Process Control Solution — YOKOGAWA AI-917-00 | Analog Input Module
Where This Product Is Used
The YOKOGAWA AI-917-00 Analog Input Module is deployed in mission-critical process automation environments where precise, multi-channel analog signal acquisition is essential. Typical installation sites include:
- Oil & Gas Refineries — Continuous monitoring of flow, pressure, and temperature transmitters across distillation columns and pipeline segments.
- Chemical & Petrochemical Plants — Real-time acquisition of 4–20 mA signals from field instruments in reactor control loops.
- Power Generation Facilities — Integration with turbine control systems and boiler management for load-following and safety interlock functions.
- Pulp & Paper Mills — Coordinating analog inputs from consistency transmitters, level sensors, and pressure gauges across multi-stage processes.
- Water & Wastewater Treatment — Centralized SCADA/DCS acquisition of flow meters, pH sensors, and dissolved oxygen probes.
- Pharmaceutical Manufacturing — GMP-compliant process monitoring in batch reactors and clean-room HVAC systems.
Technical Specifications
| Manufacturer | YOKOGAWA Electric Corporation |
| Part Number | AI-917-00 |
| Module Type | Analog Input (AI) |
| Compatible Platform | CENTUM VP / CENTUM CS 3000 DCS |
| Signal Type | 4–20 mA DC (standard), HART-compatible variants available |
| Input Channels | Multi-channel (refer to YOKOGAWA datasheet for channel count) |
| Resolution | 16-bit A/D conversion |
| Isolation | Channel-to-channel and channel-to-bus isolation |
| Operating Temperature | 0°C to 60°C |
| Power Supply | Supplied via DCS backplane (no external power required) |
| Weight | 300 g (approx.) |
| Mounting | DCS I/O card slot (hot-swap capable on supported chassis) |
| Communication | Internal DCS bus (Vnet/IP or ESB depending on platform generation) |
Why Engineers Specify This Model
- Platform Continuity — Direct drop-in replacement for existing CENTUM VP and CS 3000 installations; no re-engineering of I/O mapping or function blocks required.
- High-Resolution Conversion — 16-bit A/D ensures measurement accuracy that satisfies tight PID loop tuning requirements in refinery and chemical applications.
- Galvanic Isolation — Protects the DCS backplane from ground loops and transient surges common in industrial field wiring environments.
- Hot-Swap Capability — Supports online replacement on compatible chassis, eliminating planned shutdowns for module maintenance.
- Proven Field Reliability — YOKOGAWA’s CENTUM platform has an established track record exceeding 30 years in continuous process industries worldwide.
- Simplified Diagnostics — Integrated self-diagnostics report module health to the DCS operator station, enabling predictive maintenance workflows.
Complete System Bill of Materials
For a fully operational CENTUM VP analog input subsystem, engineers typically specify the following alongside the AI-917-00:
- YOKOGAWA CENTUM VP Field Control Station (FCS) — e.g., AFV10D or AFV30D
- I/O Node Unit (IOU) or Node Unit (NU) chassis
- Terminal Board (TB) — matched to AI-917-00 signal type (e.g., TB820 for 4–20 mA)
- Field wiring marshalling cabinet with surge protection barriers
- HART Multiplexer (optional) — for HART pass-through to asset management software
- Redundant power supply modules for IOU chassis
- Fiber optic or Vnet/IP network switch for FCS-to-HIS communication
Compliance & Industry Standards
- CE Marking — Compliant with EU EMC and Low Voltage Directives
- UL / cUL Listed — Recognized for use in North American industrial installations
- IEC 61511 — Suitable for use within Safety Instrumented Systems (SIS) when applied per functional safety assessment
- IEC 61158 / IEC 61784 — Fieldbus and industrial communication standards compliance
- RoHS Compliant — Restriction of Hazardous Substances per EU Directive 2011/65/EU
- ATEX / IECEx — Consult YOKOGAWA for zone-rated variants if hazardous area installation is required
Quality Assurance & Sourcing
Konmask.com sources the AI-917-00 through established industrial automation supply channels. Every unit offered is subject to the following quality controls:
- Visual & Physical Inspection — Connector integrity, label legibility, and housing condition verified upon receipt.
- Authenticity Verification — Part markings, date codes, and firmware revision labels cross-referenced against YOKOGAWA documentation.
- Functional Test (where applicable) — Bench-level power-on and communication checks performed on select inventory batches.
- Secure Packaging — Anti-static packaging with moisture barrier and shock-absorbing foam for international shipment.
- Traceability — Lot records maintained for warranty and returns processing.
How to Source This Part
Procurement teams and MRO buyers can acquire the YOKOGAWA AI-917-00 through the following steps:
- Request a Quote — Email support@konmask.com with your required quantity, delivery timeline, and destination country for a formal quotation.
- Add to Cart — For standard single-unit or small-quantity orders, use the Add to Cart button above and proceed through secure checkout.
- Bulk / Project Orders — For BOM-level procurement (10+ units or multi-line orders), contact us directly for volume pricing and consolidated shipping options.
- Lead Time — In-stock units ship within 1–3 business days. Out-of-stock items are sourced on request; typical lead time 2–6 weeks depending on availability.
- Export & Customs — We handle export documentation (commercial invoice, packing list, COO) for international shipments. HS Code available upon request.
Application-Specific FAQ
Q: Is the AI-917-00 compatible with both CENTUM VP and CENTUM CS 3000?
A: Yes. The AI-917-00 is designed for the CENTUM platform family. Confirm chassis and IOU generation compatibility with your YOKOGAWA system integrator or refer to the CENTUM VP Hardware Engineering Guide.
Q: Can this module be replaced online without shutting down the DCS?
A: Hot-swap capability depends on the specific IOU chassis model. Most current-generation CENTUM VP node units support online card replacement. Verify with your site’s YOKOGAWA maintenance documentation.
Q: Does the AI-917-00 support HART communication?
A: The base AI-917-00 supports standard 4–20 mA. HART pass-through capability depends on the terminal board and HART multiplexer configuration. Contact us to confirm HART-enabled variants.
Q: What is the warranty on this module?
A: Konmask.com provides a 90-day functional warranty on all modules sold. Extended warranty and on-site support can be arranged through YOKOGAWA’s authorized service network.
Q: Do you provide a certificate of conformance or test report?
A: Yes. A certificate of conformance is available upon request for all orders. Functional test reports are available for batches that have undergone bench testing.
Q: Can you source other YOKOGAWA CENTUM modules not listed on your site?
A: Absolutely. Konmask.com specializes in sourcing hard-to-find DCS and PLC components. Submit your full BOM to support@konmask.com and we will respond with availability and pricing within 24 hours.
