Genuine YOKOGAWA F3XD16-4N Basic I/O Module | FA-M3 Series – Verified Source
The YOKOGAWA F3XD16-4N is a 16-point mixed digital input/output module designed for the FA-M3 Range-free Multi-controller platform. Engineered for high-speed, high-reliability process control in demanding industrial environments, this module delivers deterministic I/O performance with seamless integration into YOKOGAWA’s modular PLC architecture. Konmask.com supplies this unit as a verified genuine component with full traceability documentation available on request.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | F3XD16-4N |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series / Platform | FA-M3 Range-free Multi-controller |
| Module Type | Basic Mixed Digital Input/Output Module |
| Total I/O Points | 16 Points (mixed DI/DO) |
| Input Voltage Range | 24 VDC (nominal) |
| Output Type | Transistor (NPN sink) |
| Isolation | Photocoupler isolation (I/O ↔ internal bus) |
| Response Time | ≤ 1 ms (input filter selectable) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 10% to 90% RH (non-condensing) |
| Power Consumption | Refer to FA-M3 system power budget |
| Weight | Approx. 214 g |
| Mounting | FA-M3 base unit slot (hot-swap capable) |
| Certifications | CE, UL, cUL (refer to current datasheet) |
| Country of Origin | Japan |
Our 4-Step Quality Verification Process
Every YOKOGAWA F3XD16-4N shipped from Konmask.com passes through a rigorous four-stage inspection protocol before dispatch:
- Step 1 – Source Authentication: Units are procured exclusively from authorized YOKOGAWA distributors or verified OEM surplus channels. Supplier credentials and purchase records are retained on file.
- Step 2 – Physical Inspection: Each module undergoes visual inspection for label integrity, firmware revision markings, connector condition, and housing authenticity. Counterfeit indicators are cross-checked against YOKOGAWA’s published security features.
- Step 3 – Functional Bench Test: Where applicable, modules are powered up and I/O point continuity, bus communication, and LED status indicators are verified against factory specifications.
- Step 4 – Documentation Package: Shipment includes a Konmask inspection report, original manufacturer labeling, and optional Certificate of Conformance (CoC) upon request.
Key Features & Benefits
- 16-point mixed digital I/O in a single compact slot — reduces panel footprint and wiring complexity
- Photocoupler isolation protects the CPU backplane from field-side transients and ground loops
- Selectable input filter time constants allow adaptation to noisy industrial field signals
- Hot-swap capable design minimizes process downtime during maintenance or module replacement
- Fully compatible with FA-M3 programming tools (WideField3) and existing ladder/function block programs
- Deterministic scan-cycle I/O update ensures reliable real-time control loop performance
Typical Applications
- Continuous process control in oil & gas, petrochemical, and refinery plants
- Discrete manufacturing automation: conveyor control, machine interlocking, and status monitoring
- Water and wastewater treatment plant SCADA integration
- Power generation auxiliary control systems
- Pharmaceutical batch process automation requiring audit-trail compliance
- Food & beverage packaging line control with hygienic environment requirements
Compatible System Components
- CPU Modules: F3SP22-0S, F3SP28-3N, F3SP38-6N, F3SP53-4H, F3SP58-6H, F3SP67-6S, F3SP76-7N, F3SP87-4S (FA-M3 series)
- Base Units: F3BU04-0N, F3BU06-0N, F3BU09-0N, F3BU12-0N
- Power Supply Modules: F3PU20-0S, F3PU30-0S
- Programming Software: WideField3 (WT3-WFENG / WT3-WFJPN)
- Communication Modules: F3LE01-5T (Ethernet), F3LP02-0N (PROFIBUS-DP)
Global Sourcing & Shipping Capabilities
Konmask.com maintains an active global procurement network for YOKOGAWA FA-M3 components, including both current-production and legacy/discontinued modules. We ship to over 80 countries with the following logistics capabilities:
- Express air freight (DHL / FedEx / UPS) with typical transit of 3–7 business days worldwide
- Sea freight consolidation for large-volume orders (LCL/FCL)
- Export documentation: commercial invoice, packing list, certificate of origin, and EAR99 classification confirmation
- Customs pre-clearance support for EU, US, and Southeast Asian import requirements
- Secure anti-static packaging with humidity indicator cards for sensitive electronics
Certifications & Compliance Statement
The YOKOGAWA F3XD16-4N is manufactured in compliance with the following standards (verify current revision with YOKOGAWA datasheet GS 34P02Q10-01E):
- CE Marking – EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- UL / cUL Listed – Industrial Control Equipment (UL 508)
- RoHS Compliant – Directive 2011/65/EU (Restriction of Hazardous Substances)
- IEC 61131-2 – Programmable Controllers: Equipment Requirements and Tests
Konmask.com does not modify, relabel, or alter manufacturer firmware or hardware. All compliance certifications remain as issued by YOKOGAWA Electric Corporation.
How to Order
- Submit RFQ: Email [email protected] with your required quantity, delivery timeline, and destination country.
- Receive Quotation: Our team responds within 1 business day with pricing, lead time, and available stock confirmation.
- Order Confirmation: Issue a Purchase Order (PO) or pay via secure online checkout. Proforma invoice available for wire transfer payments.
- Quality Check & Dispatch: Module passes our 4-step verification, is packaged securely, and tracking details are provided within 24 hours of shipment.
- After-Sales Support: 12-month warranty on verified genuine units. Technical support available via email and WhatsApp.
Authenticity & Trust FAQ
- Q: How do I know the F3XD16-4N is genuine and not counterfeit?
- A: All units are sourced from traceable supply chains. We provide supplier documentation, physical inspection reports, and can arrange third-party verification for large orders. YOKOGAWA serial numbers are cross-referenced where the manufacturer’s verification portal is available.
- Q: Do you offer a warranty?
- A: Yes. Verified genuine units carry a 12-month warranty against manufacturing defects. DOA (Dead on Arrival) units are replaced or refunded within 30 days of delivery.
- Q: Can you supply discontinued or legacy FA-M3 modules?
- A: Yes. Konmask specializes in sourcing both current-production and end-of-life YOKOGAWA components. Contact us with your full BOM for availability assessment.
- Q: What is your minimum order quantity (MOQ)?
- A: MOQ is 1 unit. Volume pricing is available for orders of 5 units or more.
- Q: Can you provide a Certificate of Conformance (CoC)?
- A: Yes, a Konmask CoC is available with every order. YOKOGAWA factory CoC is available subject to supply chain documentation availability.
