wenglor CP25QXVT80 – High-Performance Photoelectric Distance Sensor | wenglor SNAP Series
Engineering Background
wenglor sensoric GmbH, headquartered in Tettnang, Germany, is a globally recognized manufacturer of industrial sensors, safety systems, and machine vision solutions. Founded in 1983, wenglor has built a reputation for precision optics, robust housing designs, and IO-Link-ready sensor platforms trusted by OEMs and system integrators across automotive, packaging, semiconductor, and logistics industries.
Product Positioning
The CP25QXVT80 is a compact, high-resolution photoelectric distance sensor engineered for non-contact distance measurement and object detection in demanding industrial environments. Designed for procurement engineers who require reliable, spec-verified components with traceable sourcing, this sensor delivers consistent performance across variable surface conditions and ambient light interference.
Complete Technical Specifications
- Part Number / SKU: CP25QXVT80
- Manufacturer: wenglor sensoric GmbH
- Country of Origin: Germany (DE)
- Sensor Type: Photoelectric Distance Sensor
- Series / Platform: wenglor SNAP Series
- Operating Principle: Triangulation / Diffuse reflection with background suppression
- Sensing Range: Refer to official wenglor datasheet for CP25QXVT80
- Output Type: Analog / IO-Link (verify per datasheet)
- Supply Voltage: 10–30 V DC
- Protection Class: IP67
- Housing Material: High-grade thermoplastic / stainless steel front
- Connection: M12 connector
- Operating Temperature: -25°C to +60°C
- Weight: approx. 500 g (packaged)
- Certifications: CE, RoHS compliant
- HS Code: 8543.70 (electronic sensors / transducers)
Note: Always cross-reference with the official wenglor CP25QXVT80 datasheet for final engineering validation.
Proven Application Environments
- Automotive body-in-white assembly lines – gap and flush measurement
- Packaging machinery – label presence detection and fill-level monitoring
- Semiconductor wafer handling – non-contact thickness and position sensing
- Logistics & conveyor systems – object height profiling and sorting
- Printing & paper industry – web tension and edge detection
- Robotics end-of-arm tooling – part presence and pick confirmation
Engineering Advantages
- Background Suppression: Eliminates false triggers from reflective backgrounds, ensuring reliable detection on complex surfaces.
- IO-Link Compatibility: Enables real-time parameter adjustment, process data logging, and predictive maintenance integration via IO-Link master.
- Compact Form Factor: Space-optimized housing fits tight machine frames without compromising sensing performance.
- High EMC Immunity: Designed to operate reliably in electrically noisy industrial environments (welding cells, VFD-driven systems).
- IP67 Sealing: Withstands wash-down, coolant splash, and dust ingress in harsh production environments.
System Architecture & Signal Flow
The CP25QXVT80 integrates into standard PLC/DCS control architectures via its analog output (4–20 mA / 0–10 V) or IO-Link port. Typical signal flow:
- Power Supply: 24 V DC from control panel → sensor M12 connector
- Signal Output: Analog signal → PLC analog input module (e.g., Siemens SM 331, Allen-Bradley 1756-IF16)
- IO-Link Path: IO-Link master port → PROFINET / EtherNet/IP gateway → PLC CPU
- Grounding: Shield connected at control cabinet entry point per IEC 61000-5-2
Sourcing & Quality Verification
- Source: Konmask.com sources wenglor components through authorized distribution channels and verified surplus markets with full traceability.
- Inspection: Each unit undergoes visual inspection, label verification, and functional pre-check prior to dispatch.
- Documentation: Certificate of conformity and original manufacturer packaging available upon request.
- Authenticity: Holographic labels, date codes, and lot numbers verified against wenglor’s product authentication guidelines.
Procurement Process
- Submit RFQ – Contact support@konmask.com with quantity, required delivery date, and project reference.
- Quotation – Receive a formal quotation within 1 business day including lead time and shipping options.
- Order Confirmation – Purchase order accepted via email or online checkout.
- Quality Check & Dispatch – Unit inspected, packed, and shipped with tracking within 2–5 business days.
- After-Sales Support – Technical support available post-delivery for integration assistance.
Technical FAQ
Q: Is the CP25QXVT80 IO-Link compatible?
A: Yes, the CP25QXVT80 supports IO-Link communication for advanced diagnostics and remote parameterization. Confirm IO-Link version with the official wenglor datasheet.
Q: What PLC systems is this sensor compatible with?
A: The analog output is universally compatible with any PLC analog input module (Siemens, Allen-Bradley, Mitsubishi, Omron, Beckhoff, etc.). IO-Link requires a compatible IO-Link master.
Q: Can this sensor detect transparent or shiny objects?
A: Performance on transparent or highly reflective surfaces may vary. Contact our technical team for application-specific guidance.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing available for orders of 5+ units.
Q: Do you provide a warranty?
A: Yes, a 90-day functional warranty is provided on all units. Extended warranty options available upon request.
