Safety Relay Output Solution – TRICONEX 3636T | Tricon TMR Series
Where This Product Is Used
The TRICONEX 3636T Relay Output Module is a critical safety-rated output component deployed in Triple Modular Redundant (TMR) control architectures across high-hazard industries. Engineers specify this module wherever a certified, fault-tolerant relay output interface is required between the safety PLC and field actuators.
Typical deployment environments include:
- Oil & Gas Production & Refining — Emergency Shutdown Systems (ESD), High Integrity Pressure Protection Systems (HIPPS), and compressor/turbine trip circuits
- Petrochemical & Chemical Plants — Burner Management Systems (BMS), reactor interlock loops, and toxic gas release prevention systems
- LNG Terminals & Pipelines — Valve actuator control, fire & gas detection output, and pipeline isolation logic
- Power Generation — Turbine protection, boiler safety shutdown, and generator trip relay interfaces
- Offshore Platforms — Wellhead control panels, subsea control system interfaces, and platform ESD
- Nuclear & Utilities — Safety instrumented function (SIF) output loops requiring IEC 61511 compliance
Technical Specifications
| Part Number | 3636T |
| Manufacturer | TRICONEX (Schneider Electric) |
| Module Type | Relay Output Module |
| Platform | Tricon TMR Safety System |
| Architecture | Triple Modular Redundant (TMR) — 2oo3 voting |
| Output Channels | 16 relay output channels |
| Contact Type | Dry contact relay (SPDT) |
| Output Voltage Range | Up to 120 VAC / 30 VDC |
| Output Current Rating | 2 A per channel (resistive load) |
| Isolation | Optical isolation between logic and field side |
| Backplane Interface | Tricon main chassis backplane |
| Weight | 340 g |
| Operating Temperature | 0°C to 60°C |
| Certifications | SIL 3 (IEC 61508), FM, CSA, ATEX (system-level) |
Why Engineers Specify This Model
- SIL 3 Rated Architecture — The 3636T operates within the Tricon TMR framework, achieving SIL 3 capability through hardware fault tolerance (HFT=2) and 2oo3 voting logic, meeting the most stringent functional safety requirements.
- Hot-Swap / Online Replacement — Modules can be replaced under power without process shutdown, minimizing plant downtime during maintenance windows.
- Proven Field Reliability — TRICONEX TMR systems have accumulated decades of runtime in critical process industries; the 3636T is a well-documented, widely deployed output module with extensive installed base.
- Relay Contact Versatility — Dry contact relay outputs interface directly with solenoid valves, motor starters, and alarm annunciators without additional signal conditioning.
- Diagnostic Coverage — Continuous self-diagnostics detect channel faults and report to the Tricon main processor, supporting proof-test interval optimization.
- Backward Compatibility — Compatible with existing Tricon chassis and I/O termination assemblies, enabling like-for-like replacement without rewiring.
Complete System Bill of Materials
The 3636T is typically sourced alongside the following Tricon system components:
- Tricon Main Chassis (e.g., 3700A, 3706A)
- Tricon Main Processor Module (e.g., 3008, 3006)
- Relay Output Termination Assembly (e.g., 3703E, 3703A)
- Communication Module (e.g., 4351B, 4352B for TriStation connectivity)
- Power Supply Module (e.g., 8312, 8310)
- Digital Input Modules (e.g., 3501E, 3503E) for SIF loop completion
- Field Termination Cables and I/O Wiring Harnesses
Contact support@konmask.com for complete BOM assistance and cross-reference support.
Compliance & Industry Standards
- IEC 61508 — Functional Safety of E/E/PE Safety-related Systems (SIL 3 at system level)
- IEC 61511 — Functional Safety for the Process Industry Sector
- NFPA 72 — National Fire Alarm and Signaling Code (applicable BMS deployments)
- API 670 — Machinery Protection Systems (turbine/compressor applications)
- FM Approved — Factory Mutual approval for hazardous location use
- CSA Certified — Canadian Standards Association certification
- ATEX / IECEx — System-level certification for explosive atmosphere zones (verify with project SIL assessment)
Quality Assurance & Sourcing
Konmask.com sources TRICONEX 3636T modules through verified industrial surplus and authorized distribution channels. Every unit offered is subject to the following quality process:
- Visual Inspection — Board-level inspection for physical damage, corrosion, and component integrity
- Functional Verification — Power-on test and channel-level output verification where test fixtures are available
- Firmware / Revision Check — Hardware revision documented and disclosed prior to shipment
- ESD-Safe Packaging — Shipped in anti-static bags with foam cushioning and double-box protection
- Traceability Documentation — Serial number, revision, and inspection record provided with each unit
We do not sell counterfeit, refurbished-without-disclosure, or untested modules. If a unit does not pass our inspection criteria, it is not listed for sale.
How to Source This Part
Sourcing safety-critical PLC modules requires verified supply and clear lead-time communication. Here is how to proceed:
- Submit an RFQ — Email support@konmask.com with your required quantity, hardware revision (if specified), and project timeline.
- Receive Stock Confirmation — We confirm available inventory, hardware revision, and unit condition within 1 business day.
- Review Quotation — Receive a formal quotation with unit price, shipping options (DHL/FedEx express available), and lead time.
- Place Order — Order directly through this product page or via purchase order for B2B accounts.
- Shipment & Documentation — Units ship with inspection report, packing list, and commercial invoice. Export documentation available for international orders.
For urgent plant shutdowns or emergency spares, call or WhatsApp: +0086 19859288691
Application-Specific FAQ
Q: Is the 3636T compatible with the Tricon v9 and v10 chassis?
A: The 3636T is designed for the Tricon TMR platform. Compatibility depends on chassis generation and backplane revision. Please provide your chassis model number when inquiring so we can confirm fit.
Q: Can this module be used in a SIL 2 application?
A: Yes. A SIL 3-rated module can be deployed in SIL 2 applications. The SIL level of the Safety Instrumented Function is determined by the overall loop design, not the module rating alone.
Q: Do you provide a warranty on used/surplus modules?
A: We offer a 90-day functional warranty on all tested units. Warranty terms are provided with the quotation.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For out-of-stock items, lead time is quoted based on current sourcing pipeline, typically 2–6 weeks.
Q: Can you supply the matching termination assembly (3703E)?
A: Yes. We stock a range of Tricon termination assemblies and I/O accessories. Include your full BOM in your RFQ for consolidated sourcing.
Q: Do you export internationally?
A: Yes. We ship globally via DHL Express and FedEx International Priority. Export documentation, including commercial invoice and HS code declaration, is provided for all international shipments.
