Industrial AC Control Solution – Schneider Electric 140DAI74000 | Modicon Quantum Series
Where This Product Is Used
The Schneider Electric 140DAI74000 is a 32-channel AC discrete input module engineered for demanding industrial automation environments. It is widely deployed in the following sectors and applications:
- Oil & Gas Processing Plants – Field device status monitoring (valve open/close, pump run/stop) in hazardous-area control panels.
- Power Generation & Utilities – Substation automation and switchgear status acquisition via 120 VAC field signals.
- Water & Wastewater Treatment – Pump station I/O expansion for SCADA-integrated Quantum PLC racks.
- Automotive & Heavy Manufacturing – Conveyor line limit-switch and safety-interlock signal collection on high-density production floors.
- Chemical & Pharmaceutical Plants – Process interlocking and equipment-status feedback in IEC 61511-compliant safety loops.
- Building Management Systems (BMS) – HVAC equipment status and alarm input aggregation in large commercial facilities.
- Mining & Minerals Processing – Crusher, conveyor, and hoisting equipment status monitoring in remote rack installations.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 140DAI74000 |
| Manufacturer | Schneider Electric (Modicon) |
| Series | Modicon Quantum |
| Module Type | Discrete AC Input |
| Number of Channels | 32 (2 × 16-channel groups) |
| Nominal Input Voltage | 120 VAC |
| Input Voltage Range | 74–132 VAC |
| Input Frequency | 47–63 Hz |
| ON-State Voltage Threshold | ≥ 74 VAC |
| OFF-State Voltage Threshold | ≤ 20 VAC |
| Input Current per Channel | Approx. 10 mA @ 120 VAC |
| Isolation | Optical isolation, group-to-backplane |
| Response Time (ON) | ≤ 10 ms |
| Response Time (OFF) | ≤ 10 ms |
| Backplane Current Consumption | 800 mA @ 5 VDC |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Module Weight | 910 g |
| Mounting | Modicon Quantum backplane slot |
| Wiring Connector | 40-pin removable terminal block (field-side) |
Why Engineers Specify This Model
- High Channel Density – 32 AC inputs in a single Quantum slot reduces rack space and wiring cost versus dual 16-channel alternatives.
- Robust Optical Isolation – Group isolation protects the backplane and CPU from field-side transients and ground loops common in AC environments.
- Wide Voltage Window – 74–132 VAC tolerance accommodates real-world line fluctuations without nuisance faults.
- Removable Terminal Block – Field wiring stays in place during module swap, minimising maintenance downtime.
- Proven Quantum Ecosystem – Direct compatibility with 140CPU, 140CRP, and 140NOE network modules; no gateway or adapter required.
- Long Product Lifecycle – Schneider Electric maintains extended support for Quantum hardware, protecting capital investment in existing rack infrastructure.
- Diagnostics via Unity Pro / EcoStruxure Control Expert – Per-channel status bits and module health flags are natively readable in the PLC program.
Complete System Bill of Materials
A typical Modicon Quantum rack assembly incorporating the 140DAI74000 includes:
- 140DAI74000 – 32-ch AC Discrete Input Module (this item)
- 140CPU65160 or 140CPU67160 – Quantum CPU module
- 140XBP01600 – 16-slot Quantum backplane
- 140CPS11420 – 115/230 VAC power supply module
- 140NOE77101 – Ethernet TCP/IP network option module
- 140DAO84000 – 32-ch AC Discrete Output Module (paired output)
- TSXCAP0 Series – Removable terminal block connectors (field wiring)
- 140XTS00200 – Quantum rack grounding kit
Contact support@konmask.com for complete rack configuration quotations.
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive & EMC Directive
- UL Listed – UL 508 (Industrial Control Equipment)
- CSA Certified – C22.2 No. 142
- IEC 61131-2 – Programmable Controllers, Equipment Requirements
- IEC 61000-4 Series – EMC Immunity (ESD, EFT, Surge, Conducted RF)
- RoHS Compliant – Restriction of Hazardous Substances
- ATEX / IECEx – Suitable for use in Zone 2 installations when mounted in certified enclosures
Quality Assurance & Sourcing
Konmask.com sources the 140DAI74000 exclusively through authorised distribution channels and verified industrial surplus networks. Every unit offered undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware / revision-level verification against Schneider Electric published release notes
- Functional power-on test where test equipment is available
- Anti-static packaging with humidity indicator card
- Traceable documentation retained on file for audit purposes
New-in-box (NIB), refurbished, and tested-used grades are available. Grade is clearly stated at time of quotation.
How to Source This Part
- Add to Cart – Place your order directly on this page for in-stock units.
- Request a Quote – Email support@konmask.com for volume pricing, lead-time confirmation, or alternative grades.
- Phone / WhatsApp – Call or message +0086 19859288691 for urgent requirements.
- Datasheet & Documentation – Request the official Schneider Electric 140DAI74000 instruction bulletin via email; we will supply it with your order confirmation.
- Export & Cross-Border Orders – We ship globally. Provide your destination country for freight options and HS code 8537.10 customs documentation.
Application-Specific FAQ
Q: Can the 140DAI74000 accept 240 VAC field signals?
A: No. The module is rated for 120 VAC nominal (74–132 VAC range). For 240 VAC applications, use the 140DAI75300 (32-ch, 230 VAC input) instead.
Q: Is this module compatible with the Modicon M340 or M580 platform?
A: No. The 140DAI74000 is exclusively for the Modicon Quantum backplane. M340 uses BMX-series I/O; M580 uses BMEX-series I/O.
Q: How many 140DAI74000 modules can be installed in one Quantum rack?
A: Up to 15 I/O modules per 16-slot rack (one slot reserved for the CPU or power supply), subject to backplane current budget. Verify total 5 VDC draw against your 140CPS power supply rating.
Q: What software is required to configure this module?
A: EcoStruxure Control Expert (formerly Unity Pro) v13.1 or later is recommended. The module is auto-detected by the Quantum hardware catalog; no additional driver installation is required.
Q: Do you supply the removable terminal block connector?
A: The 40-pin terminal block is included with new-in-box units. For refurbished or used-tested units, please confirm connector inclusion at time of order. Spare connectors are available separately.
Q: What is the typical lead time for out-of-stock units?
A: Lead times vary by market conditions. Contact us for a real-time availability check. We maintain relationships with multiple authorised and surplus distributors to minimise lead time.
