HMI Display Repair Solution — Proface AGP3550-DISP D05044A | AGP3550 Series
Where This Product Is Used
The Proface AGP3550-DISP D05044A circuit board is the core display driver assembly for the Proface AGP3550 series HMI (Human-Machine Interface) panels. It is deployed across a wide range of industrial environments where reliable operator interface is mission-critical:
- Automotive manufacturing lines — press control stations, robotic welding cells, and conveyor management panels
- Food & beverage processing — SCADA-connected HMI terminals for batch control and CIP monitoring
- Pharmaceutical production — GMP-compliant operator panels in cleanroom environments
- Water treatment & utilities — remote pump station HMIs and SCADA visualization terminals
- Plastics & injection molding — machine parameter display and alarm management interfaces
- Semiconductor fab equipment — process recipe display and interlock status panels
- Oil & gas field instrumentation — wellhead control panel HMI displays
When the AGP3550 display fails — showing white screens, backlight failure, pixel dropout, or touch misalignment — this D05044A board is the OEM-equivalent replacement that restores full panel functionality without replacing the entire HMI unit.
Technical Specifications
| Manufacturer | Proface (Digital Electronics Corporation / Schneider Electric) |
| Part Number | AGP3550-DISP D05044A |
| Compatible HMI Model | AGP3550 Series (AGP3550-T1-D24, AGP3550-T1-AF, and variants) |
| Board Function | Display driver / LCD interface circuit board |
| Display Type Supported | TFT LCD color display panel |
| Interface | Internal ribbon/FPC connector to main CPU board |
| Operating Voltage | Per AGP3550 panel spec (24 VDC system) |
| Operating Temperature | 0°C to +50°C (storage: -20°C to +60°C) |
| Form Factor | OEM replacement PCB assembly |
| Weight | 100 g (approx.) |
| SKU | AGP3550-DISP D05044A |
Why Engineers Specify This Model
- Exact OEM form factor — drop-in replacement with no mechanical modification required; all connector positions match the original AGP3550 chassis
- Cost-effective repair path — replacing this board costs a fraction of a full HMI panel replacement, preserving existing wiring, mounting, and programming
- Eliminates display-specific faults — directly addresses white screen, backlight failure, color distortion, and display freeze without touching the CPU or I/O modules
- Minimizes downtime — board-level swap can be completed in under 30 minutes by a qualified technician, versus days for full panel procurement and reconfiguration
- Preserves existing PLC/SCADA integration — no re-programming of GP-Pro EX projects or communication settings required after replacement
- Sourced from verified supply chain — Konmask stocks boards from traceable industrial surplus and authorized distribution channels
Complete System Bill of Materials
For a complete AGP3550 HMI repair or spare-parts kit, engineers typically source the following alongside the D05044A display board:
- Proface AGP3550 main CPU/logic board
- AGP3550 TFT LCD panel (if backlight or pixel damage is present)
- AGP3550 touch screen digitizer / overlay
- AGP3550 power supply board
- FPC/ribbon cable set (display-to-CPU interface)
- AGP3550 front bezel and gasket seal kit
- 24 VDC DIN rail power supply (Meanwell or equivalent)
- GP-Pro EX programming software license (for project backup/restore)
Contact support@konmask.com to request a bundled BOM quote.
Compliance & Industry Standards
- RoHS Compliant — meets EU Directive 2011/65/EU on restriction of hazardous substances
- CE Marking — original Proface AGP3550 series carries CE certification for industrial machinery directive compliance
- UL Listed — AGP3550 platform is UL-recognized for use in industrial control panels per UL 508A
- IP65 Front Panel — the AGP3550 enclosure (when board is correctly installed) maintains IP65 ingress protection rating
- IEC 61131 — compatible HMI platform supports IEC 61131-compliant PLC communication protocols
Quality Assurance & Sourcing
At Konmask, every replacement board undergoes a structured inspection process before dispatch:
- Visual inspection — PCB surface, solder joints, connector pins, and component seating checked under magnification
- Functional bench test — where test fixtures are available, boards are powered and display output verified prior to shipment
- Anti-static packaging — shipped in ESD-safe bags with foam cushioning inside double-wall cartons
- Traceability — each unit is logged with source batch, inspection date, and technician ID
- Warranty — 90-day replacement warranty against defects in materials and workmanship
How to Source This Part
- Confirm compatibility — verify your AGP3550 panel model number and existing board revision against the D05044A part number
- Request a quote — email support@konmask.com with your panel serial number and required quantity
- Place order — add to cart directly or request a proforma invoice for B2B/PO-based procurement
- Receive & install — board ships with basic installation reference; full service manual available on request
- Verify operation — power up panel and confirm display output before closing the enclosure
For urgent breakdown situations, contact us directly at +0086 19859288691 for expedited sourcing assistance.
Application-Specific FAQ
Q: Will this board work with all AGP3550 variants?
A: The D05044A is designed for the AGP3550 display assembly. Confirm your panel’s internal board revision label matches before ordering. Contact us if you are unsure.
Q: Do I need to re-flash or reconfigure anything after replacing this board?
A: No. The D05044A is a display driver board only — it does not store project data or communication settings. Your GP-Pro EX project and PLC connections remain intact on the CPU board.
Q: My AGP3550 shows a white screen — is this board the cause?
A: White screen on AGP3550 is commonly caused by a failed display board or backlight inverter. The D05044A replacement resolves the majority of white-screen faults. If the issue persists after replacement, the LCD panel itself may also require replacement.
Q: Can Konmask supply multiple units for a planned maintenance stock?
A: Yes. We support bulk and blanket orders for MRO stocking programs. Request a volume quote via email.
Q: What is the lead time?
A: In-stock units ship within 1–3 business days. For out-of-stock items, typical lead time is 7–21 business days depending on sourcing. Contact us for real-time availability.
