Industrial Ethernet Networking Solution – SIEMENS SCALANCE X108 6GK5108-0BA00-2AA3 | SCALANCE X-100
Where This Product Is Used
The SIEMENS SCALANCE X108 is deployed across demanding industrial environments where reliable, unmanaged Ethernet connectivity is critical to continuous operations:
- Automotive Manufacturing: Connects PLCs, HMIs, and robot controllers on the shop floor, supporting PROFINET-based motion control and vision inspection lines.
- Process & Chemical Plants: Provides stable LAN segments within DCS architectures (e.g., Siemens PCS 7 / SIMATIC S7), linking field devices to control rooms.
- Water & Wastewater Treatment: Installed in remote pump stations and SCADA panels where plug-and-play Ethernet switching eliminates configuration overhead.
- Power Distribution & Substations: Used in ring or star topologies alongside SIPROTEC relays and energy meters for substation automation.
- Machine Building & OEM Panels: Integrated into control cabinets as a cost-effective, DIN-rail-mounted switch for multi-device Ethernet segments.
- Food & Beverage / Packaging Lines: Withstands washdown-adjacent environments; connects servo drives, frequency inverters, and barcode scanners.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (OEM) | 6GK5108-0BA00-2AA3 |
| Cross-Reference SKUs | AS00296-02 / 0190-27709 / C3575 / 715-011900-001 |
| Series | SCALANCE X-100 |
| Switch Type | Unmanaged Industrial Ethernet Switch |
| Number of Ports | 8 × RJ45 (10/100 Mbps, auto-sensing) |
| Transmission Rate | 10/100 Mbps, full/half duplex, auto-negotiation |
| Supply Voltage | 24 V DC (18–32 V DC) |
| Power Consumption | ≤ 3.5 W |
| Operating Temperature | -10 °C to +60 °C |
| Storage Temperature | -40 °C to +80 °C |
| Protection Class | IP30 |
| Mounting | DIN rail (35 mm) / wall mount |
| Dimensions (W×H×D) | Approx. 60 × 125 × 75 mm |
| Weight | Approx. 150 g |
| Certifications | CE, UL, cUL, ATEX Zone 2 (variant-dependent) |
| Protocol Support | PROFINET-compatible (passive pass-through) |
Why Engineers Specify This Model
- Zero-Configuration Deployment: Unmanaged design means no IP setup, no firmware tuning — power on and connect. Ideal for time-critical commissioning.
- SIEMENS Ecosystem Native: Fully compatible with SIMATIC S7-300/400/1200/1500 PLCs, SINAMICS drives, and SIPROTEC protection relays without interoperability risk.
- Industrial-Grade Reliability: Wide temperature range, conformal-coated PCB options, and DIN-rail form factor meet IEC 61131-2 panel requirements.
- Multi-SKU Cross-Reference: Sourced under OEM (6GK5108-0BA00-2AA3) and OEM-equivalent codes (AS00296-02, 0190-27709, C3575, 715-011900-001) — same hardware, verified interchangeable.
- Low Total Cost of Ownership: No licensing fees, no managed-switch overhead; reduces panel BOM cost while maintaining SIEMENS quality standards.
Complete System Bill of Materials
Typical BOM for a SIMATIC S7-1500 + SCALANCE X108 control panel segment:
- SIMATIC S7-1500 CPU (e.g., 6ES7515-2AM02-0AB0)
- SCALANCE X108 Switch — 6GK5108-0BA00-2AA3 (this unit)
- SIMATIC HMI TP700 Comfort (6AV2124-0GC01-0AX0)
- SINAMICS G120 Frequency Inverter (6SL3210-1PE21-8UL0)
- IE FC RJ45 Plug 180 × 10 pcs (6GK1901-1BB10-2AA0)
- SIMATIC NET IE FC TP Standard Cable GP 2×2 (6XV1840-2AH10)
- 24 V DC SITOP PSU100S Power Supply (6EP1334-2BA20)
- DIN Rail 35 mm × 1 m (6ES7390-1AB60-0AA0)
Compliance & Industry Standards
- CE Marking — EU Low Voltage Directive & EMC Directive compliant
- UL 508 / cUL — Industrial Control Equipment (North America)
- IEC 61000-6-2 — Immunity for industrial environments
- IEC 61000-6-4 — Emission standard for industrial environments
- PROFINET Conformance — Compatible with PROFINET IO (passive Ethernet layer)
- RoHS 2 Compliant — Restriction of Hazardous Substances
- ATEX Zone 2 — Available on specific hardware revisions (confirm with datasheet)
Quality Assurance & Sourcing
- All units sourced from authorized SIEMENS distribution channels or verified surplus with full traceability documentation.
- Each unit undergoes incoming inspection: visual check, power-on test, and port-by-port link verification before shipment.
- Serialized tracking maintained; hardware revision and firmware version recorded per order.
- Packaging: original SIEMENS anti-static bag + foam-lined carton; ESD-safe handling throughout.
- Warranty: 12 months from shipment date against manufacturing defects.
How to Source This Part
- Add to Cart — Click “Buy Now” or “Add to Cart” above. Stock is limited; reserve your unit today.
- Request a Quote — For orders of 5+ units or project BOM pricing, email support@konmask.com with your project details.
- Cross-Reference Check — If your BOM lists AS00296-02, 0190-27709, C3575, or 715-011900-001, this is the correct replacement unit.
- Lead Time — In-stock units ship within 1–3 business days. ETA confirmation provided at order.
- Export & Customs — We handle HS code documentation (HS 8517.62) and commercial invoices for international shipments.
Application-Specific FAQ
Q: Is the SCALANCE X108 compatible with PROFINET IO controllers?
A: Yes. As an unmanaged switch, it transparently passes PROFINET frames. It does not require PROFINET device configuration and works seamlessly with S7-1200/1500 PROFINET masters.
Q: Can I use this switch in a ring topology for redundancy?
A: The X108 does not support MRP (Media Redundancy Protocol). For ring redundancy, specify the SCALANCE X208 (6GK5208-0BA10-2AA3) or higher. The X108 is suited for star/tree topologies.
Q: What is the difference between 6GK5108-0BA00-2AA3 and cross-reference codes AS00296-02 / 0190-27709?
A: These are OEM-equivalent part numbers used by system integrators and equipment manufacturers (e.g., semiconductor fab tool builders). The underlying hardware is identical to the SIEMENS OEM part.
Q: Does this switch support PoE (Power over Ethernet)?
A: No. The SCALANCE X108 does not support PoE. For PoE requirements, refer to the SCALANCE XP-200 series.
Q: What DIN rail standard does the mounting bracket support?
A: Standard 35 mm DIN rail (EN 60715 / IEC 60715). Wall-mount brackets are also included in the packaging.
