Process Automation & DCS Control Solution – ABB 32GAC00000P5H0XXX-02S13340000 | AC800M Series
Where This Product Is Used
The ABB 32GAC00000P5H0XXX-02S13340000 is a high-performance DCS controller module from the AC800M Series, engineered for demanding continuous process control environments. Typical deployment scenarios include:
- Oil & Gas Processing: Pipeline SCADA systems, compressor station control, wellhead automation, and refinery DCS backbone infrastructure.
- Chemical & Petrochemical Plants: Reactor temperature/pressure loop control, batch sequencing, and safety instrumented system (SIS) integration.
- Power Generation: Boiler management systems (BMS), turbine governor control, and grid-tie synchronization logic.
- Pulp & Paper Mills: Digester control, bleaching sequence automation, and multi-drive coordination.
- Water & Wastewater Treatment: Pump station automation, dosing control, and SCADA remote I/O management.
- Mining & Minerals Processing: Flotation cell control, conveyor interlocking, and crusher load management.
- Pharmaceutical Manufacturing: GMP-compliant batch control, clean-in-place (CIP) sequencing, and audit-trail logging.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 32GAC00000P5H0XXX-02S13340000 |
| Brand / Manufacturer | ABB |
| Series | AC800M |
| Module Type | DCS Controller Module |
| Communication Interface | MMS / IEC 61850 / Profibus / Modbus TCP |
| Operating Voltage | 24 V DC (nominal) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Protection Rating | IP20 |
| Weight | 340 g |
| Certifications | CE, UL, cUL, ATEX (zone 2 rated variants) |
| Mounting | DIN rail / rack-mount backplane |
Note: Full datasheet available upon request. Contact support@konmask.com for detailed electrical specifications.
Why Engineers Specify This Model
- Proven AC800M Platform: Part of ABB’s flagship DCS family with global installed base exceeding 100,000 systems — engineers trust its reliability in 24/7 continuous operations.
- Redundancy-Ready Architecture: Supports hot-standby CPU redundancy for zero-downtime failover, critical in SIL-rated process loops.
- Scalable I/O Expansion: Seamlessly integrates with S800 I/O modules, enabling flexible system expansion without re-engineering the control backbone.
- Open Communication Standards: Native support for OPC UA, Profibus DP, FOUNDATION Fieldbus, and Modbus TCP reduces integration complexity with third-party instruments.
- Long Product Lifecycle: ABB’s extended support commitment ensures spare parts availability and firmware updates for 10+ years post-installation.
- Deterministic Scan Cycle: Guaranteed cycle time performance ensures precise loop control in fast-response applications such as compressor surge control.
Complete System Bill of Materials
For a complete AC800M DCS control node, engineers typically specify the following alongside the 32GAC00000P5H0XXX-02S13340000:
- S800 I/O Modules – AI810, AO810, DI810, DO810 for analog and digital field signals
- CI854 / CI857 – Profibus DP / FOUNDATION Fieldbus communication interface modules
- PM866 / PM891 – Redundant processor modules for hot-standby configurations
- TB820 / TB840 – ModuleBus optical modem for remote I/O cluster connections
- SD802 / SD823 – Power supply modules (24 V DC redundant)
- 800xA System Software – ABB’s Distributed Control System engineering and operator station platform
Contact support@konmask.com for complete BOM assistance and cross-reference support.
Compliance & Industry Standards
- IEC 61131-3 – Programmable controller programming languages
- IEC 61850 – Communication networks and systems for power utility automation
- IEC 61511 / IEC 61508 – Functional safety (SIL 1–3 capable configurations)
- CE Marking – EU electromagnetic compatibility and low voltage directives
- UL / cUL Listed – North American safety certification
- RoHS Compliant – Restriction of hazardous substances
- ATEX / IECEx – Zone 2 hazardous area rated (specific variants)
Quality Assurance & Sourcing
Konmask.com sources the ABB 32GAC00000P5H0XXX-02S13340000 through verified industrial supply channels. Every unit undergoes:
- Visual inspection and label authenticity verification
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator cards
- Traceability documentation (lot number, date code, origin)
We supply both new OEM stock and factory-refurbished units with warranty. Condition is clearly stated on each order confirmation.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity and delivery timeline.
- Phone / WhatsApp: Call or message +0086 19859288691 for urgent requirements.
- Add to Cart: Use the button above for standard stock orders with online checkout.
- Lead Time: In-stock items ship within 1–3 business days. Special-order items: 2–4 weeks.
- Export Documentation: We provide commercial invoices, packing lists, and CO certificates for international shipments.
Application-Specific FAQ
Q: Can the 32GAC00000P5H0XXX-02S13340000 be used in a SIL 2 safety loop?
A: The AC800M platform supports SIL-rated configurations when combined with ABB’s Safety Module and certified I/O. Consult your functional safety engineer for the specific SIL assessment of your loop.
Q: Is this module compatible with ABB 800xA version 6.x?
A: Yes. The AC800M controller family is fully supported under 800xA v6.0 and later. Firmware compatibility should be verified against your specific 800xA release notes.
Q: Can I use this controller with third-party SCADA systems (e.g., Wonderware, Ignition)?
A: Yes, via OPC DA/UA server interfaces. The AC800M exposes process data through ABB’s OPC server, which is compatible with all major SCADA platforms.
Q: What is the maximum number of I/O points supported?
A: A single AC800M controller node supports up to 12,800 I/O points via S800 remote I/O clusters, depending on the processor variant and communication modules used.
Q: Do you offer exchange or repair services?
A: Yes. Konmask.com offers board-level repair and exchange programs for AC800M modules. Contact us for pricing and turnaround time.
