ABB 3HAC030006-004 – Rotational AC Motor with Pinion | IRB 2600 Robot Platform
Engineering Background: The ABB IRB 2600 is a high-performance industrial robot widely deployed in arc welding, material handling, machine tending, and assembly automation. Its axis drive system relies on precision AC servo motors to deliver the repeatability and torque density demanded by 24/7 production environments. The 3HAC030006-004 is the OEM rotational AC motor assembly—complete with integrated pinion gear—designed as a direct replacement unit for axis drives on the IRB 2600 platform.
Product Positioning: Sourced through verified ABB-authorized supply channels, this motor assembly is the correct specification for maintenance engineers and system integrators requiring a drop-in replacement with zero re-commissioning overhead. Konmask.com stocks this part to support rapid MRO (Maintenance, Repair & Operations) turnaround for production-critical robot cells.
Complete Technical Specifications
- OEM Part Number: 3HAC030006-004
- Cross-Reference SKU: IRB26003HAC069650-001 / 1-63HAC030006-004
- Compatible Platform: ABB IRB 2600 Series (all variants)
- Motor Type: Rotational AC Servo Motor with Integrated Pinion
- Manufacturer: ABB Robotics (Sweden)
- Application: Axis drive replacement – IRB 2600 robot arm
- Pinion: Included (factory-assembled, pre-aligned)
- Condition: New / Refurbished (specify at inquiry)
- HS Code: 8501.52 (AC motors, multi-phase)
- Country of Origin: Sweden
Proven Application Environments
- Arc welding robot cells (automotive body-in-white)
- Machine tending and CNC load/unload automation
- Material handling and palletizing lines
- Assembly and press-fit operations
- Food & beverage packaging (IP-rated enclosure variants)
- Electronics manufacturing and PCB handling
Engineering Advantages
- OEM Specification: Exact ABB factory part — no adaptation or re-parameterization required upon installation.
- Integrated Pinion Assembly: Pre-mounted pinion eliminates field alignment errors and reduces MTTR (Mean Time To Repair).
- Direct Drop-In Replacement: Plug-and-play compatibility with existing IRB 2600 axis drive housings and motor connectors.
- High Torque Density: Engineered for the dynamic load profiles of 6-axis articulated robot arms in continuous-duty cycles.
- Thermal Stability: Designed to operate within ABB’s validated thermal envelope for the IRB 2600 drive train.
System Architecture & Signal Flow
The 3HAC030006-004 motor interfaces directly with the ABB IRC5 controller drive module via the robot’s internal motor cable harness. The integrated pinion meshes with the axis gearbox input stage, transmitting torque from the motor shaft to the joint reduction gear. Encoder feedback is routed through the SMB (Serial Measurement Board) to the drive unit, enabling closed-loop position and velocity control. Replacement of this unit requires axis calibration via RobotStudio or the FlexPendant after installation.
Sourcing & Quality Verification
- All units sourced through ABB-authorized distributors or certified MRO supply chains.
- Each unit undergoes incoming inspection: visual, dimensional, and electrical continuity checks.
- Traceability documentation (batch/lot records) available upon request for regulated industries.
- Packaging: anti-static, moisture-barrier sealed with desiccant — compliant with IEC 60068 transport standards.
- Warranty: 90-day replacement warranty against manufacturing defects (terms apply).
Procurement Process
- Submit Inquiry: Email support@konmask.com with your robot serial number and required quantity.
- Quotation: Receive a formal quotation with lead time and shipping options within 1 business day.
- Order Confirmation: Confirm PO; payment via T/T, PayPal, or trade credit (approved accounts).
- Dispatch: Ships via DHL Express / FedEx International Priority with full tracking.
- Installation Support: Technical guidance available via email or video call for qualified engineers.
Technical FAQ
Q: Is this motor compatible with IRB 2600-12/1.65 and IRB 2600-20/1.65 variants?
A: Compatibility depends on the specific axis and robot configuration. Please provide your robot’s serial number and axis number for confirmation before ordering.
Q: Does installation require ABB service authorization?
A: ABB recommends that motor replacement be performed by trained personnel. Axis calibration is mandatory post-installation and requires RobotStudio or FlexPendant access.
Q: Can you supply the matching gearbox or motor cable harness?
A: Yes. Konmask stocks a range of IRB 2600 drive train components. Contact us with your full BOM for a consolidated quotation.
Q: What is the lead time for this part?
A: In-stock units ship within 2–3 business days. Ex-stock lead time is typically 2–4 weeks depending on ABB supply chain status.
