Allen-Bradley 2711P-T6M20A — 6″ Grayscale Touch & Keypad HMI Terminal | PanelView Plus 600 Platform
Engineering Background
The PanelView Plus 600 series represents Rockwell Automation’s mid-range operator interface platform, engineered for demanding industrial environments where reliable human-machine interaction is non-negotiable. The 2711P-T6M20A variant combines a 6-inch grayscale display with both touch-screen and keypad input, offering redundant operator input paths that are critical in high-vibration or gloved-hand applications.
Product Positioning
Designed for OEM machine builders and plant-floor integrators operating within Allen-Bradley / Rockwell ecosystems, this terminal bridges legacy DH-485 networks and modern RS-232 serial architectures. It is a direct replacement for aging PanelView 600 units and a cost-effective alternative to full-color PanelView Plus 7 deployments where grayscale resolution is operationally sufficient.
Complete Technical Specifications
| Catalog Number | 2711P-T6M20A |
| Series | PanelView Plus 600 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Display Size | 6.0 inch (152 mm) diagonal |
| Display Type | STN Grayscale LCD |
| Resolution | 320 × 240 pixels (QVGA) |
| Input Method | Touch Screen + Function Keypad (combo) |
| Communication Ports | RS-232 (DH-485 via adapter), USB Type-A (host), USB Type-B (programming) |
| Network Protocol | DH-485, DF1, DeviceNet (via adapter) |
| Power Supply | 24 VDC nominal (18–32 VDC range) |
| Power Consumption | ≤ 18 W typical |
| Operating Temperature | 0 °C to +55 °C (32 °F to 131 °F) |
| Storage Temperature | −40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Enclosure Rating | NEMA 4/4X, 12, 13 (front face); IP65 (front face) |
| Vibration | 2 g, 10–500 Hz (operating) |
| Shock | 15 g, 11 ms half-sine |
| Memory | 32 MB Flash application storage |
| Runtime Software | FactoryTalk View ME (pre-installed) |
| Development Software | FactoryTalk View Studio ME (PC-side) |
| Panel Cutout | Per Rockwell Automation installation drawing |
| Weight | Approx. 900 g |
| Certifications | UL, CE, C-Tick |
Proven Application Environments
- Discrete Manufacturing: Assembly line operator stations, conveyor control panels, and press machine interfaces where gloved-hand keypad input is required.
- Food & Beverage: Washdown-tolerant (IP65 front face) HMI for filling, packaging, and mixing lines operating under NEMA 4X requirements.
- Water & Wastewater: Pump station and filtration system control panels with DH-485 network integration to legacy SLC 500 / MicroLogix PLCs.
- Material Handling: Palletizer, sorter, and AGV docking station interfaces requiring compact panel footprint.
- OEM Machine Retrofit: Drop-in replacement for PanelView 600 (2711-T6C8) units, preserving existing panel cutout and wiring.
- Utilities & Energy: Substation auxiliary control panels where color display is not mandated and grayscale readability under ambient light is sufficient.
Engineering Advantages
- Dual Input Redundancy: Touch screen and function keypad operate independently — operators can switch input modes without software reconfiguration, reducing downtime risk.
- Legacy Network Compatibility: Native DH-485 support (via 2711P-CBL-EX04 cable) allows direct integration with SLC 500, MicroLogix 1000/1100/1400, and PLC-5 controllers without gateway hardware.
- FactoryTalk View ME Ecosystem: Full compatibility with Rockwell’s FactoryTalk View Studio ME development environment — existing application files (.MER) transfer without modification.
- Compact 6″ Form Factor: Fits standard NEMA 4/12 enclosure cutouts; smaller footprint than 10″ or 12″ alternatives reduces panel real estate cost.
- Extended Temperature Range: 0–55 °C operating range covers most non-climate-controlled industrial environments without additional cooling.
- USB Host Port: Enables runtime data logging to USB flash drive and firmware updates without PC connection to the terminal.
System Architecture & Signal Flow
The 2711P-T6M20A operates as a FactoryTalk View ME runtime client. Application logic resides on the connected PLC (SLC 500, MicroLogix, or ControlLogix via serial bridge); the terminal reads tag values and writes operator commands over the configured communication driver.
- Typical Topology: PLC ↔ DH-485 network ↔ 2711P-CBL-EX04 serial cable ↔ 2711P-T6M20A RS-232 port
- Tag Database: Tags are defined in FactoryTalk View Studio ME and compiled into the .MER application file loaded onto the terminal’s 32 MB Flash.
- Alarm Management: Supports FactoryTalk Alarms & Events (local) with alarm history logging to USB or internal memory.
- Screen Navigation: Up to 500 display objects per screen; navigation buttons configurable via keypad function keys or touch targets.
- Power Architecture: Single 24 VDC input; internal DC-DC converter supplies display backlight and logic board. No external backlight power required.
Sourcing & Quality Verification
All units offered through Konmask.com undergo a structured incoming inspection protocol before listing:
- Visual inspection: enclosure integrity, keypad tactile response, display surface condition, connector pin check
- Power-on test: 24 VDC applied, FactoryTalk View ME runtime boot confirmed, display uniformity verified
- Communication port test: RS-232 loopback and USB host enumeration confirmed
- Nameplate verification: catalog number, series letter, and firmware revision cross-referenced against Rockwell Automation product records
- Packaging: anti-static bag, foam-lined carton, humidity indicator card included
Units are sourced from decommissioned OEM equipment, authorized distributor surplus, and verified secondary-market channels. Counterfeit screening follows IEC 62239-1 traceability principles.
Procurement Process
- Step 1 — Inquiry: Contact support@konmask.com or call +0086 19859288691 with your catalog number, required quantity, and delivery timeline.
- Step 2 — Quote: We issue a formal quotation within 1 business day including unit price, lead time, and shipping options (DHL Express / FedEx International Priority).
- Step 3 — Order Confirmation: Purchase order or online checkout accepted. Proforma invoice issued for T/T wire transfer customers.
- Step 4 — Inspection & Dispatch: Unit re-inspected, photographed, and dispatched with tracking number within 1–3 business days of payment confirmation.
- Step 5 — After-Sales: 90-day DOA warranty. Technical support available via email for integration questions.
Technical FAQ
- Q: Can the 2711P-T6M20A communicate directly with a ControlLogix PLC?
- A: Not natively over Ethernet. A serial-to-Ethernet bridge (e.g., 1761-NET-ENI) or a ControlLogix serial module (1756-DHRIO) is required to bridge DH-485/DF1 to the ControlLogix backplane.
- Q: Is this unit compatible with FactoryTalk View ME v8.x and v9.x?
- A: Yes. The 2711P-T6M20A supports FactoryTalk View ME runtime versions 5.x through 9.x. Firmware upgrades are applied via USB flash drive using the terminal’s firmware upgrade utility.
- Q: What is the panel cutout dimension?
- A: Refer to Rockwell Automation installation drawing 2711P-IN006 for exact cutout dimensions. Typically 192 mm × 138 mm (W × H) for the 6″ PanelView Plus 600 series.
- Q: Can existing PanelView 600 (2711-T6C8) application files be used?
- A: No direct migration. PanelView 600 applications (.PVP format) must be converted using the PanelView Plus Transfer Utility to FactoryTalk View ME (.MER) format before loading onto the 2711P-T6M20A.
- Q: What is the backlight lifespan?
- A: Rockwell Automation specifies approximately 50,000 hours MTBF for the CCFL backlight under normal operating conditions. Backlight replacement kits are available as a service part.
- Q: Does Konmask offer volume pricing?
- A: Yes. Volume discounts apply for orders of 3+ units. Contact support@konmask.com for a tiered pricing schedule.
