Siemens 6SL3330-1TE35-3AA3 Basic Line Module | Replacement, Equivalent & Selection Guide
The Siemens 6SL3330-1TE35-3AA3 is a high-power Basic Line Module from the SINAMICS S120 drive system, rated at 530A input current for demanding industrial applications. This page provides full technical specifications, verified replacement options, and a practical selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 6SL3330-1TE35-3AA3 |
| Series | SINAMICS S120 |
| Module Type | Basic Line Module (BLM) |
| Input Current | 530 A |
| Input Voltage | 3-phase AC 380–480 V ±10% |
| DC Link Voltage | ~600 V DC |
| Power Rating | ~315 kW (at 400 V AC) |
| Cooling Method | Forced air cooling (internal fan) |
| Protection Class | IP20 |
| Ambient Temperature | 0°C to +40°C (derating above 40°C) |
| Weight | ~16 kg |
| Communication | DRIVE-CLiQ |
| Standards | CE, UL, cUL |
Compatible Replacement & Equivalent Models
When the 6SL3330-1TE35-3AA3 is unavailable or discontinued, the following models may serve as functional replacements depending on your system configuration:
| Model | Input Current | Notes |
|---|---|---|
| 6SL3330-1TE35-3AA3 (OEM) | 530 A | Exact match — preferred replacement |
| 6SL3330-1TE38-4AA3 | 840 A | Higher rating — upward compatible with derating |
| 6SL3330-1TE32-6AA3 | 260 A | Lower rating — only if load permits |
| 6SL3330-1TE33-8AA3 | 380 A | Intermediate option — verify DC bus capacity |
| Third-party BLM equivalents | 530 A class | Consult Konmask for verified cross-reference |
Note: Always verify DC link voltage, DRIVE-CLiQ firmware version, and cabinet dimensions before substituting modules.
Why Choose the Original Model
- Exact firmware compatibility — native DRIVE-CLiQ handshake with S120 Control Units (CU320-2, CU310-2)
- Guaranteed DC bus matching — no derating calculations required
- Siemens warranty support — eligible for Siemens repair and exchange programs
- Proven field reliability — widely deployed in steel, paper, and heavy process industries
- Simplified commissioning — plug-and-play with STARTER / TIA Portal V16+
Typical Applications
- Heavy-duty multi-axis drive systems (steel mills, rolling lines)
- Large pump and compressor drives in oil & gas
- Paper machine section drives
- Mining conveyor and hoist systems
- Centralized DC bus architectures with multiple Motor Modules
- Crane and lifting equipment with regenerative braking
System Compatibility
The 6SL3330-1TE35-3AA3 is designed to operate within the SINAMICS S120 Booksize / Chassis platform and is compatible with:
- Control Units: CU320-2 DP, CU320-2 PN, CU310-2 DP/PN
- Motor Modules: All S120 Chassis Motor Modules sharing the same DC bus
- Line Filters: 6SL3000-0BE35-3AA0 (recommended EMC filter)
- Line Reactors: 6SL3000-0CE35-3AA0
- Braking Modules: 6SL3300-1AE32-5AA0 and equivalents
- Software: STARTER V5.4+, TIA Portal V15.1+, SINAMICS Startdrive
Selection Guide
Use the following criteria to confirm the 6SL3330-1TE35-3AA3 is the right module for your application:
- Step 1 — Calculate total motor load: Sum the rated currents of all Motor Modules on the shared DC bus. The BLM input current must exceed this total by ≥10%.
- Step 2 — Verify supply voltage: Confirm 3-phase 380–480 V AC supply with ≤±10% variation.
- Step 3 — Check cabinet space: Confirm chassis dimensions and cooling airflow clearance (min. 100 mm top/bottom).
- Step 4 — Confirm firmware: Match DRIVE-CLiQ firmware version with existing Control Unit to avoid compatibility errors.
- Step 5 — Assess regeneration needs: BLM is non-regenerative; if regenerative braking is required, consider the Active Line Module (ALM) series instead.
Quality Assurance & Sourcing
- ✅ Genuine Siemens parts sourced from authorized distribution channels
- ✅ 4-point inspection: visual check → label verification → functional test → packaging audit
- ✅ Traceability: each unit ships with original Siemens documentation and batch records
- ✅ Refurbished options available — fully tested, 90-day warranty, clearly labeled
- ✅ Export compliance: HS Code 8504.40, CE & RoHS compliant
How to Order
- Confirm part number: 6SL3330-1TE35-3AA3
- Specify quantity and required delivery timeline
- Request a quotation via support@konmask.com or WhatsApp +0086 19859288691
- Receive pro-forma invoice with lead time confirmation
- Choose shipping method: DHL Express / sea freight / air freight
- Receive unit with test report and original packaging
Replacement & Compatibility FAQ
Q: Can I replace 6SL3330-1TE35-3AA3 with a higher-rated BLM?
A: Yes, a higher-rated BLM (e.g., 6SL3330-1TE38-4AA3) is electrically compatible but requires verifying cabinet space and DC bus wiring ratings.
Q: Is this module interchangeable with the Active Line Module (ALM)?
A: No. The BLM is non-regenerative and uses a different control topology. ALM and BLM are not directly interchangeable without system redesign.
Q: What firmware version is required?
A: SINAMICS S120 firmware V4.7 SP9 or later is recommended. Always match the firmware version across all DRIVE-CLiQ components.
Q: Do you supply refurbished units?
A: Yes. Refurbished units are fully tested, clearly labeled, and carry a 90-day warranty. Contact us for pricing.
Q: Can this module be used outside the SINAMICS S120 platform?
A: No. The 6SL3330-1TE35-3AA3 is designed exclusively for the SINAMICS S120 Chassis system and is not compatible with other drive platforms.
