Robot Programming Solution – ABB FlexPendant 3HAC047118-003 | IRB 6700 Series
Where This Product Is Used
The ABB FlexPendant 3HAC047118-003 is the primary operator interface for ABB IRB 6700 series industrial robots equipped with the IRC5 controller (DSQC3060 / 3HAC064211-001). It is deployed across demanding industrial environments where precise robot programming, jogging, and real-time monitoring are critical:
- Automotive Body-in-White (BIW) Welding Lines – Teach and fine-tune weld paths on high-payload IRB 6700 robots handling car body panels.
- Heavy-Duty Material Handling – Program pick-and-place routines for payloads up to 235 kg in stamping and press-tending cells.
- Foundry & Casting Automation – Operate robots in high-temperature, high-vibration environments where pendant durability is non-negotiable.
- Palletizing & Depalletizing – Configure layer patterns and gripper logic directly from the pendant touchscreen on the factory floor.
- Machine Tending & CNC Loading – Jog axes and set tool offsets with millimeter precision during setup and changeover.
- Maintenance & Diagnostics – Access real-time I/O status, event logs, and axis calibration routines without a PC connection.
Technical Specifications
| Part Number | 3HAC047118-003 |
| Compatible Controller | IRC5 (DSQC3060 / 3HAC064211-001) |
| Compatible Robot Series | ABB IRB 6700 (all variants: 150/3.2, 175/3.05, 200/2.6, 235/2.65) |
| Display | 7-inch color touchscreen, 800 × 480 px |
| Operating System | Windows CE / RobotWare embedded |
| Communication Interface | Ethernet (RJ45) via IRC5 controller umbilical |
| Enabling Device | 3-position enabling switch (deadman) |
| Emergency Stop | Integrated hardware E-stop button |
| Ingress Protection | IP54 |
| Weight | 1.6 kg |
| Cable Length | 10 m (standard) |
| Language Support | Multi-language (configurable via RobotWare) |
| OEM Part Status | Genuine ABB / OEM-grade replacement |
Why Engineers Specify This Model
- Direct IRB 6700 Compatibility – Plug-and-play with IRC5 single/dual cabinet controllers; no firmware patching required.
- RAPID Programming On-Pendant – Edit, debug, and run ABB RAPID programs directly from the touchscreen without a laptop.
- 3-Position Enabling Switch – Meets ISO 10218-1 safety requirements for manual guiding in reduced-speed mode.
- Robust Industrial Build – IP54-rated housing withstands coolant splash, metal dust, and daily handling in harsh shop-floor conditions.
- Hot-Swap Capable – Disconnect and reconnect while the controller is powered (with proper safety precautions) to minimize downtime.
- Integrated Joystick – 6-axis joystick enables smooth manual motion in all coordinate systems (World, Tool, Wrist).
Complete System Bill of Materials
For a fully operational ABB IRB 6700 cell, the following components are typically required alongside this FlexPendant:
- ABB IRC5 Controller Cabinet – DSQC3060 (3HAC064211-001)
- ABB IRB 6700 Robot Manipulator (specify payload/reach variant)
- FlexPendant Cable Assembly – 3HAC031683-001 (10 m) or 3HAC044075-001 (7 m)
- RobotWare License – IRC5 base license + application options (Arc, PickMaster, etc.)
- Axis Computer / Drive Unit – 3HAC025338-001 (DSQC668)
- I/O Module – DSQC652 (3HAC025917-001) for digital I/O expansion
Compliance & Industry Standards
- ISO 10218-1:2011 – Industrial robots: Safety requirements for robot design
- IEC 60204-1 – Safety of machinery: Electrical equipment of machines
- EN ISO 13849-1 – Safety-related parts of control systems (PLd)
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC
- RoHS Compliant – Restriction of Hazardous Substances Directive
Quality Assurance & Sourcing
- ✅ OEM-Grade Parts – Sourced from authorized ABB distribution channels and verified surplus stock.
- ✅ Pre-Shipment Functional Test – Each unit is powered on and communication-verified before dispatch.
- ✅ Traceability – Serial number and firmware version documented with every shipment.
- ✅ Anti-Static Packaging – ESD-safe packaging with desiccant for long-term storage integrity.
- ✅ 90-Day Warranty – Covered against manufacturing defects and DOA (Dead on Arrival).
How to Source This Part
- Confirm Compatibility – Verify your IRC5 controller serial number and RobotWare version before ordering.
- Request a Quote – Contact support@konmask.com for volume pricing, lead time, and export documentation.
- Place Order – Add to cart and complete checkout; we accept T/T, PayPal, and major credit cards.
- Shipping – DHL / FedEx express worldwide; typical transit 3–7 business days. Export-controlled items may require EUC documentation.
- After-Sales Support – Our engineers provide installation guidance and RobotWare configuration support post-delivery.
Application-Specific FAQ
Q: Is 3HAC047118-003 compatible with IRB 6700-205/2.8?
A: Yes. The FlexPendant 3HAC047118-003 is compatible with all IRB 6700 variants sharing the IRC5 controller platform, including the 205/2.8 model.
Q: Can this pendant be used with an IRC5 Compact controller?
A: Yes, provided the IRC5 Compact uses the DSQC3060 main computer. Verify the controller generation before ordering.
Q: What RobotWare version does this pendant support?
A: Compatible with RobotWare 6.x and later. For RobotWare 5.x systems, please contact us to confirm firmware compatibility.
Q: Do you provide the FlexPendant cable separately?
A: Yes. We stock standard 10 m cables (3HAC031683-001) and 7 m cables (3HAC044075-001). Please specify when ordering.
Q: Is this a new or refurbished unit?
A: We stock both new OEM units and professionally refurbished units. Product condition is clearly stated on the listing. Contact us if you need clarification.
