Machine Control HMI Solution – Allen-Bradley 2711C-K3M | PanelView C300 Series
Where This Product Is Used
The Allen-Bradley 2711C-K3M PanelView C300 Mono/Keypad is a compact human-machine interface (HMI) terminal engineered for demanding industrial environments. Engineers and system integrators deploy this unit across a wide range of applications:
- Conveyor & Material Handling Systems — operator control panels for start/stop, speed reference, and fault acknowledgment on belt and roller conveyors
- Packaging Machinery — line-speed control, batch counting, and recipe selection on form-fill-seal and cartoning equipment
- Pump & Compressor Stations — local operator interface for pressure setpoints, run/stop commands, and alarm display in water treatment and oil & gas facilities
- HVAC & Building Automation — zone control terminals integrated with MicroLogix or CompactLogix PLCs for temperature and airflow management
- Machine Tool & Assembly Lines — cycle initiation, parameter entry, and status monitoring on CNC-adjacent or semi-automatic assembly stations
- Food & Beverage Processing — wash-down-adjacent installations requiring a compact, keypad-driven interface with clear monochrome display readability
Technical Specifications
| Attribute | Value |
|---|---|
| Catalog Number | 2711C-K3M |
| Series | PanelView C300 |
| Display Type | Monochrome (Mono) |
| Interface Type | Keypad (no touchscreen) |
| Display Size | 3-inch diagonal |
| Communication | RS-232 / DH-485 (MicroLogix compatible) |
| Power Supply | 24V DC |
| Operating Temperature | 0 °C to 55 °C (32 °F to 131 °F) |
| Storage Temperature | -40 °C to 85 °C |
| Enclosure Rating | NEMA 4/4X, 12, 13 (panel-mount) |
| Weight | Approx. 300 g |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| SKU / Part Number | 2711C-K3M |
Why Engineers Specify This Model
- Proven MicroLogix Ecosystem Fit — native DH-485 communication makes the 2711C-K3M the default HMI pairing for MicroLogix 1000/1100/1400 controllers without additional gateways
- Compact Panel Footprint — 3-inch mono display fits standard cutouts in small enclosures where space is at a premium
- Keypad Reliability in Harsh Environments — no touchscreen glass to crack or degrade; membrane keypad withstands vibration, gloves, and contaminated environments
- Low Total Cost of Ownership — simple programming via PanelBuilder 300 software, minimal maintenance, and long field service life reduce lifecycle costs
- NEMA 4/4X Rating — suitable for wash-down and dust-laden environments without additional enclosure upgrades
- Established Spare Parts Availability — widely stocked globally, reducing downtime risk for maintenance teams managing aging MicroLogix-based lines
Complete System Bill of Materials
A typical MicroLogix-based control panel using the 2711C-K3M includes the following components:
- Allen-Bradley 2711C-K3M — PanelView C300 HMI (this unit)
- Allen-Bradley MicroLogix 1100 (1763-L16BWA) or MicroLogix 1400 (1766-L32BWA) — host PLC
- 1761-CBL-PM02 — RS-232 programming/communication cable (HMI to PLC)
- 1606-XLP30E — 24V DC power supply (30W, DIN-rail mount)
- 1492-J3 — DIN-rail terminal blocks for field wiring
- PanelBuilder 300 Software — HMI application development (Rockwell Automation)
- RSLogix 500 / Studio 5000 Logix Designer — PLC programming software
Compliance & Industry Standards
- UL Listed — UL 508 (Industrial Control Equipment)
- CE Marked — compliant with EU Low Voltage Directive and EMC Directive
- NEMA 4 / 4X / 12 / 13 — enclosure ingress protection ratings
- RoHS Compliant — restriction of hazardous substances per EU Directive 2011/65/EU
- CSA Certified — Canadian Standards Association approval for North American markets
Quality Assurance & Sourcing
Konmask.com sources the 2711C-K3M through established industrial distribution channels with full traceability. Every unit offered undergoes the following verification process:
- Visual inspection of housing, keypad membrane, and connector integrity
- Label and firmware version verification against Rockwell Automation documentation
- Functional power-on test where applicable
- Anti-static packaging and secure export carton for international shipment
We do not list units with missing labels, damaged connectors, or unverifiable provenance. Condition (new surplus, refurbished, or used) is explicitly stated in each listing.
How to Source This Part
- Add to Cart — click the purchase button above to place an order directly through Konmask.com
- Request a Quote — for bulk quantities (>5 units) or project-based procurement, email support@konmask.com with your project details and required delivery date
- Lead Time — in-stock units ship within 1–3 business days; out-of-stock units are subject to sourcing lead time (typically 5–15 business days)
- Export & International Orders — we ship globally; contact us for customs documentation, HS code confirmation, and freight options
- Payment — T/T bank transfer, PayPal, and major credit cards accepted; net terms available for qualified accounts
Application-Specific FAQ
Q: Is the 2711C-K3M compatible with CompactLogix or ControlLogix PLCs?
A: The 2711C-K3M communicates via DH-485 and RS-232, which are native to MicroLogix platforms. CompactLogix and ControlLogix use EtherNet/IP as their primary HMI protocol. For those platforms, a PanelView Plus or PanelView 800 series terminal is recommended. A protocol converter (e.g., ProSoft MVI46) can bridge DH-485 to ControlNet/EtherNet/IP in legacy retrofit scenarios.
Q: Can I use PanelBuilder 300 on Windows 10/11?
A: PanelBuilder 300 is a legacy application designed for Windows XP/7. Running it on Windows 10/11 typically requires compatibility mode or a virtual machine (VMware/VirtualBox with a Windows XP image). Rockwell Automation does not officially support PanelBuilder 300 on Windows 10/11.
Q: What is the difference between 2711C-K3M and 2711C-T3M?
A: The 2711C-K3M is the keypad-only variant; the 2711C-T3M is the touchscreen variant of the same PanelView C300 platform. Both share the same 3-inch mono display and DH-485 communication. Choose the keypad model for gloved-hand or high-vibration environments; choose the touchscreen model where graphical navigation is preferred.
Q: Is a replacement backlight or display available?
A: The PanelView C300 uses an LCD panel without a user-replaceable backlight in the field. Display replacement requires depot-level repair. Konmask.com can advise on repair service options or provide a replacement unit — contact us for details.
Q: What warranty applies to this unit?
A: Warranty terms depend on the condition of the unit as stated in the listing (new surplus, refurbished, or used). Please refer to the listing condition notes or contact support@konmask.com for specific warranty terms before purchase.
