Industrial Current Sensing Solution – WOODWARD 5466-026 | NETCON Series
In power generation and turbine control environments, accurate real-time current measurement is not optional — it is the foundation of safe, stable operation. The WOODWARD 5466-026 NETCON Duplex Current Input module delivers dual-channel analog current acquisition engineered specifically for WOODWARD’s NETCON distributed control platform, trusted by plant engineers across gas turbines, steam turbines, and generator protection systems worldwide.
When a turbine control loop demands sub-millisecond signal fidelity and zero cross-channel interference, the 5466-026 is the module engineers specify by name.
Where This Product Is Used
The WOODWARD 5466-026 is deployed in mission-critical environments where duplex (redundant) current signal acquisition is mandatory:
- Gas Turbine Control Systems — Fuel flow metering, compressor inlet current monitoring, and load-sharing feedback loops in GE, Siemens, and Solar Turbines installations running WOODWARD NETCON controllers.
- Steam Turbine Governor Systems — Speed and load current feedback for steam admission valve control in combined-cycle power plants (CCPP).
- Generator Protection Panels — Differential current sensing for generator stator protection, integrated with NETCON-based excitation control.
- Compressor Control Cabinets — Anti-surge and performance control loops in centrifugal and axial compressors at LNG terminals and petrochemical plants.
- Marine Propulsion Control — Dual-redundant current input for diesel-electric propulsion management systems on offshore vessels and naval platforms.
- Hydro Turbine Governors — Gate position current feedback in hydroelectric generating units with WOODWARD NETCON architecture.
If your facility runs WOODWARD NETCON and requires certified duplex analog input capability, the 5466-026 is the OEM-specified solution.
Technical Specifications
| Manufacturer | WOODWARD |
| Part Number | 5466-026 |
| Series / Platform | NETCON Distributed Control System |
| Module Type | Duplex Current Input |
| Channel Configuration | Dual-channel (Duplex / Redundant) |
| Input Signal Type | Analog Current (4–20 mA standard range) |
| Signal Isolation | Galvanic isolation per channel |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C |
| Power Supply | Via NETCON backplane bus |
| Form Factor | NETCON rack-mount plug-in module |
| Weight | 940 g |
| Compliance | CE, UL, IEC 61511 (SIL-capable platform) |
| Condition Available | New OEM / Tested Surplus / Refurbished |
Note: Specifications are based on WOODWARD published documentation. Contact Konmask for datasheet confirmation prior to installation in safety-critical loops.
Why Engineers Specify This Model
- True Duplex Architecture — Both channels operate simultaneously with independent signal paths, enabling hot-standby redundancy without external switching hardware.
- NETCON Native Compatibility — Plug-and-play integration with WOODWARD NETCON racks; no firmware patching or custom configuration required.
- Galvanic Channel Isolation — Eliminates ground loops and common-mode noise that corrupt analog readings in high-EMI turbine environments.
- High Signal Fidelity — Precision ADC conversion maintains accuracy across the full 4–20 mA range, critical for tight governor control loops.
- Proven Field Reliability — Deployed in continuous-duty power generation assets with MTBF ratings consistent with WOODWARD’s industrial-grade component standards.
- Direct OEM Replacement — Identical form, fit, and function to factory-installed units; no re-engineering of existing NETCON cabinets.
Complete System Bill of Materials
The 5466-026 operates within the WOODWARD NETCON ecosystem. A complete current input subsystem typically includes:
- 5466-026 — Duplex Current Input Module (this item)
- NETCON Rack / Chassis — WOODWARD backplane rack (5462-xxx series) providing power and communication bus
- NETCON Power Supply Module — Redundant 24 VDC or 48 VDC supply module
- NETCON CPU / Controller Module — Central processing unit for control logic execution
- Field Wiring Terminal Assembly — Screw-terminal or D-sub field connection interface
- Current Transmitters (Field Side) — 4–20 mA loop-powered transmitters (pressure, flow, temperature, position)
- NETCON Configuration Software — WOODWARD ToolKit or equivalent for module parameterization
Contact Konmask to source complete NETCON system assemblies or individual replacement modules.
Compliance & Industry Standards
- CE Marking — Electromagnetic compatibility and low-voltage directive compliance for EU installations
- UL Listing — Underwriters Laboratories recognition for North American industrial applications
- IEC 61511 / IEC 61508 — NETCON platform supports Safety Instrumented System (SIS) applications; consult WOODWARD SIL documentation for loop-specific validation
- IEC 61000-4 Series — EMC immunity standards for industrial environments (ESD, EFT, surge, conducted RF)
- ISO 9001 — WOODWARD manufacturing facilities operate under ISO 9001 quality management systems
- API 670 / API 612 — Compatible with turbine protection and control system requirements per American Petroleum Institute standards
Quality Assurance & Sourcing
Konmask sources WOODWARD 5466-026 modules through verified industrial supply channels with full traceability:
- OEM New Stock — Factory-sealed units with original WOODWARD packaging and documentation where available
- Tested Surplus — Decommissioned units from controlled plant shutdowns, functionally tested to WOODWARD specifications before listing
- Refurbished / Reconditioned — Professionally restored units with component-level inspection, cleaning, and burn-in testing
- Counterfeit Screening — All units undergo visual inspection, marking verification, and functional bench testing; counterfeit or non-conforming parts are rejected and destroyed
- Traceability Documentation — Test reports, inspection certificates, and chain-of-custody records available upon request
- Warranty — 12-month operational warranty on all tested and refurbished units; OEM new units carry manufacturer warranty
How to Source This Part
- Confirm Part Number — Verify 5466-026 against your NETCON rack label, cabinet drawing, or WOODWARD BOM. Cross-reference with any suffix variants (e.g., -026A, -026B) if applicable.
- Submit Inquiry — Contact Konmask via email or phone with your required quantity, condition preference (new / surplus / refurbished), and delivery timeline.
- Receive Quotation — We provide pricing, lead time, and available condition within 24 business hours.
- Order Confirmation — Purchase order accepted via email; proforma invoice issued for prepayment or net terms (qualified accounts).
- Inspection & Dispatch — Unit inspected, photographed, and packed to IPC/JEDEC anti-static standards before shipment.
- Delivery & Support — Tracked international shipping with DHL / FedEx / UPS; Konmask technical team available for installation guidance post-delivery.
Typical lead time: In-stock units ship within 3–5 business days. Sourced units: 7–21 business days depending on origin.
Application-Specific FAQ
Q: Can the 5466-026 replace a single-channel current input module in my NETCON rack?
A: The 5466-026 is a duplex (dual-channel) module. It occupies a single rack slot but provides two independent input channels. Verify your rack slot assignment and NETCON configuration file before substituting for a single-channel variant.
Q: Is the 5466-026 compatible with WOODWARD NETCON II and NETCON III platforms?
A: Compatibility depends on the specific NETCON generation and backplane revision. Konmask recommends providing your full NETCON system part number and software version for confirmation before ordering.
Q: Can this module accept 0–20 mA or 0–10 V signals?
A: The 5466-026 is designed for 4–20 mA current loop inputs. For voltage input or alternative current ranges, consult WOODWARD’s NETCON analog input module catalog for the appropriate variant.
Q: What happens if one channel fails in duplex mode?
A: In a properly configured NETCON duplex loop, the controller detects the channel fault via diagnostics and continues operating on the healthy channel. Alarm annunciation and failover behavior depend on your NETCON application software configuration.
Q: Do you provide a test report with the module?
A: Yes. All surplus and refurbished units shipped by Konmask include a functional test report. OEM new units include WOODWARD factory documentation where available.
Q: Can Konmask supply the complete NETCON rack assembly?
A: Yes. Konmask specializes in complete WOODWARD NETCON system sourcing including racks, CPU modules, I/O modules, and power supplies. Contact us with your full BOM for a consolidated quotation.
