PROFIBUS DP Fieldbus Solution — ABB CI854BK01 (3BSE069449R1) | AC 800M Freelance Series
Where This Product Is Used
The ABB CI854BK01 is a PROFIBUS DP master/slave communication interface module designed for the AC 800M controller platform. It is deployed across a wide range of industrial automation environments where deterministic fieldbus communication is critical:
- Oil & Gas Processing Plants — Integrates field instruments (pressure transmitters, flow meters, valve positioners) via PROFIBUS DP into the AC 800M DCS backbone.
- Chemical & Petrochemical Facilities — Enables real-time process data exchange between distributed I/O stations and the central control system in hazardous-area installations.
- Power Generation & Utilities — Connects motor control centers (MCCs), drives, and protection relays to the plant DCS for unified supervisory control.
- Pulp & Paper Mills — Manages high-speed cyclic data transfer between the AC 800M controller and remote I/O clusters on the production line.
- Water & Wastewater Treatment — Provides reliable fieldbus connectivity for pump stations, dosing systems, and SCADA integration points.
- Pharmaceutical Manufacturing — Supports GMP-compliant process automation with deterministic communication to field devices in cleanroom environments.
Technical Specifications
| Part Number | CI854BK01 |
| ABB Order Code | 3BSE069449R1 |
| Series / Platform | AC 800M / Freelance |
| Module Type | Communication Interface Module |
| Fieldbus Protocol | PROFIBUS DP (EN 50170) |
| Operating Mode | DP Master Class 1 & Class 2 / DP Slave |
| Max. DP Slaves | Up to 125 slaves per segment |
| Baud Rate | 9.6 kbps – 12 Mbps (auto-detect) |
| Connector | 9-pin D-Sub (RS-485) |
| Power Supply | Via AC 800M backplane (5 VDC) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Humidity | 5% – 95% RH (non-condensing) |
| Weight | 460 g |
| Country of Origin | Sweden |
| HS Code | 853710 |
Why Engineers Specify This Model
- Native AC 800M Integration — Plug-and-play compatibility with the AC 800M controller family eliminates custom driver development and reduces commissioning time.
- Dual-Role Flexibility — Operates as both DP Master (Class 1 & 2) and DP Slave, enabling flexible network topologies including redundant ring architectures.
- High-Speed Deterministic Communication — Auto-negotiated baud rates up to 12 Mbps ensure cycle times meet the demands of fast-loop process control.
- Proven Reliability in Harsh Environments — Designed to IEC 61131-2 standards with wide temperature tolerance and vibration resistance for plant-floor deployment.
- Seamless ABB 800xA Integration — Fully supported by ABB System 800xA engineering tools for online configuration, diagnostics, and asset monitoring.
- Long Product Lifecycle — ABB’s extended support commitment for the AC 800M platform protects capital investment in existing DCS infrastructure.
Complete System Bill of Materials
For a fully operational PROFIBUS DP fieldbus node using the CI854BK01, the following components are typically required:
- ABB CI854BK01 (3BSE069449R1) — PROFIBUS DP Communication Interface Module (this item)
- ABB AC 800M Controller (e.g., PM864A / PM866A) — Host controller unit
- ABB TB807 / TB840A — Termination board for backplane mounting
- ABB SD821 / SD822 — 24 VDC power supply unit
- PROFIBUS DP cable (shielded, Type A, IEC 61158) — Field wiring
- PROFIBUS DP bus terminator plugs — Network termination at segment ends
- ABB 800xA Engineering Workstation — Configuration and commissioning software
Compliance & Industry Standards
- PROFIBUS DP — EN 50170 / IEC 61158 / IEC 61784
- Programmable Controllers — IEC 61131-2
- EMC Directive — CE marked (2014/30/EU)
- RoHS Compliant — Directive 2011/65/EU
- Functional Safety — Suitable for use in SIL-rated systems when configured per ABB safety manual
- ATEX / IECEx — Consult ABB documentation for hazardous-area installation requirements
Quality Assurance & Sourcing
Every ABB CI854BK01 unit offered through Konmask.com undergoes a structured verification process before dispatch:
- Visual Inspection — Enclosure integrity, connector condition, and label legibility checked against ABB factory standards.
- Functional Power-On Test — Module powered and status LEDs verified for normal boot sequence.
- Firmware Version Verification — Firmware revision confirmed and documented with each shipment.
- Traceability — Serial number and batch code recorded; full documentation available on request.
- Packaging — Anti-static bag + foam-lined carton; original ABB packaging retained where available.
We source from authorized ABB distributors, decommissioned plant upgrades, and certified surplus channels. All units are genuine ABB — no counterfeit or rebranded parts.
How to Source This Part
- Request a Quote — Email [email protected] with your required quantity, delivery timeline, and destination country.
- Receive Proforma Invoice — We respond within 1 business day with pricing, lead time, and shipping options (DHL / FedEx / sea freight).
- Confirm & Pay — Secure payment via T/T bank transfer, PayPal, or credit card through our Shopify checkout.
- Dispatch & Track — Units ship within 3–5 business days; tracking number provided upon dispatch.
- After-Sales Support — 90-day warranty on all tested units; technical support available via email or WhatsApp.
Application-Specific FAQ
Q: Is the CI854BK01 compatible with the AC 800M PM864A controller?
A: Yes. The CI854BK01 is designed for the AC 800M platform and is compatible with PM864A, PM866A, and other AC 800M controller variants. Verify firmware compatibility with your specific controller revision using ABB’s compatibility matrix.
Q: Can this module operate as a PROFIBUS DP slave?
A: Yes. The CI854BK01 supports both DP Master (Class 1 & 2) and DP Slave modes, configurable via ABB 800xA engineering tools.
Q: What is the maximum cable length for PROFIBUS DP at 12 Mbps?
A: At 12 Mbps, the maximum segment length is 100 m using Type A cable. Repeaters can extend the network. At lower baud rates (e.g., 187.5 kbps), segment length extends to 1,000 m.
Q: Do you provide an ABB test report or certificate of conformity?
A: We provide our internal inspection report with every shipment. Original ABB certificates of conformity are available for new/unused stock. Contact us to confirm availability for your specific unit.
Q: Can you supply multiple units for a plant-wide DCS upgrade?
A: Yes. We maintain stock of multiple CI854BK01 units and can fulfill bulk orders. Contact us for volume pricing and consolidated shipping options.
Q: What export documentation is available for international shipments?
A: We provide commercial invoice, packing list, and certificate of origin. For regulated destinations, we can assist with export classification (ECCN / HS code documentation).
