VANGUARD CPCI-350Q-P-38 PSMU-350-3 – AC Power Supply Module | CompactPCI Platform
Engineering Background
The VANGUARD CPCI-350Q-P-38 (PSMU-350-3) is an AC input power supply module engineered for CompactPCI (CPCI) chassis environments. Designed to meet the rigorous demands of industrial automation, telecommunications infrastructure, and defense-grade embedded computing, this unit delivers stable, regulated DC outputs from a standard AC mains input. VANGUARD’s PSMU series is recognized for its high mean time between failures (MTBF) and compliance with PICMG 2.11 power interface standards.
Product Positioning
Targeting procurement engineers and system integrators who require a drop-in replacement or new-build power solution for 3U/6U CompactPCI backplanes, the CPCI-350Q-P-38 bridges legacy system longevity with modern efficiency requirements. It is stocked and verified by Konmask.com as a genuine, tested unit suitable for mission-critical deployments.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | CPCI-350Q-P-38 / PSMU-350-3 |
| Manufacturer | VANGUARD |
| Form Factor | CompactPCI (CPCI) Power Supply Module |
| Input Voltage | AC 85–264 V (universal input) |
| Input Frequency | 47–63 Hz |
| Output Power | 350 W (nominal) |
| Output Voltages | +3.3 V, +5 V, +12 V, −12 V (PICMG 2.11 compliant) |
| Efficiency | ≥ 80% at full load |
| Cooling | Forced-air / chassis fan tray |
| Connector Interface | CompactPCI backplane power connector |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | −40 °C to +85 °C |
| Humidity | 5%–95% RH, non-condensing |
| Weight | Approx. 150 g |
| Compliance | PICMG 2.11, CE, RoHS |
| MTBF | > 100,000 hours (MIL-HDBK-217F) |
Note: Specifications are reference values. Contact Konmask.com for datasheet confirmation prior to final BOM submission.
Proven Application Environments
- Industrial Automation: CompactPCI-based PLC and DCS controller chassis requiring stable multi-rail DC power
- Telecommunications: Central office and edge compute platforms with 24/7 uptime requirements
- Defense & Aerospace: Ruggedized embedded computing systems with extended temperature and vibration tolerance
- Transportation: Railway signaling and traffic management CompactPCI racks
- Test & Measurement: Automated test equipment (ATE) chassis power subsystems
- Legacy System Maintenance: Direct replacement for aging PSMU-350 series units in existing CPCI infrastructure
Engineering Advantages
- Universal AC Input: Operates across 85–264 VAC without manual voltage selection, simplifying global deployment
- PICMG 2.11 Compliance: Ensures full electrical and mechanical compatibility with standard CompactPCI backplanes and chassis
- High Output Power Density: 350 W in a compact CPCI module form factor reduces chassis slot consumption
- Robust Protection Circuits: Over-voltage protection (OVP), over-current protection (OCP), and short-circuit protection (SCP) on all output rails
- Hot-Swap Capable: Supports live insertion/removal per PICMG hot-swap specifications, minimizing system downtime
- Extended MTBF: >100,000 hours rated life supports long-lifecycle industrial and defense programs
System Architecture & Signal Flow
The CPCI-350Q-P-38 accepts universal AC mains input through an IEC inlet with integrated EMI filtering. The power factor correction (PFC) stage boosts the rectified DC bus to a regulated intermediate voltage. A high-frequency DC-DC converter stage then generates the PICMG-compliant output rails (+3.3 V, +5 V, +12 V, −12 V). Output rails are distributed to the CompactPCI backplane via the PSMU connector, powering all installed peripheral and processor boards. An onboard management controller monitors rail voltages, temperatures, and fan status, asserting fault signals to the system host via the CPCI management bus.
Sourcing & Quality Verification
- Genuine Parts: All VANGUARD modules sourced by Konmask.com are procured through authorized distribution channels or directly from verified OEM surplus inventories
- Incoming Inspection: Each unit undergoes visual inspection, label verification, and functional power-on testing before dispatch
- Traceability: Lot codes and date codes are recorded; documentation available upon request for AS9120 / ISO 9001 audit trails
- Anti-Counterfeit: Units are cross-referenced against VANGUARD part number databases; suspected non-genuine parts are quarantined and not sold
- Warranty: 12-month warranty against manufacturing defects; DOA replacement within 30 days of receipt
Procurement Process
- Confirm Part Number: Verify CPCI-350Q-P-38 / PSMU-350-3 matches your chassis power slot specification and PICMG revision
- Request Datasheet: Contact support@konmask.com for the full VANGUARD PSMU-350-3 datasheet and test report
- Submit RFQ: Provide quantity, required delivery date, and destination country for a firm quotation within 24 hours
- Order Confirmation: Purchase order accepted via email; proforma invoice issued for wire transfer or credit card payment
- Shipping: DHL / FedEx express worldwide; EXW Xiamen or CIF destination available; typical lead time 3–7 business days
- After-Sales: Technical support available via email and WhatsApp; warranty claims processed within 5 business days
Technical FAQ
Q: Is the CPCI-350Q-P-38 compatible with both 3U and 6U CompactPCI chassis?
A: The PSMU-350-3 is designed for the CPCI power slot as defined by PICMG 2.11. Compatibility depends on your specific chassis manufacturer’s power slot implementation. Please share your chassis model for confirmation.
Q: Can this unit operate on 48 VDC input instead of AC?
A: No. The CPCI-350Q-P-38 is an AC input module. For DC input requirements, contact Konmask.com for alternative VANGUARD PSMU variants.
Q: What is the lead time for volume orders (>10 units)?
A: Volume orders are subject to stock availability. Submit an RFQ to support@konmask.com for a committed delivery schedule.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. A CoC is available upon request for all orders. VANGUARD factory CoC or Konmask inspection CoC can be provided depending on procurement requirements.
Q: Is RoHS compliance documentation available?
A: Yes. RoHS compliance declarations are available for all VANGUARD PSMU-350 series modules. Request via email prior to order placement.
