YOKOGAWA F3PU10-0N – FA-M3 Series Power Supply Module | Industrial PLC Power Unit
Engineering Background
The YOKOGAWA FA-M3 (F3 Series) is one of the most widely deployed programmable automation controller platforms in process-critical industries across Asia-Pacific, the Middle East, and Europe. Engineered for deterministic control in demanding environments, the FA-M3 architecture separates power delivery from logic processing — making the power supply module a foundational component for system reliability and uptime.
Product Positioning
The F3PU10-0N is the dedicated power supply module for YOKOGAWA FA-M3 base units. It converts AC mains input to the regulated DC rails required by CPU, I/O, and communication modules. Procurement engineers specifying replacement or expansion units for FA-M3 racks should confirm base unit compatibility and input voltage range before ordering.
Complete Technical Specifications
| Manufacturer | YOKOGAWA Electric Corporation |
| Part Number / SKU | F3PU10-0N |
| Series / Platform | FA-M3 / F3 Series |
| Module Type | Power Supply Module |
| Input Voltage | 100–240 V AC, 50/60 Hz (universal input) |
| Output Voltage | 5 V DC (logic rail) + 24 V DC (field power, model-dependent) |
| Rated Output Current | Refer to FA-M3 system manual for base-unit load capacity |
| Isolation | Reinforced isolation between AC input and DC output rails |
| Protection | Overcurrent, overvoltage, short-circuit protection |
| Mounting | FA-M3 base unit slot (left-most position) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Humidity | 10–90% RH, non-condensing |
| Country of Origin | Japan |
| Weight (approx.) | 2.4 kg |
| Certifications | CE, UL (refer to YOKOGAWA datasheet for current approvals) |
Proven Application Environments
- Oil & gas upstream/downstream process control
- Chemical and petrochemical plant automation
- Power generation and utilities SCADA integration
- Pharmaceutical batch control (FDA 21 CFR Part 11 environments)
- Pulp, paper, and continuous manufacturing lines
- Water treatment and municipal infrastructure
- Semiconductor fab equipment control
Engineering Advantages
- Universal AC Input: 100–240 V AC auto-ranging eliminates region-specific SKU proliferation.
- Redundancy-Ready: FA-M3 architecture supports dual power supply configurations for high-availability systems.
- Hot-Swap Capable: Designed for minimal-disruption replacement in live FA-M3 racks (verify with system integrator).
- Compact Form Factor: Single-slot footprint preserves rack space for I/O and communication modules.
- Proven MTBF: YOKOGAWA FA-M3 components are rated for continuous industrial duty with documented field reliability records.
System Architecture & Signal Flow
In a standard FA-M3 rack, the F3PU10-0N occupies the leftmost slot and distributes regulated power across the backplane to all installed modules. The CPU module (e.g., F3SP28, F3SP38, F3SP53, F3SP58, F3SP67, F3SP71, F3SP76) draws logic power from the 5 V rail, while field-side I/O modules may draw from the 24 V rail depending on module type. Proper load calculation per the FA-M3 System Manual (IM 34M01A01-01E) is required before commissioning.
Signal flow: AC Mains Input → EMI Filter → Rectifier → DC-DC Converter → Regulated 5 V / 24 V Rails → FA-M3 Backplane → CPU / I/O / Comm Modules
Sourcing & Quality Verification
- All units sourced through verified industrial automation supply channels.
- Pre-shipment inspection includes visual check, label verification, and functional power-on test where applicable.
- Original YOKOGAWA part markings, serial numbers, and firmware labels are preserved and unmodified.
- Packaging inspected for transit damage before dispatch.
- Certificate of conformance available upon request for regulated industries.
Procurement Process
- Confirm your FA-M3 base unit model and current power budget (refer to IM 34M01A01-01E).
- Verify input voltage at your installation site (100–240 V AC).
- Submit your order via Konmask.com or contact us directly for volume pricing and lead time.
- Receive order confirmation with estimated dispatch date within 1 business day.
- Shipment with tracking; express options available for urgent MRO requirements.
- Post-delivery technical support available via email or phone.
Technical FAQ
Q: Is the F3PU10-0N compatible with all FA-M3 base units?
A: The F3PU10-0N is designed for the YOKOGAWA FA-M3 (F3 Series) platform. Compatibility depends on the specific base unit model. Always cross-reference with the FA-M3 System Manual before installation.
Q: Can two F3PU10-0N modules be used in a redundant power configuration?
A: FA-M3 supports redundant power supply configurations on select base units. Consult the system manual or contact our technical team for your specific rack model.
Q: What is the lead time for this module?
A: In-stock units typically ship within 1–3 business days. Contact us for current stock status and expedited shipping options.
Q: Do you provide a warranty?
A: Yes. All units are covered by our standard 90-day functional warranty. Extended warranty and service agreements are available upon request.
Q: Can I request a datasheet or certificate of conformance?
A: Yes. Contact support@konmask.com with your order reference and we will provide the relevant documentation.
