Tektronix PCE-2 LIF-1 Control Board – Logic Interface & Platform Control | PCE-2 Mainframe Series
Engineering Background
The Tektronix PCE-2 mainframe platform was engineered for high-channel-count, modular test and measurement environments. The LIF-1 (Logic Interface Function) control board serves as the central coordination layer between the mainframe backplane, plug-in modules, and the host controller interface. Part numbers K15SB000, 039-0137-00, and 657-0000-00 are OEM cross-references identifying the same assembly across different Tektronix service documentation revisions.
Product Positioning
This board is a direct OEM-equivalent replacement targeting maintenance engineers, calibration labs, and ATE system integrators who require a verified, traceable spare for Tektronix PCE-2 chassis. Konmask.com sources this component through authorized industrial channels with full traceability documentation available upon request.
Complete Technical Specifications
- Manufacturer: Tektronix
- Part Number (Primary): K15SB000
- Cross-Reference P/N: 039-0137-00 / 657-0000-00
- Board Designation: LIF-1 (Logic Interface Function)
- Platform Compatibility: Tektronix PCE-2 Mainframe
- Board Type: Control / Logic Interface PCB Assembly
- Form Factor: PCE-2 proprietary card format
- Weight (approx.): 500 g
- Condition: New / Refurbished OEM (specify at inquiry)
- Country of Origin: USA (Tektronix OEM)
- RoHS Status: Per original OEM specification
Proven Application Environments
- Tektronix PCE-2 mainframe chassis repair and preventive maintenance
- Automated Test Equipment (ATE) depot-level overhaul
- Defense and aerospace calibration laboratories
- Semiconductor fab equipment maintenance programs
- University and research institute instrument refurbishment
- OEM service centers requiring traceable spare parts
Engineering Advantages
- OEM Traceability: All three part numbers (K15SB000 / 039-0137-00 / 657-0000-00) are verified against Tektronix service documentation
- Drop-in Replacement: No firmware modification or re-calibration required for standard PCE-2 chassis swap
- Functional Verification Available: Boards can be tested against PCE-2 backplane prior to shipment upon request
- Long Lead-Time Alternative: Eliminates 8–16 week OEM factory lead times for discontinued or allocation-constrained parts
- Documentation Package: Certificate of conformance and inspection report available
System Architecture & Signal Flow
Within the PCE-2 mainframe, the LIF-1 board occupies the logic interface slot and manages bidirectional signal arbitration between the backplane bus and installed plug-in modules. It handles interrupt routing, module identification, and control-plane communication to the host IEEE-488 / GPIB controller. Failure modes typically manifest as module non-recognition, bus lockup, or intermittent communication errors — all of which are resolved by replacing this assembly.
Sourcing & Quality Verification
- Sourced through verified industrial surplus and OEM service channels
- Each unit inspected for physical integrity: no bent pins, cracked PCB, or corroded connectors
- Batch traceability records maintained for 3 years
- Anti-static packaging (ESD bag + foam insert) as standard
- Optional: third-party inspection report available for defense/aerospace procurement
Procurement Process
- Submit RFQ via [email protected] or WhatsApp +0086 19859288691
- Receive quotation with lead time and condition confirmation within 24 hours
- Approve proforma invoice — payment via T/T, PayPal, or credit card
- Shipment via DHL / FedEx with tracking; ESD-safe packaging standard
- Post-delivery technical support available for installation verification
Technical FAQ
Q: Are K15SB000, 039-0137-00, and 657-0000-00 the same part?
A: Yes. These are Tektronix OEM cross-reference numbers for the same LIF-1 control board assembly used across different PCE-2 service manual revisions.
Q: Is this board compatible with all PCE-2 chassis revisions?
A: The LIF-1 board is designed for the PCE-2 mainframe platform. Please confirm your chassis serial number range with our technical team to ensure full compatibility.
Q: Can you provide a test report before shipment?
A: Yes. Functional pre-shipment testing against a PCE-2 backplane is available upon request. Please specify this requirement in your RFQ.
Q: What is the warranty?
A: 90-day warranty against DOA (Dead on Arrival) and functional defects under normal operating conditions. Extended warranty available upon negotiation.
Q: Do you accept returns?
A: Returns accepted within 30 days for unused, uninstalled units in original packaging. Please contact [email protected] to initiate.
