ABB ASDI-03 (3HNA010255-001) – Paint Robot Axis Computer Board | IRC5P Controller Platform
Engineering Background: The ABB IRC5P (Integrated Robot Controller for Paint) platform powers the majority of ABB’s automotive and industrial spray-painting robot installations worldwide. At the heart of its motion control architecture sits the Axis Computer board — the dedicated DSP-based module responsible for real-time servo loop closure, encoder feedback processing, and coordinated multi-axis trajectory execution.
Product Positioning: The ABB ASDI-03 (Part No. 3HNA010255-001) is the third-generation Axis Computer board designed exclusively for IRC5P paint robot controllers. It replaces earlier ASDI-01/02 revisions and delivers enhanced noise immunity and faster cycle times critical in solvent-rich spray booth environments. Procurement engineers sourcing MRO replacements or spare-parts inventory for ABB IRB 5500, IRB 580, and IRB 52 paint robots will find this module a direct, plug-and-play fit.
Complete Technical Specifications
- Part Number: 3HNA010255-001
- ABB Ordering Code: ASDI-03
- Compatible Controller: ABB IRC5P (Paint Robot Controller)
- Compatible Robot Models: IRB 5500, IRB 580, IRB 52 series
- Module Function: Axis Computer — real-time servo control & encoder interface
- Communication Bus: Internal DSQC backplane (proprietary ABB)
- Axes Supported: Up to 6 robot axes + external axes
- Processor Architecture: DSP-based real-time motion processor
- Operating Voltage: 24 VDC (supplied via controller backplane)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: -25 °C to +70 °C
- Humidity: 5–95% RH, non-condensing
- Weight: 560 g (approx.)
- Form Factor: PCB card, IRC5P cabinet slot-mount
- Firmware: Compatible with RobotWare 5.x / 6.x (IRC5P variant)
- Certifications: CE (as part of IRC5P system)
- Country of Origin: Sweden / EU (ABB Robotics)
Proven Application Environments
- Automotive OEM paint shops — body-in-white and exterior topcoat spray lines
- Tier-1 automotive supplier coating booths
- Industrial appliance and furniture spray-painting cells
- Aerospace component surface treatment lines
- General industrial robotic dispensing and sealing applications
Engineering Advantages
- Third-Generation Design: ASDI-03 supersedes ASDI-01 and ASDI-02 with improved EMI shielding — essential in high-voltage electrostatic spray environments.
- Real-Time Servo Closure: Dedicated DSP ensures deterministic <1 ms servo loop execution, maintaining path accuracy at high TCP speeds.
- Direct Drop-In Replacement: Mechanically and electrically compatible with existing IRC5P cabinet slots — no firmware re-flashing required when replacing same-generation boards.
- Encoder Redundancy Support: Handles resolver and incremental encoder inputs simultaneously for safety-rated axis monitoring.
- Extended MTBF: Industrial-grade components rated for continuous 24/7 operation in thermally demanding paint booth enclosures.
System Architecture & Signal Flow
Within the IRC5P cabinet, the ASDI-03 occupies the Axis Computer slot on the main DSQC backplane. The Main Computer (DSQC 668/679) sends trajectory set-points over the internal bus; the ASDI-03 closes the servo loop locally by comparing set-points against resolver/encoder feedback from each drive unit (DSQC 601/602). Drive enable signals, brake control, and safety supervision are all routed through this board before reaching the axis drive modules.
Sourcing & Quality Verification
- Condition: New surplus / refurbished — each unit individually tested under power before shipment
- Traceability: Part number and revision label verified against ABB spare-parts database
- Packaging: ESD-safe anti-static bag + foam-lined carton
- Warranty: 12-month Konmask warranty covering functional defects
- Inspection Report: Available upon request for critical MRO procurement
Procurement Process
- Confirm your IRC5P controller serial number and current ASDI board revision (label on existing board).
- Submit your RFQ via support@konmask.com or place order directly on Konmask.com.
- Lead time: in-stock units ship within 1–2 business days; DHL / FedEx express available.
- Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
- Post-installation technical support available via email or WhatsApp.
Technical FAQ
Q: Is ASDI-03 backward compatible with ASDI-01/02 slots?
A: Yes — the board uses the same backplane connector and slot dimensions. However, always verify the RobotWare version supports ASDI-03 before swapping.
Q: Can this board be used in a standard IRC5 (non-paint) controller?
A: No. The IRC5P variant has a different backplane pinout and firmware stack. ASDI-03 is exclusively for IRC5P paint robot controllers.
Q: Do you provide a test report?
A: Yes. A functional test report is available upon request for orders requiring MRO documentation.
Q: What is the typical failure mode for ASDI-03?
A: Most field failures present as axis error 50056 (Axis Computer communication fault) or 50057 (Encoder feedback loss). If your IRC5P logs these errors and drive units test healthy, the ASDI-03 is the primary suspect.
