ABB 3BHE028915R0101 PCD237 A101 Controller Board | Replacement, Equivalent & Selection Guide
The ABB 3BHE028915R0101 (PCD237 A101) is a high-performance controller board designed for ABB’s industrial automation and drive control systems. This page provides full technical specifications, verified compatible replacements, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number: 3BHE028915R0101
- Series / Module Code: PCD237 A101
- Manufacturer: ABB
- Type: Controller Board / Control Card
- Application: ABB ACS / ACS800 / ACS880 series drive control; DCS / PLC auxiliary control
- Form Factor: PCB plug-in module
- Weight: approx. 2,300 g (packaged)
- Condition Available: New Original / Tested Surplus / Refurbished
- Country of Origin: Sweden / Finland (ABB manufacturing)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or cross-references for the 3BHE028915R0101. Always verify firmware version and hardware revision compatibility before substitution:
- ABB 3BHE024577R0101 – PCD231 series, same drive platform, verify I/O mapping
- ABB 3BHE022294R0101 – PCD235 variant, compatible in select ACS800 configurations
- ABB 3BHE028915R0102 – Revision R0102, functionally equivalent with minor firmware update
- ABB 3BHE028915R0001 – Earlier revision, confirm compatibility with target drive firmware
- Third-party OEM equivalents – Available on request; Konmask verifies pin-out and signal compatibility prior to shipment
Note: Cross-reference data is provided for reference only. Konmask.com recommends engineering validation before field replacement.
Why Choose the Original Model
- ✅ Factory-calibrated – ABB OEM boards ship pre-configured for target drive series
- ✅ Firmware integrity – Original part retains certified firmware; no re-flashing required
- ✅ Warranty alignment – Using OEM parts preserves ABB system warranty and service agreements
- ✅ Long service life – Industrial-grade components rated for continuous 24/7 operation
- ✅ Reduced commissioning risk – Drop-in replacement with no parameter re-mapping
Typical Applications
- ABB ACS800 / ACS880 variable frequency drive (VFD) control boards
- ABB DCS800 DC drive controller replacement
- Industrial motor control centers (MCC) and drive cabinets
- Power generation and utilities automation
- Oil & gas, petrochemical plant control systems
- Pulp & paper, cement, and mining process automation
- Water treatment and HVAC drive control
System Compatibility
- Drive Series: ABB ACS800, ACS880, DCS800
- Control Platform: ABB RDCU / RMIO / AINT control units
- Communication: DDCS fiber-optic, PROFIBUS, Modbus RTU (configuration-dependent)
- Power Supply: 24 VDC auxiliary (internal bus-powered)
- Operating Temperature: 0 °C to +55 °C (standard industrial rating)
- Standards: CE, UL, IEC 61800 series compliance
Selection Guide
Use the following decision matrix to select the correct board for your application:
- Step 1 – Identify drive model: Confirm your ABB drive series (ACS800 / ACS880 / DCS800) and firmware version from the drive nameplate or parameter list.
- Step 2 – Match hardware revision: The suffix R0101 denotes hardware revision; ensure the replacement matches or is backward-compatible.
- Step 3 – Verify I/O requirements: Confirm digital/analog I/O count and communication protocol match your system design.
- Step 4 – Check lead time vs. urgency: New OEM stock offers longest life; tested surplus is available for immediate dispatch.
- Step 5 – Contact Konmask: Send your drive nameplate data and we will confirm exact compatibility before order.
Quality Assurance & Sourcing
- 🔍 100% functional test before shipment on all surplus and refurbished units
- 📦 Anti-static ESD packaging with moisture barrier and shock-absorbing foam
- 🏭 Traceable supply chain – sourced from authorized distributors, OEM overstock, and decommissioned plant equipment
- 📋 Certificate of conformance available on request
- 🔄 12-month warranty on all tested and refurbished units
- 🚀 Global shipping – DHL / FedEx / UPS express available; export documentation included
How to Order
- Add to cart directly, or contact us with your drive nameplate data for compatibility confirmation.
- Specify required condition: New Original / Tested Surplus / Refurbished.
- Provide shipping destination for freight quote and lead time confirmation.
- Payment: T/T bank transfer, PayPal, or credit card accepted.
- Dispatch: typically 1–3 business days after payment confirmation.
📧 Email: [email protected]
📞 Phone / WhatsApp: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can 3BHE028915R0102 replace 3BHE028915R0101?
A: In most cases yes — R0102 is a minor hardware revision. Confirm firmware compatibility with your drive version before swapping.
Q: Is a third-party equivalent safe to use?
A: Third-party boards can work in non-critical applications, but OEM is always recommended for safety-critical or warranty-covered systems.
Q: Do you provide a test report?
A: Yes. A functional test report is available for all surplus and refurbished units upon request.
Q: What is the lead time for new OEM stock?
A: New OEM units typically ship within 5–15 business days depending on ABB factory availability. Surplus stock ships within 1–3 days.
Q: Can you help identify the correct replacement if I only have the drive model?
A: Absolutely. Send us your drive model, serial number, and firmware version and our engineers will identify the correct board.
