SIEMENS 6AV2128-3MB06-0AX1 Comfort Panel 15″ Touch HMI | Replacement, Equivalent & Selection Guide
The SIEMENS 6AV2128-3MB06-0AX1 is a 15.4″ widescreen Comfort Panel HMI from the SIMATIC HMI Comfort series, engineered for demanding industrial automation environments. Fully integrated with TIA Portal V13 SP1 and above, it delivers high-resolution visualization, multi-touch capability, and robust connectivity for complex machine and process control applications.
At Konmask.com, we specialize in sourcing genuine SIEMENS automation components and verified compatible alternatives — helping engineers make confident selection and replacement decisions.
Technical Specifications
- Part Number: 6AV2128-3MB06-0AX1
- Series: SIMATIC HMI Comfort Panel
- Display Size: 15.4″ Widescreen TFT
- Resolution: 1280 × 800 px (WXGA)
- Touch Type: Resistive multi-touch
- Processor: 1 GHz ARM Cortex-A8
- RAM: 256 MB
- Flash Memory: 24 MB (user memory)
- Operating System: Windows CE 6.0
- Interfaces: 2× USB 2.0, 2× PROFINET (RJ45), 1× MPI/PROFIBUS DP, 1× RS-422/485, 1× SD card slot, 1× Audio
- Supply Voltage: 24 V DC (19.2–28.8 V)
- Power Consumption: Approx. 30 W
- Protection Rating: IP65 (front panel), IP20 (rear)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: −20 °C to +60 °C
- Dimensions (W×H×D): 419 × 287 × 54 mm
- Weight: Approx. 3.5 kg
- Certifications: CE, UL, cULus, ATEX Zone 2
- Engineering Software: WinCC (TIA Portal) V13 SP1+
Compatible Replacement & Equivalent Models
If the 6AV2128-3MB06-0AX1 is unavailable or you are evaluating alternatives, the following models offer compatible or equivalent functionality:
- 6AV2128-3MB06-0AX0 — Previous firmware revision; same hardware, earlier software baseline. Direct drop-in replacement in most installations.
- 6AV2124-0MC01-0AX0 (TP1200 Comfort) — 12″ variant; reduced display area but identical communication interfaces and TIA Portal integration.
- 6AV2124-0QC02-0AX1 (TP1200 Comfort PRO) — Enhanced version with extended temperature range and PROFINET IRT support.
- 6AV2128-3QB06-0AX0 (TP1500 Comfort PRO) — 15″ PRO variant; adds extended temperature, conformal coating option, and PROFINET IRT.
- Weintek MT8150XE — Third-party 15″ multi-touch HMI; supports SIEMENS S7-300/400/1200/1500 via Ethernet. Cost-effective alternative for non-safety-critical applications.
- Kinco MT4620TE — 15″ TFT HMI with PROFIBUS DP and Ethernet; compatible with SIEMENS PLCs via standard drivers.
Note: Always verify firmware version, communication protocol, and project compatibility before substitution. Contact Konmask technical support for validation assistance.
Why Choose the Original Model
- Native TIA Portal Integration: Seamless project engineering with WinCC, no third-party driver required.
- PROFINET & PROFIBUS Dual Connectivity: Supports both modern and legacy SIEMENS network architectures simultaneously.
- IP65 Front Protection: Suitable for wash-down and dusty industrial environments.
- Proven Reliability: Widely deployed in automotive, food & beverage, and process industries globally.
- Long-term Availability: SIEMENS Comfort Panel series has an extended product lifecycle with guaranteed spare parts support.
- Scalable Visualization: Supports up to 2,048 process tags, 50 alarms, and complex faceplates.
Typical Applications
- Machine tool control and CNC visualization
- Automotive assembly line HMI stations
- Food & beverage processing and packaging lines
- Water treatment and utilities SCADA front-ends
- Pharmaceutical batch process monitoring
- Building automation and energy management systems
- Oil & gas upstream/downstream control panels
System Compatibility
- SIMATIC S7-1500 (recommended pairing via PROFINET)
- SIMATIC S7-1200 (Ethernet/PROFINET)
- SIMATIC S7-300 / S7-400 (MPI, PROFIBUS DP, or Ethernet)
- SIMATIC ET 200SP / ET 200MP (distributed I/O visualization)
- WinCC Runtime Advanced / Professional (PC-based SCADA integration)
- Third-party PLCs via OPC UA, Modbus TCP, or EtherNet/IP (with appropriate drivers)
Selection Guide
Use the table below to select the right Comfort Panel for your application:
- Display size needed ≤ 12″: → TP1200 Comfort (6AV2124-0MC01-0AX0)
- Display size needed = 15″, standard environment: → 6AV2128-3MB06-0AX1 ✓ (this model)
- Display size needed = 15″, extended temp / harsh environment: → TP1500 Comfort PRO (6AV2128-3QB06-0AX0)
- Display size needed ≥ 19″: → TP1900 Comfort (6AV2124-0UC02-0AX0)
- Budget-sensitive, non-SIEMENS PLC: → Weintek MT8150XE or Kinco MT4620TE
- Requires ATEX Zone 1 certification: → Consult SIEMENS Ex-rated panel solutions
Quality Assurance & Sourcing
- Genuine Parts: All SIEMENS products sourced through authorized distribution channels with full traceability.
- Inspection: Each unit undergoes visual inspection and functional verification prior to shipment.
- Warranty: 12-month warranty against manufacturing defects.
- Documentation: CE declaration, datasheet, and test report available upon request.
- Anti-counterfeit: Holographic SIEMENS labels and serial number verification provided.
How to Order
- Part Number: 6AV2128-3MB06-0AX1
- MOQ: 1 unit
- Lead Time: In-stock items ship within 1–3 business days; ex-factory orders 4–8 weeks.
- Payment: T/T, PayPal, credit card accepted.
- Shipping: DHL / FedEx / UPS worldwide express; sea freight available for bulk orders.
- RFQ: Email [email protected] with quantity and delivery requirements for a formal quotation.
Replacement & Compatibility FAQ
Q: Can the 6AV2128-3MB06-0AX1 replace the older 6AV2128-3MB06-0AX0?
A: Yes. The -0AX1 is the updated firmware revision and is backward compatible. Existing WinCC projects may require a minor version migration in TIA Portal.
Q: Is this panel compatible with S7-300 via MPI?
A: Yes. The integrated MPI/PROFIBUS DP port supports direct connection to S7-300/400 without additional hardware.
Q: Can I use a Weintek or Kinco panel as a direct replacement?
A: Functionally possible with driver configuration, but project migration from WinCC is required. Recommended only when cost constraints outweigh integration complexity.
Q: What is the difference between Comfort Panel and Basic Panel?
A: Comfort Panels support more tags, scripting, recipes, data logging, and advanced communication protocols. Basic Panels are entry-level with limited functionality.
Q: Does Konmask offer technical support for integration?
A: Yes. Our engineering team provides pre-sales selection advice and post-sales integration support. Contact us at [email protected].
