Process Control Power Solution – YOKOGAWA PW482-10 S2 | CENTUM VP / CS 3000 Series
Where This Product Is Used
The YOKOGAWA PW482-10 S2 Power Supply Module is a mission-critical component deployed across high-availability industrial control environments. Typical installation sites include:
- Oil & Gas Refineries – Powering CENTUM VP field control stations (FCS) in continuous process units such as crude distillation, hydrotreating, and gas compression.
- Chemical & Petrochemical Plants – Supplying stable DC power to redundant DCS cabinets managing reactor temperature, pressure, and flow loops.
- LNG Terminals & Offshore Platforms – Used in safety-instrumented and process-control panels where power interruption is not tolerable.
- Power Generation (Thermal / Nuclear) – Integrated into turbine control and boiler management systems requiring IEC-grade power conditioning.
- Pulp, Paper & Pharmaceuticals – Deployed in batch and continuous process DCS racks where clean, regulated DC power is mandatory for I/O module stability.
- Water & Wastewater Treatment – Installed in remote field panels controlling pumping stations and chemical dosing systems.
Technical Specifications
| Manufacturer | YOKOGAWA Electric Corporation |
| Part Number | PW482-10 S2 |
| Module Type | Power Supply Module |
| Compatible Platform | CENTUM VP, CENTUM CS 3000 |
| Input Voltage | 100–240 V AC, 50/60 Hz (wide-range) |
| Output Voltage | 24 V DC (regulated) |
| Rated Output Current | 10 A |
| Rated Output Power | 240 W |
| Redundancy Support | Yes – supports N+1 redundant power configuration |
| Isolation | Input/Output galvanic isolation |
| Protection Features | Overvoltage, overcurrent, short-circuit, overtemperature |
| Cooling Method | Forced air / convection (cabinet-integrated) |
| Weight | 900 g |
| Mounting | DIN rail / rack-mount (CENTUM standard backplane) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5% to 95% RH (non-condensing) |
Why Engineers Specify This Model
- Platform Compatibility – Designed exclusively for YOKOGAWA CENTUM VP and CS 3000 architectures; plug-and-play replacement with no firmware reconfiguration required.
- Redundant Power Architecture – Supports parallel operation for N+1 redundancy, eliminating single points of failure in critical control loops.
- Wide AC Input Range – Accepts 100–240 V AC globally, simplifying procurement for multinational plant operators.
- Comprehensive Protection – Built-in OVP, OCP, SCP, and OTP safeguards protect downstream I/O modules and field instruments from power anomalies.
- Proven Field Reliability – Validated in continuous 24/7 process environments with MTBF ratings consistent with YOKOGAWA’s high-availability DCS standards.
- Minimal Footprint – Compact module form factor integrates directly into existing CENTUM cabinet layouts without structural modification.
Complete System Bill of Materials
The PW482-10 S2 is typically specified alongside the following YOKOGAWA components for a complete, redundant FCS power subsystem:
- PW482-10 S2 × 2 (N+1 redundant pair)
- YOKOGAWA EB401 / EB501 – Field Control Station (FCS) Enclosure
- YOKOGAWA ACM11 / ACM12 – Node Interface Unit
- YOKOGAWA ADM11 / ADM51 – Analog I/O Modules
- YOKOGAWA ALR111 – Alarm Module
- YOKOGAWA ESB Bus Coupler – for Vnet/IP network integration
- UPS (24 V DC compatible) – for extended power-loss ride-through
Contact support@konmask.com for full BOM quotation and cross-reference assistance.
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL / cUL Listed – Recognized for use in North American industrial installations
- IEC 61010-1 – Safety requirements for electrical equipment for measurement, control, and laboratory use
- IEC 61131-2 – Programmable controllers: equipment requirements and tests
- RoHS Compliant – Restriction of Hazardous Substances Directive
- ATEX / IECEx – Suitable for integration into ATEX-zoned cabinet assemblies (verify zone classification with your system integrator)
Quality Assurance & Sourcing
At Konmask.com, every YOKOGAWA module is subject to a rigorous intake and verification process before dispatch:
- Authenticity Verification – All units are cross-referenced against YOKOGAWA’s official part numbering and label standards.
- Functional Inspection – Power-on bench testing confirms output voltage regulation, protection circuit activation, and status LED behavior.
- Condition Grading – Units are graded as New (factory-sealed), Refurbished (tested & recertified), or Surplus (tested, cosmetic wear acceptable). Grade is disclosed at point of sale.
- Traceability Documentation – Serial number records and test reports available upon request for regulated industries.
- Secure Packaging – Anti-static packaging with foam cushioning; export-compliant labeling for international shipments.
How to Source This Part
- Confirm your part number – Verify PW482-10 S2 against your CENTUM system BOM or YOKOGAWA engineering drawing.
- Request a quote – Email support@konmask.com with quantity, required condition grade, and delivery timeline.
- Lead time & stock check – In-stock units ship within 3–5 business days; sourced units typically 2–4 weeks.
- Payment & logistics – T/T bank transfer, PayPal, and trade-term options (EXW, FOB Xiamen, CIF) available.
- After-sales support – 12-month warranty on refurbished units; technical support available via email and WhatsApp.
Application-Specific FAQ
Q: Is the PW482-10 S2 compatible with both CENTUM VP and CS 3000?
A: Yes. The PW482-10 S2 is designed for use across YOKOGAWA’s CENTUM platform family. Always verify cabinet slot compatibility with your system revision documentation.
Q: Can two PW482-10 S2 modules operate in parallel for redundancy?
A: Yes. YOKOGAWA’s CENTUM power architecture supports N+1 redundant power supply configurations. Both modules share the load and one takes over automatically upon failure of the other.
Q: What is the difference between PW482-10 and PW482-10 S2?
A: The S2 suffix denotes a second-generation revision with enhanced EMC filtering and improved thermal management. It is backward-compatible with original PW482-10 slots.
Q: Do you supply the module with a warranty?
A: Yes. Refurbished and surplus units carry a 12-month functional warranty. New factory-sealed units carry the original YOKOGAWA manufacturer warranty.
Q: Can this module be used outside of a YOKOGAWA DCS system?
A: The PW482-10 S2 is optimized for CENTUM backplane integration. Use in non-YOKOGAWA systems is not recommended and may void warranty.
Q: What documentation can you provide?
A: We can supply the YOKOGAWA datasheet, test report, and packing list. For regulated industries, serial number traceability records are available on request.
