Genuine Allen-Bradley 1768-M04SE 4-Axis Servo Interface Module | CompactLogix – Verified Source
The Allen-Bradley 1768-M04SE is a 4-axis servo interface module designed for the CompactLogix L4x platform, enabling precise multi-axis motion control in demanding industrial environments. Sourced through verified supply channels and inspected by Konmask.com’s quality team before every shipment.
Technical Specifications
- Part Number: 1768-M04SE
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Series: CompactLogix 1768
- Module Type: Servo Interface / Motion Control Module
- Axes Supported: Up to 4 servo axes
- Interface: SERCOS (Serial Real-time Communication System)
- Compatible Controllers: CompactLogix L43, L45 (1768 platform)
- Backplane Communication: CompactLogix local I/O bus
- Power Consumption: Refer to Rockwell Automation product documentation
- Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F)
- Storage Temperature: -40 °C to 85 °C
- Relative Humidity: 5–95% non-condensing
- Weight: Approx. 500 g
- Certifications: UL, CE, cUL
Our 4-Step Quality Verification Process
Every 1768-M04SE shipped from Konmask.com passes through a rigorous four-stage inspection protocol:
- Step 1 — Source Verification: We trace each unit to authorized distributors or OEM-certified supply chains. No grey-market or unverified lots are accepted.
- Step 2 — Physical Inspection: Trained technicians inspect housing, labels, connector pins, and firmware revision markings for authenticity indicators.
- Step 3 — Functional Bench Test: Where applicable, modules are powered and tested for communication handshake and basic axis enumeration prior to packaging.
- Step 4 — Documentation Review: Serial number, date code, and revision level are logged and cross-referenced against manufacturer records before dispatch.
Key Features & Benefits
- 4-axis SERCOS motion interface for high-speed, synchronized servo control
- Seamless integration with Studio 5000 Logix Designer for motion programming
- Deterministic real-time communication via SERCOS fiber-optic ring
- Supports electronic gearing, camming, and coordinated motion profiles
- Hot-swap capable within CompactLogix chassis (check firmware compatibility)
- Compact form factor — fits standard 1768 local expansion chassis
- Backed by Rockwell Automation’s global support ecosystem
Typical Applications
- Packaging Machinery: Multi-axis pick-and-place, form-fill-seal, and cartoning lines requiring synchronized motion
- Printing & Converting: Web tension control and register mark synchronization across multiple servo drives
- Assembly Automation: Robotic cell coordination and precision torque/position control
- Material Handling: Conveyor indexing, palletizing, and gantry positioning systems
- CNC & Machining Centers: Coordinated axis interpolation for cutting and milling operations
- Semiconductor & Electronics Manufacturing: Ultra-precise stage positioning and wafer handling
Compatible System Components
- Controllers: 1768-L43, 1768-L45 CompactLogix processors
- Chassis: 1768-A10, 1768-A7 local expansion chassis
- Power Supply: 1768-PA3, 1768-PB3
- SERCOS Drives: Kinetix 6000 (2094-xx), Kinetix 6200/6500 series
- Programming Software: Studio 5000 Logix Designer v21+
- Communication Modules: 1768-ENBT (EtherNet/IP), 1768-EWEB
- I/O Modules: 1769 Compact I/O series (via 1768-C10 cable)
Global Sourcing & Shipping Capabilities
- Stock Availability: In-stock and ex-warehouse units available for immediate dispatch
- Lead Time: Standard orders ship within 3–5 business days; expedited options available
- Shipping Regions: Worldwide — Asia-Pacific, Europe, North America, Middle East, Africa
- Export Compliance: All shipments comply with applicable export control regulations (EAR/ECCN)
- Packaging: Anti-static ESD packaging with foam cushioning; original manufacturer packaging preserved where available
- Customs Documentation: Commercial invoice, packing list, and certificate of origin provided upon request
Certifications & Compliance Statement
- UL Listed — Underwriters Laboratories industrial control equipment standard
- CE Marked — Compliant with EU Low Voltage Directive and EMC Directive
- cUL — Canadian certification for industrial use
- RoHS Compliant — Restriction of Hazardous Substances (verify revision level)
- SERCOS III / SERCOS II Protocol — Conforms to IEC 61491 motion bus standard
- IEC 61131-3 — Compatible with structured text and ladder logic programming environments
How to Order
- Confirm Part Number: Verify 1768-M04SE matches your system’s firmware and chassis revision requirements.
- Request a Quote: Contact us via support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Review & Approve: We provide a formal quotation with unit price, lead time, and shipping terms (EXW/FOB/CIF available).
- Place Order: Purchase directly through this product page or via purchase order (PO) for qualified B2B accounts.
- Receive & Verify: Each shipment includes a quality inspection report and traceable documentation for your records.
Authenticity & Trust FAQ
Q: How do I know the 1768-M04SE I receive is genuine?
A: Every unit is sourced from verified supply chains and passes our 4-step inspection process. We provide serial number documentation and can assist with Rockwell Automation’s product authentication tools upon request.
Q: Do you offer a warranty?
A: Yes. All modules carry a minimum 90-day functional warranty. Extended warranty options are available — contact us for details.
Q: Can you supply multiple units for a production line build?
A: Absolutely. We support volume orders and can coordinate phased delivery to match your project schedule. Request a bulk quote via email.
Q: What if the module is DOA (Dead on Arrival)?
A: We offer a full replacement or refund for DOA units reported within 7 days of receipt, subject to our returns policy. Contact support@konmask.com immediately with photos and serial number.
Q: Do you provide datasheets or installation manuals?
A: Yes. Rockwell Automation’s official documentation (publication 1768-UM002) is available upon request. We can also provide application notes for common integration scenarios.
Q: Can you source discontinued or hard-to-find revisions?
A: We specialize in legacy and hard-to-source industrial components. Contact us with your specific revision requirement and we will advise on availability.
