Machine Control & Process Visualization Solution — Allen-Bradley 2711P-T6C5D | PanelView Plus 6
Where This Product Is Used
The Allen-Bradley 2711P-T6C5D PanelView Plus 6 Graphic Terminal is deployed across a wide range of industrial environments where operators require a reliable, compact human-machine interface (HMI) for real-time process monitoring and control. Typical application sites include:
- Automotive Assembly Lines — operator panels for conveyor control, torque monitoring, and station sequencing
- Food & Beverage Processing — batch recipe management, CIP cycle visualization, and line speed control
- Water & Wastewater Treatment — pump station monitoring, valve control, and alarm annunciation
- Packaging Machinery — OEM machine panels for fill-seal, labeling, and palletizing equipment
- HVAC & Building Automation — chiller plant control, AHU sequencing, and energy monitoring dashboards
- Oil & Gas Upstream/Midstream — wellhead control panels and compressor station HMI stations
- Pharmaceutical Manufacturing — GMP-compliant operator interfaces for mixing, filling, and sterilization processes
Technical Specifications
| Part Number | 2711P-T6C5D |
| Series | PanelView Plus 6 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Display Size | 6.5″ Color TFT LCD |
| Display Resolution | 640 × 480 (VGA) |
| Touch Screen | Analog Resistive Touch |
| Communication Ports | DH-485, RS-232 (DF1), USB Host & Device |
| Power Supply | 24V DC |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -20°C to 70°C |
| Enclosure Rating | NEMA 4/4X, 12, 13; IP65 (front face) |
| Memory | 512 MB Flash / 128 MB RAM |
| Weight | Approx. 840 g |
| Software | FactoryTalk View ME (compatible) |
| Catalog Number | 2711P-T6C5D |
Why Engineers Specify This Model
- Compact 6.5″ footprint — ideal for space-constrained control panels and OEM machine enclosures where larger terminals are impractical
- DH-485 native connectivity — direct integration with legacy SLC 500 and MicroLogix PLC networks without additional gateways
- FactoryTalk View ME compatibility — seamless application development within the Rockwell Automation software ecosystem, reducing engineering time
- NEMA 4X / IP65 front-face rating — suitable for wash-down environments in food processing and chemical plants
- Proven field reliability — widely deployed in installed base globally, with extensive third-party support and spare parts availability
- USB host port — enables on-site application updates and data logging without network access
Complete System Bill of Materials
For a fully operational PanelView Plus 6 control station, engineers typically specify the following complementary components:
- PLC / Controller: Allen-Bradley MicroLogix 1400 (1766-L32BWA) or SLC 5/05 (1747-L553)
- Communication Cable: 1761-CBL-PM02 (DH-485 to RS-232 adapter cable)
- Power Supply: 1606-XLP30E (24V DC, 30W panel-mount PSU)
- Panel Mounting Hardware: 2711P-RMCP (replacement mounting clips kit)
- Protective Overlay: 2711P-RL6C (replacement overlay for 2711P-T6C5D)
- USB Memory Module: Standard USB 2.0 flash drive (FAT32 formatted) for application backup
- Development Software: FactoryTalk View ME Studio (9.0 or later recommended)
Compliance & Industry Standards
- UL Listed (UL 508)
- CE Marked — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- NEMA 4, 4X, 12, 13 enclosure ratings
- IP65 (front panel ingress protection)
- RoHS Compliant
- cUL Listed (Canadian market)
- Compatible with ISA-101 HMI design guidelines
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley 2711P-T6C5D unit is subject to our multi-point verification process before dispatch:
- Authenticity Verification — units are inspected against Rockwell Automation OEM markings, label integrity, and firmware version consistency
- Functional Pre-check — power-on test and display verification performed on each unit
- Traceability — lot codes and date codes documented for full supply chain transparency
- Packaging Integrity — anti-static packaging with shock-absorbing foam for safe international transit
- Warranty — 12-month replacement warranty against manufacturing defects
We source from authorized distributors, certified surplus channels, and direct OEM relationships to ensure product authenticity and availability.
How to Source This Part
- Add to Cart — click the purchase button above to place your order directly
- Request a Quote — for volume orders (5+ units) or project-based procurement, contact us at support@konmask.com for preferential pricing
- Lead Time — in-stock units ship within 1–3 business days; ex-stock orders confirmed within 24 hours
- Export & Cross-border — we support international shipping with full commercial invoice, packing list, and HS code documentation (HS: 8537.10)
- Payment — T/T bank transfer, PayPal, and major credit cards accepted
Application-Specific FAQ
Q: Is the 2711P-T6C5D compatible with CompactLogix or ControlLogix PLCs?
A: The 2711P-T6C5D communicates natively via DH-485 and RS-232 (DF1). For EtherNet/IP connectivity to CompactLogix or ControlLogix, you would need a 2711P-T6C20D8 or higher model with an Ethernet port. A 1761-NET-ENI bridge can also be used as an adapter.
Q: Can I reuse an existing FactoryTalk View ME application from an older PanelView Plus terminal?
A: Yes. Applications developed in FactoryTalk View ME Studio are generally forward-compatible. Minor revision adjustments may be required for display resolution differences. Backup your .MER file before migration.
Q: What is the maximum number of tags supported?
A: The PanelView Plus 6 (600 series) supports up to 500 tags per application in FactoryTalk View ME, sufficient for most machine-level HMI applications.
Q: Is this unit suitable for hazardous (Ex) locations?
A: The standard 2711P-T6C5D is not ATEX or IECEx certified. For Zone 2 / Division 2 hazardous area installations, consult Rockwell Automation for purge-and-pressurization enclosure solutions.
Q: Do you provide programming or configuration services?
A: Konmask.com specializes in hardware supply. For FactoryTalk View ME application development services, we can refer you to certified Rockwell Automation system integrators in your region.
