statement
The PILZ PNOZ X11P is designed and certified to the following international standards:
- EN ISO 13849-1:2015 — Safety of Machinery: Safety-Related Parts of Control Systems (Category 4 / PLe)
- IEC 62061:2021 — Safety of Machinery: Functional Safety (SIL 3)
- IEC 61508 — Functional Safety of E/E/PE Safety-Related Systems
- EN 60947-5-1 — Low-Voltage Switchgear: Control Circuit Devices
- CE Marking — EU Machinery Directive 2006/42/EC compliant
- UL / cUL Listed — North American market compliance
- TÜV Certified — Independent third-party safety assessment
Konmask.com does not modify, repair, or alter any PILZ product. All units are supplied in original manufacturer condition. Customers are responsible for ensuring correct application and installation in accordance with PILZ documentation and local regulatory requirements.
How to Order
- Confirm Part Number: Verify PNOZ X11P against your BOM or existing installation documentation
- Request a Quote: Contact us via email or phone with your required quantity and delivery timeline
- Receive Proforma Invoice: We issue a proforma invoice with unit price, shipping cost, and lead time confirmation
- Payment & Dispatch: Upon payment confirmation, your order is picked, verified, and dispatched with full documentation
- Track & Receive: Tracking number provided upon shipment; delivery confirmation and after-sales support available
Authenticity & Trust FAQ
Q: How do I know the PNOZ X11P I receive is genuine PILZ?
A: Every unit passes our 4-step verification process (detailed above). We retain source documentation and can provide batch records upon request. If you have any authenticity concern upon receipt, contact us immediately — we will investigate and resolve at no cost to you.
Q: Do you supply original packaging and documentation?
A: Yes. All units are supplied in original PILZ packaging with datasheet and CE declaration of conformity where available from the source batch.
Q: Can I request a test report or inspection certificate?
A: Functional test records are available for units that have undergone bench testing. Third-party inspection (SGS, Bureau Veritas) can be arranged for large orders at buyer’s cost.
Q: What is your return policy if the unit is faulty?
A: We offer a 12-month warranty against manufacturing defects and sourcing errors. Faulty units are replaced or refunded — contact support@konmask.com with your order reference and fault description.
Q: Are you an authorised PILZ distributor?
A: Konmask.com operates as an independent stocking distributor. We source from authorised channels and apply our own quality verification process. For OEM warranty and direct factory support, we recommend contacting PILZ directly. Our value is speed, availability, and verified quality for MRO and project procurement.
Q: Can you supply multiple units for a project?
A: Yes. We handle single-unit MRO replacements and multi-unit project orders. Volume pricing is available — contact us for a project quotation.
