ABB 3HAC057285-001 Robot Servo Armature – IRB Series Industrial Robot Component
When a servo armature fails inside an ABB industrial robot, the entire production line comes to a halt. Automotive welding cells, electronics assembly stations, and precision material-handling systems all depend on the continuous, accurate torque delivery that only a correctly specified armature can provide. A worn or damaged armature introduces positional drift, overheating, and ultimately unplanned downtime that costs manufacturers thousands of dollars per hour. The ABB 3HAC057285-001 servo armature is the factory-designated replacement that restores full motion performance without the risk of compatibility guesswork.
The 3HAC057285-001 occupies a critical position within ABB’s IRB-series robot spare-parts ecosystem. Carrying the companion part reference 024290200 and the extended designation 14D36-ESOPRS0P1-B19N-ST6S00N-ROSO, this armature is engineered to ABB’s exacting tolerances for winding resistance, insulation class, and dynamic balance. As one of the world’s leading industrial-robot OEMs, ABB supplies this component to maintenance teams across automotive, food & beverage, semiconductor, and heavy-industry sectors globally, making it one of the most sought-after servo spare parts in the international automation market.
Technical Specifications
- Part Number: 3HAC057285-001
- Alternate Reference: 024290200
- Extended Designation: 14D36-ESOPRS0P1-B19N-ST6S00N-ROSO
- Manufacturer: ABB Robotics
- Component Type: Servo Motor Armature (Rotor Assembly)
- Compatible Platform: ABB IRB Series Industrial Robots
- Weight: 600 g (approx.)
- Condition: New / Surplus New / Refurbished (specify on inquiry)
Note: Additional electrical and mechanical specifications (winding resistance, insulation class, shaft dimensions) are available upon request. We do not publish unverified parameters.
Key Features & Benefits
- OEM-Grade Precision: Manufactured to ABB’s original design tolerances, ensuring drop-in compatibility with no field modification.
- Restored Motion Accuracy: Correct dynamic balance and winding symmetry eliminate positional drift and vibration that degrade path accuracy.
- Thermal Reliability: High-grade insulation materials maintain performance across the full operating temperature range of ABB servo drives.
- Reduced Downtime Risk: A verified OEM part number eliminates the sourcing uncertainty that comes with generic or unbranded alternatives.
- Global Availability: Stocked and ready to ship worldwide, minimizing lead time for urgent maintenance situations.
Industry & Equipment Applications
- Automotive Manufacturing: Spot-welding robots, body-in-white assembly, and paint-shop handling arms.
- Electronics & Semiconductor: PCB handling, chip placement, and cleanroom pick-and-place systems.
- Food & Beverage: High-speed packaging, palletizing, and hygienic material transfer lines.
- Metal Fabrication: Arc welding, laser cutting, and press-tending robot cells.
- Logistics & Warehousing: Automated sorting, depalletizing, and goods-to-person fulfillment robots.
System Integration & Compatible Parts
The 3HAC057285-001 armature is designed to work within ABB’s servo motor and drive ecosystem. When performing a servo motor overhaul, consider sourcing the following complementary components to ensure a complete and reliable repair:
- ABB servo motor stator assembly (consult robot model BOM)
- ABB servo drive / axis computer module
- ABB resolver or encoder feedback unit
- ABB motor cable and connector kit
- ABB robot controller (IRC5 / OmniCore series)
Contact our technical team with your robot model and axis number for a complete compatible-parts list.
Our Quality Assurance Process
- Source Verification: All parts are sourced from authorized ABB distributors, certified MRO suppliers, or directly from decommissioned OEM equipment.
- Visual & Dimensional Inspection: Each armature is inspected for winding integrity, shaft condition, and label authenticity before dispatch.
- Traceability: Part numbers, lot codes, and supplier documentation are retained for every shipment.
- Secure Packaging: Anti-static and shock-resistant packaging protects precision components during international transit.
How to Order
- Submit an inquiry via the Contact / RFQ form on this page, or email [email protected].
- Provide your robot model, serial number, and required quantity for fastest response.
- Receive a formal quotation with lead time, shipping options, and payment terms within 24 business hours.
- Confirm the order and receive tracking information upon dispatch.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, servo, and robot spare parts — not general electronics.
- Verified Part Numbers: Every listing is cross-referenced against OEM documentation to ensure accuracy.
- Responsive B2B Service: Dedicated account managers for MRO buyers, system integrators, and OEM service teams.
- Global Shipping: DHL, FedEx, and UPS express options to 150+ countries with full export documentation.
- Competitive Pricing: Request a quote — volume discounts available for maintenance contracts and project orders.
Frequently Asked Questions
- Q: Is the 3HAC057285-001 a new or refurbished part?
- A: We stock both new and professionally refurbished units. Please specify your preference when submitting an inquiry, and we will confirm availability and pricing accordingly.
- Q: Which ABB robot models use this armature?
- A: This part is associated with the ABB IRB series. Please provide your specific robot model and axis number so our engineers can confirm compatibility before you order.
- Q: What is the lead time for international orders?
- A: In-stock items typically ship within 1–3 business days. Express delivery to most destinations takes 3–7 business days via DHL or FedEx.
- Q: Can you provide a certificate of conformance or test report?
- A: Yes. Documentation packages including inspection reports and supplier certificates are available upon request for quality-critical applications.
- Q: Do you accept returns if the part is not compatible?
- A: We strongly recommend confirming compatibility via our technical team before ordering. Returns are handled case-by-case; please review our returns policy or contact support.
