SIEMENS 6SL3244-0BB13-1PA1 SINAMICS S120 Power Module | Replacement, Equivalent & Selection Guide
The SIEMENS 6SL3244-0BB13-1PA1 is a single-axis power module from the SINAMICS S120 series, designed for precise servo and vector drive applications in industrial automation. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Manufacturer: Siemens AG
- Part Number / SKU: 6SL3244-0BB13-1PA1
- Series: SINAMICS S120
- Type: Single-Axis Power Module (PM)
- Rated Output Power: 0.75 kW
- Input Voltage: 3-phase AC 380–480 V (±10%)
- Output Current: 1.3 A (continuous)
- Cooling Method: Internal air cooling
- Communication Interface: DRIVE-CLiQ
- Protection Class: IP20
- Ambient Temperature: 0 °C to +40 °C (up to +55 °C with derating)
- Weight: Approx. 7.5 kg
- Dimensions (W×H×D): Refer to Siemens SINAMICS S120 hardware manual
- Standards: CE, UL, cUL
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the 6SL3244-0BB13-1PA1. Always verify electrical and mechanical compatibility before substitution:
- 6SL3210-1SE11-7UA0 – SINAMICS S120 Booksize Power Module, 1.7 A; suitable for similar power range with booksize form factor
- 6SL3210-1SE12-2UA0 – Higher current variant (2.2 A) for applications requiring headroom
- 6SL3210-1SE13-2UA0 – 3.2 A booksize module; consider when load may increase
- 6SL3210-1SE14-1UA0 – 4.1 A booksize; next tier up for multi-axis expansion
- 6SL3210-1SE16-0UA0 – 6.0 A booksize; for higher-power axis replacement
Note: Cross-referencing requires matching DC link voltage, DRIVE-CLiQ firmware version, and motor encoder compatibility. Contact Konmask for verified replacement sourcing.
Why Choose the Original Model
- Factory-matched firmware and DRIVE-CLiQ protocol for seamless S120 system integration
- Guaranteed compatibility with Siemens CU320-2 and CU310-2 Control Units
- Proven reliability in continuous-duty servo applications
- Full Siemens warranty and traceability when sourced through authorized channels
- Simplified commissioning via STARTER / TIA Portal without parameter re-mapping
Typical Applications
- CNC machine tool spindle and feed axis drives
- Packaging machinery with precise position control
- Textile and printing machine servo axes
- Conveyor and handling systems requiring dynamic speed regulation
- Robotics and multi-axis coordinated motion systems
System Compatibility
- Control Units: SINAMICS S120 CU320-2 DP / PN, CU310-2 DP / PN
- Line Modules: Active Line Module (ALM), Smart Line Module (SLM), Basic Line Module (BLM)
- Motors: Siemens 1FK7, 1FT7, 1PH8 series (DRIVE-CLiQ encoder)
- Software: STARTER V5.x, TIA Portal V15+, SINAMICS Startdrive
- Bus Systems: PROFIBUS DP, PROFINET IO
Selection Guide
Use the following criteria to confirm the 6SL3244-0BB13-1PA1 is the right module for your application, or to select an appropriate alternative:
- Step 1 – Verify rated motor current: Ensure module continuous output current (1.3 A) ≥ motor rated current
- Step 2 – Check form factor: Confirm chassis / booksize / cabinet mounting matches your panel design
- Step 3 – Confirm DC link voltage: Must match the Line Module DC bus in your S120 drive line-up
- Step 4 – Validate DRIVE-CLiQ version: Firmware compatibility between Control Unit and Power Module
- Step 5 – Check ambient conditions: Derate output if ambient exceeds 40 °C or altitude > 1000 m
- Step 6 – Confirm encoder interface: DRIVE-CLiQ native or SMC (Sensor Module Cabinet) required for non-DRIVE-CLiQ motors
Quality Assurance & Sourcing
- All units supplied by Konmask.com are inspected for authenticity and functional integrity
- Batch traceability records available upon request
- New, refurbished, and surplus stock options available — clearly labeled
- Export documentation (CO, packing list, commercial invoice) provided for international orders
- Lead time: In-stock items ship within 1–3 business days; special orders 7–21 days
How to Order
- Online: Add to cart directly on this page at Konmask.com
- Email RFQ: support@konmask.com — include quantity, delivery address, and required delivery date
- Phone / WhatsApp: +0086 19859288691
- Bulk / OEM orders: Contact us for volume pricing and blanket order arrangements
Replacement & Compatibility FAQ
Q: Can I replace 6SL3244-0BB13-1PA1 with a booksize Power Module?
A: Only if the panel layout supports the booksize form factor and the DC link bus is compatible. Consult the SINAMICS S120 hardware manual for mechanical dimensions.
Q: Is firmware update required when replacing the Power Module?
A: Typically yes — use STARTER or TIA Portal to align firmware versions between the Control Unit and the new Power Module via DRIVE-CLiQ auto-detection.
Q: Does Konmask provide a warranty on this module?
A: Yes. New original units carry the standard Siemens warranty. Refurbished units carry a 90-day Konmask functional warranty.
Q: Can this module be used with third-party motors?
A: Yes, via an SMC (Sensor Module Cabinet) to adapt non-DRIVE-CLiQ encoders. Verify resolver or incremental encoder type before ordering the SMC.
Q: What is the lead time for out-of-stock units?
A: Typically 7–21 business days depending on global supply. Contact us for real-time availability.
